The rear panel of this 4 Channel Sound Card has the following jacks:
1.
Line In (blue) – Line-In Connect to the audio output port of
stereo
2.
Mic In (pink) – Connect to the Microphone (Mono)
3.
Front-Speaker (green) – Output to speakers with the amplifier
or earphones or Audio-in of home stereo
4.
Rear-Speaker (black) – Connect to the rear speakers while four
channel speakers mode is enabled
In addition to the rear panel jacks, this 4 Channel Sound Card also has
the following internal connection:
The Connector
J1
J2
J3
Jun/07
The Function
Analog CD/IN Port(Signals: L-G-G-R)
Analog CD/IN Port(Signals: G-R-G-L)
Aux-in
5
MN4000000027
