Carisma GT14B Instruction Manual

1:16 scale shaft drive 4wd

Advertisement

Chassis Specification
• Length : 309mm • Width : 213mm • Wheelbase : 190mm • Front Tire : ø75.5mm x 33mm (width) • Rear Tire : ø75.5mm x 26mm (width)
˚
• Camber : Preset -1
• Running Weight : Approx. 920g with battery pack
Contents
Safety Precaution
MAN-G00184
INSTRUCTION MANUAL
˚
toe - out (adjustable) • Rear Toe - in : Preset 2.5
˚
˚
2
3
4
6
7
8
9
10
11
12
13
17
18
19
20
21
22
23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT14B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Carisma GT14B

  • Page 1: Table Of Contents

    • Running Weight : Approx. 920g with battery pack Contents Safety Precaution Item Included / Tool Required About the 2.4GHz Radio System About GT14B Chassis Steering and Rate Adjustment Chassis Set-up Tips Battery Pack & Charger Menu Trouble Shooting Guide...
  • Page 2 The associated regulatory agencies of the following countries recognize the noted certifications for this product as authorized for sale and use. Declaration of Conformity Products: Carisma CTX-2810 2.4GHz Transmitter, MRX2800 Receiver, V6 Type R Electronic Speed Controller , MS-903GT Servo Equipment Class: 2 The objects of declaration described above are in conformity with the requirements of the specifications listed below.
  • Page 3: Item Included / Tool Required

    ITEM INCLUDED Parts Included CTX-2810 Transmitter GT14B Main Chassis / Car Body / Assembled Antenna Pipe Servo Saver Adaptor Spur Gear (66T, 68T) Hex Wrench Mini Spanner Plastic Wrench TOOLS REQUIRED Required Equipment Recommended to use the following tools to operate or maintenance of your RC model :...
  • Page 4: About The 2.4Ghz Radio System

    ABOUT THE RADIO SYSTEM Carisma CTX-2810 2.4GHz FHSS Technology System The following is an overview of the various functions and adjustments found on CTX-2810 radio system for GT14 series RC models. Since GT14 model operates on the radio signal you control, it is important for you to read and understand about all of these functions and adjustments before driving.
  • Page 5 ABOUT THE RADIO SYSTEM About Transmitter Antenna In favor of the user to operate as they wish during running, the antenna of CTX-2810 transmitter • Always keep the antenna of transmitter vertical to the ground can be rotated to every direction within the adjustment range. While the foldable feature is helpful when synchronization.
  • Page 7: About Gt14B Chassis

    - RED LED flashing quickly 3 times, turn off and then repeat Condition • Battery Low Stop GREEN - GREEN LED solid on and RED LED flashing slowly Partial Forward Recommended Gear Ratio with 4500KV Carisma Brushless Motor Max Forward Partial Reverse Pinion Spur Gear Gear Max Reverse ✔...
  • Page 8: Steering And Rate Adjustment

    After you have finished, turn the GT14B Model Car off first by sliding the switch on the ESC to the “ OFF” position. After the model has been turned off, turn off the transmitter. If you wish to clean your GT14B Model Car, use compressed air and / or a soft paint brush to remove the dust and dirt. Never use chemicals or anything wet as it can cause damage to both the electronics and plastic parts.
  • Page 9: Chassis Set-Up Tips

    CHASSIS TUNING TIPS GT14B Model Car has several adjustments available to match your driving need. Although there are multiple shock positions and camber link locations provided, we have built this model with the best overall settings. The following are simple adjustments and easily maintained settings for proper operation and performance. It is advised when making any adjustment you do so in small increments and always check for other parts of the chassis that are affected.
  • Page 10: Slipper Adjustment

    Mini Spanner Mini Spanner the GT14B Model Car on the ground. As you push the car backwards allowing it to roll freely, punch the throttle. The slipper should slip no more than an inch or two as it accelerates. With the included motor and battery it should slip just a little.
  • Page 11: Battery Pack & Charger Menu

    BATTERY PACK & CHARGER MENU Battery Pack & Charger Manual Operation • Completely discharge a Nickel - Metal Hydride (NiMH) battery pack befor you charge it. Frequent charging a Nickel - Metal Hydride battery pack that is not fully discharged can shorten its battery life. 7.2V Battery Charger 7.2V Battery Charger •...
  • Page 12: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE Trouble Shooting Guide / Q&A Solutions Problems Possible Reasons Short run time / • Battery not fully charged • Fully recharge batteries Running slow • Battery power has run down • Replace new batteries • Motor gets dirty or worn out •...
  • Page 13: Assembly Diagrams

    OIL SHOCK / DIFFERENTIAL GEAR ASSEMBLY DIAGRAM Oil Shock Assembly Diagram MASM1687A RBP-G00010 MASM053A MASM053A GT14B0801 GT14B0802 RBP-G00014 MASM457A GT14B0805 GT14B0806 MASM1688A MASM1686A GT14B0803 GT14B0804 Ball Differential Assembly Diagram EVA-G00003 SSW-G00370 MASM745A MASM033A MASM589A GT14BP0902 MASM1833A MASM1858A MASM1836A MASM083A MASM083A MASM033A MASM1836A MASM588A...
  • Page 14 STEERING HUB / REAR HUB ASSEMBLY DIAGRAM Steering Hub Assembly Diagram MASM487A MASM1631A ME031A ME031A MASM1624A GT14BP0302 MASM1631A Steering Hub / C-Hub Assembly Diagram MASM487A GT14BP0507 SSW-G00454 GT14BP0305 MASM245A SSW-G00454 MASM733A Rear Hub Assembly Diagram GT14BP0507 MASM487A MASM245A MASM1624A GT14BP0305 ME031A MASM733A ME031A...
  • Page 15: Caster : Preset

    STEERING UNIT / SERVO UNIT ASSEMBLY DIAGRAM GT14BP0607 GT14BP0703 GT14BP0702 MS903 MASM693A GT14BP0701 SSW-G00284 FRP-G00029 SSW-G00147 SSW-G00147...
  • Page 16 MOTOR ASSEMBLY DIAGRAM Motor Mounting / Pinion and Spur Gear Mesh Setting the Gear Mesh Proper gear mesh is important to the performance of your vehicle.If mesh is too loose it will cause the spur gear to fail (strip); if set too tight it will decrease speed and the motor will overheat. To set the gear mesh, loosen the motor screws and insert a small piece of paper between Pinion gear and Spur gear.
  • Page 17: Assembly Diagrams 13

    HINGE MOUNT ASSEMBLY DIAGRAM...
  • Page 18: Gt14B Exploded Diagram

    GT14B EXPLODED DIAGRAM...
  • Page 19: Spare Parts List

    Front Inner Hinge Pin Brace GT14BP0602 Front Outer Hinge Pin Brace GT14BP0603 Front Shock Tower Support GT14BP0604 Rear Inner Hinge Pin Brace GT14B Hinge Pin Brace / Shock Tower Support 14735 GT14BP0605 Rear Outer Hinge Pin Brace GT14BP0606 Rear Shock Tower Support GT14BP0607...
  • Page 20 2.6 x 10CM(D=4.6mm) SSW-G00454 GT14B-B0101BL Main Body Blue GT14B-B0102 Bottom Cover GT14B-B0103BL Rear Wing Blue GT14B-B0104BL Front Nose Blue GT14B Blue Car Body with Stickers 14682 GT14B-B0105 Front Nose base GT14B-B0106 Spur Gear Cover DCC-G00136 GT14B Body Sticker DCC-G00137 GT14B Logo Sticker...
  • Page 21: Option Parts List

    GT14B Carbon Fibre Main Chassis 14763 GT14B Carbon Fibre Upper Deck 14764 GT14B Turnbuckle 14685 GT14B Carbon Fibre Shock Tower 14766 GT14B Aluminum Wheel Hex 14686 GT14B Assembled CVD Set 14761 GT14B 7.4V 2000mAh LiPo Battery 14765 GT14B Aluminum Inner Hinge Pin Brace...
  • Page 22 14767 GT14B Aluminum Slipper Plate 14769 GT14B Shock Spring ( Soft ) 14770 GT14B Anti Roll Bar 14794 GT14B Aluminum Rear Inner Hinge Pin Brace (3˚ Toe-in) 14775 GT14B Spur Gear 66T 14796 GT14B Hard Servo Spring 14776 GT14B Spur Gear 68T...
  • Page 23: Setup Sheet

    SETUP SHEET Servo : Wing : Front Tire Insert : Rear Tire Insert : Front Anti Roll Bar : Rear Anti Roll Bar :...
  • Page 24 Tel : (852) 2427 5831 Fax : (852) 2480 3087 Email : info@matoys.com www.matoys.com VISIT US ON www.shop-carisma.com © 2010 Carisma. All Rights Reserved. Product specifications are subject to change. Printed in China Some models shown are prototypes which may vary slightly from what is inside.
