- Page 1 Premium Entry Level Real-Time HD-SDI DVR User’s Manual OR-7500FD ▪ Triple Streaming / Digital Zoom ▪ Advanced User Authority Level ▪ Max 128ch CMS Client S/W ▪ POS (Text Insert Function)
-
Page 2: Preface
Digital Video Surveillance System. For best use of this product, read this manual carefully and keep this manual close to your hand. Copyright/Authentication/Trademark/Limited Warranty Copyright Copyright (c)2012. Orion Technology . All rights reserved. All contents and pictures cannot be copied without permission. Authentication CE, FCC, KCC Trademark Ethernet(TM) is a trademark of Xerox Corporation. - Page 3 User’s Manual OR-7500FD Series Risk of death or serious injury. This is the highest priority danger warning. • RISK OF EXPLOSION IF BATTERY IS REPLACED BY INCORRECT TYPE. DISPOSE OF USED BATTERY ACCORDING TO THE INSTRCTIONS. • THIS EQUIPMENT IS INDOOR USE AND ALL THE COMMUNICATION WIRINGS ARE LIMITED TO INSIDE OF THE BUILDING.
- Page 4 User’s Manual OR-7500FD Series Risk of minor injury or damage. • If a foreign substance is stuck to the product, remove it using a soft cloth or tissue. Do not use chemical agents (thinner, solvent, etc.) to remove the substance.
-
Page 5: Table Of Contents
User’s Manual OR-7500FD Series Contents Preface ....................0 Contents ..................... 4 Chapter 1. Introduction ..............7 1. The System ......................7 2. General Features ....................7 3. Specification ....................... 8 Chapter 2. System Installation ............9 1. Package Contents ....................9 2. - Page 6 User’s Manual OR-7500FD Series 2-6-2. MENU > EVENT > Motion ............... 35 2-6-3. MENU > EVENT > Video Loss ..............37 2-6-4. MENU > EVENT > Text-In ............... 38 2-6-5. MENU > EVENT > System ............... 40 3. Playback ......................41 3-1.
- Page 7 User’s Manual OR-7500FD Series F. Import Digital Signage File into DVR ............... 76 Appendix D. NEMON Network Archive Instructions ......77 1. Outline ....................... 77 2. Feature ....................... 77 3. How to use Network Archiver ................78 Step 1) Entering Archiving Site address and following information for a site registrati on and log-in.
-
Page 8: Chapter 1. Introduction
User’s Manual OR-7500FD Series Chapter 1. Introduction 1. The System This product is targeted at expanding DVR market. As the market is expanding from Professional to Consumer and into wider sectors, both price and feature oriented products are highly demanded in these days across different market sectors. This product is designed to fulfill these various aspects of different market sectors. -
Page 9: Specification
User’s Manual OR-7500FD Series 3. Specification OR-7504FD Model OR-7502FD 4 BNC (No Loop-out) 2 BNC (No Loop-out) Video 1 HDMI, 1 VGA , 2 CVBS (Spot) 4 RCA Line-in 2 RCA (Line Input) Audio 1 HDMI, 1 RCA (Line Output), 2 RCA (Spot) -
Page 10: Chapter 2. System Installation
User’s Manual OR-7500FD Series Chapter 2. System Installation 1. Package Contents The following components are included in product box: DVR Unit DC Adaptor Power Cord Remote Controller Quick Guide (User's Manual & Network S/W) -
Page 11: Connecting Devices
User’s Manual OR-7500FD Series 2. Connecting Devices Following picture shows the rear panel of DVR: • Front USB : Two USB ports are available in front to connect external devices like HDD, Flash memory for Backup, System upgrade or USB mouse. - Page 12 User’s Manual OR-7500FD Series HDMI, VGA Output Connect HDMI monitor or VGA monitor. This DVR provides same image output on HDMI and VGA monitor. Available output resolutions are 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768. Factory default is 1280 x 720. To change output, see following 3 steps.
-
Page 13: Cautions
User’s Manual OR-7500FD Series 3. Cautions • Avoid installing the product where there are direct rays or it is hot by locating near from heat generator. (May cause fire) • Do not put vase, flowerpot, cup, cosmetics, drug, and anything the contain water on product. -
Page 14: Chapter 3. Using Dvr
User’s Manual OR-7500FD Series Chapter 3. Using DVR 1. Basic Operation 1-1. Front Panel & IR Remote Controller This DVR should be installed correctly before using. Button’s position and shape may varied by DVR model. Commonly used main buttons positioned in front panel. -
Page 15: Turning On The System
User’s Manual OR-7500FD Series ZOOM Button Zoom current camera image on screen. PIP Button Change to PIP screen mode from live screen. FREEZE Button Freeze current screen. AUDIO Button Select channel for live & playback audio output. OSD Button Turn on/off OSD display. -
Page 16: Display Icons
User’s Manual OR-7500FD Series 1-4. Display Icons No Recording Recording (Red) E.REC (Emergency Recording) Event Recording (Red) Pre Event Recording (Blue) Motion Detection Sensor Detection Text In PTZ Camera Instant Backup Clip Maker (Blue) Backup (Red) Video Loss... -
Page 17: User Or Admin Login
User’s Manual OR-7500FD Series 1-5. User or Admin Login Press MENU to enter main menu. Login screen appears to enter ID and Password. Up to 8 numbers are required on password with combination of numbers from 0 to 9. Click numeric buttons on the bottom to enter password. -
Page 18: The Main Menu
User’s Manual OR-7500FD Series 1-6. The Main Menu The Main Menu of DVR consists of SYSTEM, DEVICE, DISPLAY, RECORD, NETWORK and EVENT. And each menu consists of various sub menus that allow detail set up of the system. Use Mouse, Remote Controller or Front Buttons to access each menu. -
Page 19: Contextual Menu
User’s Manual OR-7500FD Series 1-7. Contextual Menu Additional Contextual Menu screen appears by pressing right button on the Mouse. Camera : Select camera no. OSD: select OSD display option Freeze : Pause current image display Display: Display option Audio : Select Audio output... -
Page 20: Dvr Configuration
User’s Manual OR-7500FD Series 2. DVR Configuration 2-1. SYSTEM In SYSTEM menu, System configuration options for general Information, Date &Time, User, Quick Setup and System Log can be selected. 2-1-1. MENU > SYSTEM > Information In Information screen, DVR Name, MAC Address, Version, Upgrade, Mac Address, Remote Controller ID and Configuration options can be selected. -
Page 21: Menu > System > Date & Time
User’s Manual OR-7500FD Series 2-1-2. MENU > SYSTEM > Date & Time In the Date & Time, Time Zone, Date, Time, NTP Server, Holiday options can be selected. Highlight and press Time Zone to select right Time Zone. Select ‘Use Daylight Saving Time’ if it is applicable. -
Page 22: Menu > System > User
User’s Manual OR-7500FD Series 2-1-3. MENU > SYSTEM > USER User can define new user and permissions on this page Add new user with press button. To delete, use button. Auto Login: It allows user to log in right after system boots up automatically. As a system allows... -
Page 23: Menu > System > Quick Setup
User’s Manual OR-7500FD Series 2-1-4. MENU > SYSTEM > QUICK SETUP Quick Setup Menu allows easy and basic setup for main menu settings. 2-1-5. MENU > SYSTEM > SYSTEM LOG In the System Log, full list of system logs can be searched. -
Page 24: Device
User’s Manual OR-7500FD Series 2-2. DEVICE Under Device menu, Device configuration options for Camera, Audio, Alarm, Keyboard and RS232 & RS485 (POS/PTZ/Keyboard) can be selected. 2-2-1. MENU > DEVICE > Camera Set Camera display option. Camera display (video loss display) can be disabled by unmarking the box next to it if there is no camera connected. -
Page 25: Menu > Device > Audio
User’s Manual OR-7500FD Series Covert Setting Covert setting allows the privacy on monitoring. If Covert is set, live or playback image will not be displayed. Covert can be scheduled by day, time and mode by cameras. Covert Low Mode: No display of video image on screen but OSD still remains on screen. -
Page 26: Menu > Device > Keyboard
User’s Manual OR-7500FD Series 2-2-4. MENU > DEVICE > Keyboard Press to find and select keyboard from the list. 2-2-5. MENU > DEVICE > RS232 & RS485 Press to select a device for each port. RS232: Supports Text In (POS) device. PTZ... -
Page 27: Display
User’s Manual OR-7500FD Series 2-3. DISPLAY Set display configuration and composite output on this menu. 2-3-1. MENU > DISPLAY > Display Language: Select system language. Press to find available language options. Hide Status Bar: Select On/Off and time to hide Status Bar when system is not in use. -
Page 28: Menu > Display > Cvbs
User’s Manual OR-7500FD Series 2-3-2. MENU > DISPLAY > CVBS Video type : Select signal type (NTSC/PAL) for composite output. Aspect Ratio: select ratio of composite output image according to following situation. - Letterbox In Letterbox, it shows 16:9 ratio screen displayed. -
Page 29: Record
User’s Manual OR-7500FD Series 2-4. RECORD Under Record menu, Record configuration options for Storage, Record and Record Tools can be selected. 2-4-1. MENU > RECORD > Storage In Storage, it displays the installed/connected storage status such as Capacity, Type, Usage and Status. - Page 30 User’s Manual OR-7500FD Series In Event, pre and post recording options for Event can be set. Pre-Event Duration: Video Images occurred right before an Event can be recorded by setting Pre-Event under Event Mode. Duration Pre-Event recording can be set using Pre- Event(sec) up to 30 seconds.
-
Page 31: Menu > Record > Utilities
User’s Manual OR-7500FD Series 2-4-3. MENU > RECORD > Utilities In Recording Status, it displays current recording options and status. The list will show Recording Frames, Video Quality, Resolution. Press Calculate once resolutions, ips, number of cameras and quality are set. The recording period is calculated based the size of HDD installed. -
Page 32: Network
User’s Manual OR-7500FD Series 2-5. NETWORK In Network menu, Network configuration options for network Address, DDNS, Remote Notification and Transmission can be set up. 2-5-1. MENU > NETWORK > Address In Address, Information such as Type, IP address, Subnet Mask, Gateway Port and DNS can be set for network connections. -
Page 33: Menu > Network > Ddns
User’s Manual OR-7500FD Series 2-5-2. MENU > NETWORK > DDNS In the DDNS, network options for DDNS can be selected. DDNS: Dynamic Domain Name Server allows dynamic network connections. Note : “dvr-ddns.com” and “www.dyndns.org” offer free registrations for DDNS service. -
Page 34: Menu > Network > Transmission
User’s Manual OR-7500FD Series be sent to remote site via email. SMTP Server: Enter SMTP server with virtual keyboard. SMTP server information can be obtained from a system administrator. Sender: Enter the address/name where the email is being sent from. -
Page 35: Event
User’s Manual OR-7500FD Series 2-6. EVENT In Event menu, user can set event related actions. Events are about Sensor, Motion, Video Loss, Text-In, System. 2-6-1. MENU > EVENT > Sensor In Sensor, each sensor can be selected for activation and its type. Select Sensor Type using button. -
Page 36: Menu > Event > Motion
User’s Manual OR-7500FD Series Preset feature on PTZ camera can be activated by the Event triggering. When Event occurs, PTZ moves to the preset position where event and positions are. The above menu shows that sensor 1 is set to activate cameras 1,2,3 and 4. If you click PTZ section, PTZ preset (position) can be set for cameras in the event of Sensor activation. - Page 37 User’s Manual OR-7500FD Series In Record, each camera can be connected to single or multiple motion detections from other cameras. Press to select cameras to be synchronized with motions detections. In Alarm, each camera with motion can be connected to single and multiple alarms. Press to select alarms to be connected to cameras for motion events.
-
Page 38: Menu > Event > Video Loss
User’s Manual OR-7500FD Series 2-6-3. MENU > EVENT > Video Loss In Video Loss, single or multi cameras can be synchronized for event recording when there is a video loss. Press to select single or multi cameras to be synchronized with cameras for video loss. -
Page 39: Menu > Event > Text-In
User’s Manual OR-7500FD Series 2-6-4. MENU > EVENT > Text-In The system allows Text In from POS/ATM machines. Note : For use of POS/ATM, the system must support generic ASCII code. Text-In Model: Select Text-In model from the list Transaction Begin: Enter a word which the transaction info to be displayed on screen as a start. - Page 40 User’s Manual OR-7500FD Series In Notification, text event can be synchronized with single and multi callback or emailing sites. Press to enter callback or email address to be synchronized with text event. In Text In, each text input can be synchronized with single and multiple cameras. Press...
-
Page 41: Menu > Event > System
User’s Manual OR-7500FD Series 2-6-5. MENU > EVENT > System In System, S.M.A.R.T function monitors storage conditions such as Temperature, Conditions and Recording. Storage Full option can be set to notify a message for the indication of HDD storage usage level. Warning message can be notified in various ways as described below. -
Page 42: Playback
User’s Manual OR-7500FD Series 3. Playback The system provides various playback menus to search recorded data. Please click right Mouse button on Search Mode and select the storage type. If backup data is selected, the data on external HDD can be searched. -
Page 43: Go To Time
User’s Manual OR-7500FD Series 3-1. Go to Time Select Go to Time to search recorded data by time/date. Set time/date using button. Go to Beginning and End options are selectable to search the very first and last data recorded. Once desired settings are completed, press OK to begin playback. -
Page 44: Text-In Search
User’s Manual OR-7500FD Series playback the event data. 3-4. Text-In Search Text In Search provides easy search by transactions. Search for Time and Transaction information. Press Search for detail information. From: Set beginning time to start search or select First for search from the first data. -
Page 45: Backup Data Playback
User’s Manual OR-7500FD Series 3-5. Backup Data Playback Backup files on backup media can be played on DVR. Insert the media with backup files and select a file to playback it on DVR. 3-6. Playback Control R.Play: Reverse Playback Step Backward: Go to the previous image... -
Page 46: Backup
User’s Manual OR-7500FD Series 4. Backup Recorded data can be backed up on USB Flash memory. Select backup or Clip Copy option during Search or Live mode by selecting Backup. 4-1. Backup In the BACKUP, the recorded data can be selected for backup to USB devices. -
Page 47: Instant Backup
User’s Manual OR-7500FD Series 4-2. Instant Backup Press backup button to start Instant Backup during the playback. Instant Backup window will appear when press backup button during the normal playback mode. Select Device, File Name, Audio and press Start to continue the playback and backup. The Backup Icon will appear on the screen during the Instant Playback. -
Page 48: Chapter 4. Remote Software
User’s Manual OR-7500FD Series Chapter 4. Remote Software 1. Using Remote Software Note : Before using the remote software, refer to a customer card in the package to download the software. Please install the software on your PC once you download it. - Page 49 User’s Manual OR-7500FD Series Playback Control: Use buttons to control playback images. (Stop, Move by Image, Play, Rewind/Forward, and Move to First/End) Display Mode: Select display modes. (single screen, 4, 9, 16, 25, 36, 49, 64 and full screen) Change Display Page: Change Display Mode to Previous or Next page in camera order.
-
Page 50: Site Set Up
User’s Manual OR-7500FD Series 1-2. Site Set Up Click Connect button to display registered remote locations or add new locations. Click button to add remote location and required information. Name: Enter Site Name Address: Enter IP address or domain name of the site... - Page 51 User’s Manual OR-7500FD Series Click to save information and complete the registration. Double click the location or Highlight it and click Connection button to get connected to the site. The DVR and Client program on PC start searching each other once they are on the same local network.
-
Page 52: Favorite Set Up
User’s Manual OR-7500FD Series 1-3. Favorite Set Up Favorite function allows multiple site management. Up to 64 different cameras and sites can be monitored and managed on one screen. Select Favorite tap. Click button to group multiple sites as one favorite group. -
Page 53: Site List Panel
User’s Manual OR-7500FD Series 1-3. Site List Panel The remote sites also can be registered on Site List Panel. Use , EDIT , REMOVE buttons on the bottom to register and managed the remote sites and favorite sites. Drag and Drop the listed sites on to the display section to connect the sites. Each camera can be dragged and dropped to arrange independent displays. -
Page 54: Tool Panel
User’s Manual OR-7500FD Series 1-4. Tool Panel 1-4-1. DVR Status DVR tap shows Video Loss, Motion Detection, Sensor Detection status of currently connected remote site. User can activate a remote alarm on DVR Status options. Reload: Refresh the latest DVR status info. -
Page 55: Text-In
User’s Manual OR-7500FD Series 1-4-3. TEXT-IN Displays recorded TEXT-IN info. TEXT-IN tap is activated under playback mode only. 1-4-4. GPS GPS is for Mobile DVR tracking under playback mode. GPS data is recorded with images using built in GPS on Mobile DVR. This data will be displayed on Google Map under playback mode. -
Page 56: Remote Playback
User’s Manual OR-7500FD Series 2. Remote Playback 2-1. Calendar Search Calendar Search Panel appears when a site is connected under playback mode as shown below. Time bar will appear once the date is selected and the image preview will appear when the specific time is selected on the time bar. -
Page 57: Event Search
User’s Manual OR-7500FD Series 2-2. Event Search Select Event Search on the bottom of the screen to open Event Search Panel. Enter Date, Event Type and etc and select SEARCH button to retrieve the search results. Fold Event Search Panel Event Search Select an event from the list for playback. -
Page 58: Text-In Search
User’s Manual OR-7500FD Series 2-3. Text-In Search Select Text-In Search on the bottom of the screen to open TEXT-IN Search Panel. Enter Date and Text and select SEARCH button to retrieve the search results. Fold Text-In Search Panel Text-In Search... -
Page 59: Saving Recorded Data
User’s Manual OR-7500FD Series 2-4. Saving recorded data Screenshot Select button to capture the current image during the playback as show below. Select Save... button to save the image. The Image can be saved in JPEG, BMP and PNG format. -
Page 60: Play Backup Data
User’s Manual OR-7500FD Series Backup Select button during the playback and select “Backup” to open the window as shown below to save data in own video format. • Enter file name and select Location. • Select the time period. • Select Camera number. Press Start to create Backup file. -
Page 61: Play Independent Hdd Data On Pc
User’s Manual OR-7500FD Series 2-6. Play Independent HDD Data on PC Independent HDD (removed from a DVR) data can be played on PC using the remote software. Have the HDD connected to PC using a SATA to USB connector cable. Make sure the HDD is... -
Page 62: Setup
User’s Manual OR-7500FD Series 3. Setup 3-1. Remote Software Setup Click on Setup to enter the remote software setup menu. Product: Displays general information of the S/W Software Version: Displays current S/W version Secondary Monitor: Select the secondary monitor when using multi monitors on PC Event Pop-up Duration: Set the time duration for a camera display when it is displayed in full screen mode in case of event. - Page 63 User’s Manual OR-7500FD Series Click on Display tap to enter display setup menu. Maintain Aspect Ration (4:3): Keep 4:3 ration on the remote software display screen Use Alpha-Blending: Enables alpha-blending effect to S/W UI Video Acceleration: Video Acceleration option enhances natural live image display on the client S/W.
- Page 64 User’s Manual OR-7500FD Series Click on Sequence tap to enter sequence setup menu. Set sequence mode and sequential sites from registered individual or Favorite sites. Click the site and select > button to add the site into the sequencing list.
- Page 65 User’s Manual OR-7500FD Series Click on User tap to enter user setup menu. Register the remote software users. Each user needs to use the password they set in registration when they log in. Select Add to start new user registration.
-
Page 66: Remote Dvr Setup
User’s Manual OR-7500FD Series 3-2. Remote DVR Setup Click on and Remote Setup to enter remote setup menu. Select a DVR for setup and select Connection button. Setup menu will appear as show below once it is connected Note : The remote software provides interactive setup system that allows easy local DVR settings... -
Page 67: Remote Upgrade
User’s Manual OR-7500FD Series 3-3. Remote Upgrade The system upgrade can be done through the remote software program on PC. • Click on and Remote Setup to enter remote setup menu. • Select Information under System. • Click Upgrade next to S/W version to find a file for upgrade •... -
Page 68: Callback
User’s Manual OR-7500FD Series 4. Callback Start-> Program -> remote software folder -> Callback Callback icon will be displayed on the bottom right of Window once the program starts. Callback message will be displayed/notified as shown above. Click Callback icon to display main window of Callback as shown below. - Page 69 User’s Manual OR-7500FD Series Select a log from the list and click Live or Playback icon image to connect related DVR. Clear: Clear all the logs listed on Callback window Log: Click Log button to display log search window as shown below.
-
Page 70: Appendix A. Remote Access Using I.e
User’s Manual OR-7500FD Series Appendix A. Remote Access Using I.E. DVR can be accessed remotely using Internet Explore. Execute internet explore program and enter DVR address (e.g. IP) to get connected. Remote Log In page appears once connected to DVR. Enter ID, PW and Port information, and select Live or Playback mode to display desired remote control option. -
Page 71: Appendix B. How To Set Ddns Using Router
User’s Manual OR-7500FD Series Appendix B. How to set DDNS using router (Except using public IP or connect with ADSL directly) Make it easy to understand through the example as below. Please refer the Diagram and follow this instruction. For example, If you connect 3 DVRs through local Network. - Page 72 User’s Manual OR-7500FD Series - Fill out the registration information as below. - Click ‘Submit’ to make the account. - Enter your domain name and click ‘Request Domain’ to create the domain name. - You can see the registered dome name “dvr1.dvr-ddns.com”...
-
Page 73: Router Configuration
User’s Manual OR-7500FD Series - You can create 3 domain names for one account. - Click “Create additional domain names” to make another domain name. 2. Router Configuration - Insert the gateway address on the explorer to connect the homepage for the Router. -
Page 74: Dvr Configuration
User’s Manual OR-7500FD Series 3. DVR Configuration Example of DVR Network setting. Select Static IP option and enter following options accordingly. The system should be allocated with individual IP address. Make sure the ports for DVR are all set accordingly or set network ports according to DVR port settings. -
Page 75: Appendix C. Digital Signage Maker
User’s Manual OR-7500FD Series Appendix C. Digital Signage Maker Digital Signage Maker converts any video files into DVR’s Digital Signage format (JPG). Digital Signage Maker Options and Limitations. (Before/After Conversion) Video File Digital Signage File Conversion Video Files Filename_00001.JPG, File Name... -
Page 76: How To Use Digital Signage Maker
User’s Manual OR-7500FD Series 1. How to use Digital Signage Maker a. Select Source Video File Files with extensions such as JPG, BMP, JPEG are not supported. Please refer to above list for right file formats. b. Select Output Device Existing Logical drive or Removable device is displayed as Drive Name. -
Page 77: Import Digital Signage File Into Dvr
User’s Manual OR-7500FD Series F. Import Digital Signage File into DVR Create a folder by name of ‘advertise’ and same the files in that folder in USB flash memory. Files must be saved in the folder and the folder name should be ‘advertise’. DVR will not recognize any other folder names. -
Page 78: Appendix D. Nemon Network Archive Instructions
User’s Manual OR-7500FD Series Appendix D. NEMON Network Archive Instructions 1. Outline NEMON Network Archiver is a Remote Archiving Program to keep recorded data from DVRs on remote sites via Network. 2. Feature The S/W can be used without any additional upgrade of the DVRs. -
Page 79: How To Use Network Archiver
User’s Manual OR-7500FD Series 3. How to use Network Archiver Start Network Archiver(Archiving) by using Schedule Wizard(New Schedule). Step 1) Entering Archiving Site address and following information for a site registration and log-in. Name : Enter the Site name. Address : Enter the Site address for Remote Archiving. -
Page 80: Step 2) Selecting A Starting Point Of Data For Remote Archiving
User’s Manual OR-7500FD Series Step 2) Selecting a starting point of data for Remote Archiving. First : Archiving from the very beginning of recorded data on DVR. Last : Archiving from the latest recorded data on DVR. Specific : Archiving from designated point by user. If data doesn’t exist on the designated point, archiving will start from the latest data right after the designated point. -
Page 81: Step 3) Setting Performing Schedule For Archiving
User’s Manual OR-7500FD Series Step 3) Setting performing schedule for Archiving. Auto Connection Scheduler : Set a time schedule for Archiving. Select a time for Start/Stop point, the system will automatically perform Archiving as the schedule set. If Archiving is failed due to any causes, it will continuously attempt to re-connect the sites. -
Page 82: Step 4) Creating Storage Group. (Refer To 4-D For The Detail)
User’s Manual OR-7500FD Series Step 4) Creating Storage Group. (refer to 4-D for the detail) Storage Group File : Set name of new Storage Group File. The default directory is designated to “My Documents NEMON Network Archiver Storages\<Site Name>\<Site Name>.strgx”. -
Page 83: Set Up
User’s Manual OR-7500FD Series 4. Set Up A. Main Screen Each schedule information is displayed on the main screen in real time. (Overall information of Site and Log-in / Starting point of ‘Archiving / Storage Group is considered and called ‘Schedule’. Each list is considered as one ‘Schedule’.) -
Page 84: Tool Bar
User’s Manual OR-7500FD Series If clicking right button of mouse on each list, it displays contextual menu for the Schedule operations. Start : Start selected Schedule. Stop : Stop selected Schedule. Delete : Delete selected Schedule. The Schedule can be deleted only when the Archiving is stopped. -
Page 85: Detail Information
User’s Manual OR-7500FD Series C. Detail Information a. Site Name / Address / Playback Port / Username / Password : Information on registered Site and Log-in. (refer to 3-Step1 for the detail) Status : It shows current Archiving status and directly related with Icon on Archiving status of main screen. - Page 86 User’s Manual OR-7500FD Series b. Archiving Schedule Auto Connection Scheduler : Set time schedule for Archiving. Select time for Start/Stop points. Archiving will automatically be performed as the time set. If Archiving is failed due to any causes, it will continuously attempt to re-connect the sites. If Always is selected, Archiving will continue until user stops the operation.
-
Page 87: Storage Manager
User’s Manual OR-7500FD Series D. Storage Manager Manage Storage Group each Archiving schedule. Filename : Name of Storage File. It is possible to check full path where the file is being stored by tool tip when mouse cursor is placed on the Filename. -
Page 88: Log
User’s Manual OR-7500FD Series E. Log Check the Log status of each Schedule. F. System Tray The program icon (System Tray) is located as shown below. Network Archiver provides System Tray. Find the System Tray in order to shut down Network Archivier safely and completely. -
Page 89: Reference
User’s Manual OR-7500FD Series 5. Reference a. Storage Playback to utilize ORION CMS Each Storage File(.strg) and Storage Group File(.strgx) can be played on ORION CMS. Playback all Storage Files linked and belong to the Storage Group at once. b. Restrictions 1. -
Page 90: Compliance Notice Of Fcc
User’s Manual OR-7500FD Series COMPLIANCE NOTICE OF FCC: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.
