  • Page 1 H.264(4CH/BNC) Network Combo DVR...
  • Page 2 4Ch H.264 hardware codec - Network DVR Installation & Safeguards INSTALLATION & SAFEGUARDS INSTALLATION & SAFEGUARDS INSTALLATION & SAFEGUARDS INSTALLATION & SAFEGUARDS All the safety and operating instructions should be read before the unit is operated. Environment Condition for Installation Environment Condition for Installation Environment Condition for Installation Environment Condition for Installation...

  • Page 3: Table Of Contents

    4Ch H.264 hardware codec - Network DVR Contents Contents CHAP. 1 Features & Package Contents ---------------------------------------------------------------- 1-1. Features ---------------------------------------------------------------- 1-2. Package Contents ---------------------------------------------------------------- CHAP. 2 Function of Each Parts ---------------------------------------------------------------- 2-1. Front ---------------------------------------------------------------- 2-2. Rear ---------------------------------------------------------------- 2-3. Remote Control ---------------------------------------------------------------- CHAP.
  • Page 4 4Ch H.264 hardware codec - Network DVR Contents 5-3. Record ---------------------------------------------------------------- Record Setup ---------------------------------------------------------------- Schedule Setup ---------------------------------------------------------------- 5-4. Configuration ---------------------------------------------------------------- HDD Management ---------------------------------------------------------------- Time/Date Setup ---------------------------------------------------------------- Camera Setup ---------------------------------------------------------------- Motion Setup ---------------------------------------------------------------- Interval Setup ---------------------------------------------------------------- Alarm Setup ---------------------------------------------------------------- Password Setup ---------------------------------------------------------------- Buzzer Setup ----------------------------------------------------------------...

  • Page 5: Chap. 1 Features & Package Contents

    4Ch H.264 hardware codec - Network DVR CHAP 1. Features & Package Contents CHAP 1. CHAP 1. Features & Package Contents CHAP 1. CHAP 1. Features & Package Contents Features & Package Contents Features & Package Contents 1 1 1 1 - - - - 1. Features 1.

  • Page 6: Package Contents

    4Ch H.264 hardware codec - Network DVR CHAP 1. Features & Package Contents 1-2. Package Contents 2. Remote Controller 3. Power Cable 4. Power Adapter 1. Built In DVR Main Unit 5. User’s Manual 6. Software CD 7. Battery for remote controller 10.

  • Page 7: Front

    4Ch H.264 hardware codec - Network DVR CHAP. 2 Function of Each Button CHAP. 2 Function of Each Button CHAP. 2 Function of Each Button CHAP. 2 Function of Each Button CHAP. 2 Function of Each Button 2-1 FRONT ① ① ① ① ②...

  • Page 8: Rear

    4Ch H.264 hardware codec - Network DVR CHAP. 2 Function of Each Button 2-2. REAR Name Function ① Audio input 1ch audio input Audio output 1ch audio output ② Connection with PTZ camera or other external device using RS 485 RS 485 Relay out terminal Relay output...

  • Page 9: Remote Control

    4Ch H.264 hardware codec - Network DVR CHAP. 2 Function of Each Button 2-3. REMOTE CONTROL Function Related to Playback menu. (It works only during playback) 1)Playback speeds :Lower, Faster 2)Select value : Plus, Minus Move a cursor. (Generally, to operate every function, move the cursor by pressing arrow buttons and press ‘Enter’) OSD on/off...

  • Page 10: Chap. 3 Installation

    4Ch H.264 hardware codec - Network DVR CHAP. 3 Installation 3-1. Installation 1) Camera, Mouse and Power Connect camera to the camera input on rear panel of DVR marked CAMERA IN. 2) Other External Device RS-485 : Controls external device like PTZ camera. (Pin No.1 &...

  • Page 11: Chap. 4 Operation

    4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 4-1. System Log-In GENERAL USE OF MOUSE Mouse buttons Functions Mouse Wheel Increases or decreases setup value on the Menu mode Right Decreases setup value on the Menu mode Increases setup value on the Menu mode Left Execute all of the functions (clicking icons) * Please use a mouse pad for proper operation of the mouse.
  • Page 12 4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 1) HDD Clear 1) HDD Clear You can see HDD Model name, serial number, number of blocks and size of HDD. In order to clear HDD, click ‘CLEAR’ at the bottom as shown below. (1) Please refer to 4-1.
  • Page 13 4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 2) Factory Default Factory default setting initializes DVR system. (1) Please refer to 4-1. System Log in again. (2) Click ‘FACTORY DEFAULT’. Then, click ‘ENTER’. DVR LOG DVR LOG DVR LOG DVR LOG- - - - IN IN IN IN MAIN MENU MAIN MENU...

  • Page 14: Display Configuration

    4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 4-3. Display Configuration...

  • Page 15: Live View Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 4-4. Live View Setup 1) Full / Multiple View CHAP. 4 Move the cursor onto [4 - split icon] in the icon bar and click it to view 4 channel division. To enlarge each channel, click 1,2,3,4 Icon.

  • Page 16: Record

    4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 4-5. Record It basically records as a setting made in Schedule Record mode except for emergency record mode. - Emergency Record Once you click this icon , it keeps recording continuously regardless of schedule setting. - Schedule Record (Continuous, Motion, Alarm and Motion/Alarm) Go to MAIN MENU->...

  • Page 17: Search

    4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 4-7. Search There are three search methods controlled by a mouse wheel button, left and right button of a mouse. When you click [SEARCH] icon , then you see a window shown as below. Select a target data by using the mouse.

  • Page 18: Ptz Camera Operation

    4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation 4-8. PAN/TILT/ZOOM Camera Operation Click the [PTZ] the icon in the icon bar, then you can see ‘arrow’ keys & ‘+/-’ key shown below. Click these arrow keys to move a PTZ camera to each direction. By using ‘+/-’ key, you can control ZOOM IN/OUT function.
  • Page 19 4Ch H.264 hardware codec - Network DVR CHAP. 4 Operation (4) To set start time of back-up and back-up data size in MEDIA sub-menu, use the mouse (left/right/wheel button). ※ End time of back-up will be calculated automatically as per start time & date and the back-up data size you set.

  • Page 20: Chap 5. Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup CHAP 5. Setup CHAP 5. Setup CHAP 5. Setup CHAP 5. Setup 5-1. General Operation Click the [MENU] icon and input user password to log in. (1) Please refer to 4-1. System Log in again. Then, click ‘ENTER’.

  • Page 21: Display Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 5-2. Display Setup This is setup menu for display on the screen. If you click ‘DISPLAY SET UP’, then you change setting values for display as shown below. DISPLAY SETUP DISPLAY SETUP DISPLAY SETUP DISPLAY SETUP...

  • Page 22: Screen Display Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 2) Screen Display Setup SCREEN DISPLAY VERTICAL POSITION HORIZONTAL POSITION BOARDER ENABLE BOARDER COLOR GRAY DEFAULT VERTICAL POSITION : -5 ~ 5 HORIZONTAL POSITION : -31 ~ 31 BORDER ENABLE : ON/OFF BORDER COLOR : COLOR SELECT 3) OSD Setup OSD SETUP...

  • Page 23: Record Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 5-3. Record This is the most important configuration of the DVR. When you select ‘RECORD’ in the main menu, you can see the window as shown on the right. RECORD RECORD RECORD RECORD...

  • Page 24: Schedule Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 2) Schedule Setup DVR system records in Schedule Recording mode. In Schedule Recording mode, you can choose four different types of recording modes and schedule by 2 hour interval from Sunday to Saturday. Default recording mode is continuous recording.

  • Page 25: Configuration

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 5-4. Configuration When you click ‘CONFIGURATION’ on the main CONFIGURATION CONFIGURATION CONFIGURATION CONFIGURATION menu, you can go to ‘CONFIGURATION’ menu as shown on the right. HDD MANAGEMENT CAMERA SETUP MOTION SETUP ALARM SETUP INTERVAL SETUP TIME/DATE SETUP...
  • Page 26 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 2) Time/Date Setup In this setup, you can select date/time of DVR TIME/DATE SETUP TIME/DATE SETUP TIME/DATE SETUP TIME/DATE SETUP system and display format. You can adjust values by using the mouse wheel or DATE JUN/15/2007 left/right button of the mouse.
  • Page 27 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 4) Motion Setup MOTION SETUP MOTION SETUP MOTION SETUP MOTION SETUP CHANNEL SENSITIVITY DURATION SIZE ALL-DEFAULT DEFAULT MOTION SETUP: You can change values by mouse wheel and left/right button of the mouse. - SENSITIVITY: Adjust sensitivity of a movement.
  • Page 28 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 5) Interval Setup See the switching time interval for SEQ or PIP function. INTERVAL SETUP INTERVAL SETUP INTERVAL SETUP INTERVAL SETUP (1 sec. ~99 sec. ） SEQUENCE SCREEN :Set the sequencing switch time SEQUENCE SCREEN 01 SEC interval in live full screen.

  • Page 29: External Device Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 8) Buzzer Setup BUZZER SETUP BUZZER SETUP BUZZER SETUP BUZZER SETUP KEY TONE VIDEO LOSS You can select Buzzer OFF/ON on this setup menu. ALARM ACTIVE MOTION DETECT DEFAULT 5-5. External Device Setup Please refer to 4-1.
  • Page 30 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup (1) IP Setup : IP SETUP IP SETUP IP SETUP IP SETUP MAC ADDRESS 00-0A-A2-00-FD-63 Shows the network information assigned to the DHCP MODE MANUAL DVR unit. If the DHCP setup status is IP DETECT AUTOMATIC, you can set the IP port only.
  • Page 31 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup B. Dynamic IP B. Dynamic IP B. Dynamic IP B. Dynamic IP Internet Internet Internet Internet Cable Modem (Dynamic IP) (Server) This contrasts with a Dynamic IP address, wherein an IP address is assigned to a computer, usually by a remote server which is acting as a Dynamic Host Configuration Protocol server.
  • Page 32 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup C. Dynamic IP of C. Dynamic IP of C. Dynamic IP of C. Dynamic IP of PPPoE PPPoE PPPoE PPPoE (DSL) (DSL) (DSL) (DSL) Router or DSL Modem Gateway (Dynamic IP) (Server) (IP Share) DVR doesn’t support DSL (PPPoE), user will need to set NETWORK with IP SHARE in order to...
  • Page 33 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup If you are using a router, please setting up DMZ and Port Forwarding instructions below. [How to set DMZ] [How to set DMZ] [How to set DMZ] [How to set DMZ] - - - - Set DMZ as per router manual, if you want to connect a DVR by u Set DMZ as per router manual, if you want to connect a DVR by u Set DMZ as per router manual, if you want to connect a DVR by using one internet line.
  • Page 34 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup D. Direct connect to DVR D. Direct connect to DVR D. Direct connect to DVR D. Direct connect to DVR (Server) When you try to connect to DVR directly, you must use DIRECT CABLE. a.
  • Page 35 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 3. Right-button click [Local Area Connection] 4. Click [General] – [Internet Protocol (TCP/IP)] ‘Properties’...

  • Page 36: Mouse Setup

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 5. IP Address Setting IP Address : AAA.BBB.CCC.DDD AAA.BBB.CCC is identical with DVR’s setting DDD with DVR’s setting is not same Subnet mask must be 255.255.255.0 Default gateway is AAA.BBB.CCC.1 AAA.BBB.CCC is identical with HUB’s Address DNS Server is different in the country and ISP Supplier.
  • Page 37 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup c. PC c. PC c. PC c. PC’ ’ ’ ’ s reaffirmation s reaffirmation s reaffirmation s reaffirmation 1. Click [start] – [Run..] 2. Input ‘cmd’ and click [OK]...
  • Page 38 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 3. Click [start] – [Run..] and type command ‘ping 192.168.1.160(DVR’s address)’ Case 1. PC – HUB or HUB – DVR is not connected Please verify 1. PC’s TCP/IP Setting, 2. DVR’s setting again Case 2.
  • Page 39 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup DDNS SETUP DDNS SETUP DDNS SETUP DDNS SETUP (2) DDNS Setup : DDNS ENABLE Please refer to CH.8 DDNS Setup DNS SERVER 192.168.063.001 INTERVAL D-00 H-00 N-20 for more information. REGISTER DDNS STATUS Refer to CH7-2 DDNS set up in DVR on page 53.
  • Page 40 4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 2) Pan/Tilt Setup PAN/TILT SETUP PAN/TILT SETUP PAN/TILT SETUP PAN/TILT SETUP COMMAND SETUP COMMAND SETUP COMMAND SETUP COMMAND SETUP CHANNEL COMMAND SETUP MODEL PELCO-D  PTZ Camera setup SPEED SETUP PTZ ID ...

  • Page 41: Firmware Upgrade

    4Ch H.264 hardware codec - Network DVR CHAP. 5 Setup 5-6. Firmware Upgrade When it comes to firmware upgrade, you may ask your local dealer. FIRMWARE UPGRADE FIRMWARE UPGRADE FIRMWARE UPGRADE FIRMWARE UPGRADE CURRENT VER 10049 / V 2.00 UPGRADE VER FW1 Version FW2 Version CHECH USB...

  • Page 42: Irs Setup

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS CHAP 6. IRS (Integrated Remote Station) CHAP 6. IRS (Integrated Remote Station) CHAP 6. IRS (Integrated Remote Station) CHAP 6. IRS (Integrated Remote Station) MAIN INTERFACE MAIN INTERFACE MAIN INTERFACE MAIN INTERFACE Exit IRS SETUP...
  • Page 43 4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 6 6 6 6 - - - - 1. IRS Setup 1. IRS Setup 1. IRS Setup 1. IRS Setup MANUAL MANUAL Select “Manual” to input IP address and port number manually. MANUAL MANUAL DDNS...

  • Page 44: Dvr Setup

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 6 6 6 6 - - - - 2. DVR Setup 2. DVR Setup 2. DVR Setup 2. DVR Setup You can change some settings of DVR listed below over a network. (Alarm, Buzzer, Interval, Record Configuration, Record Schedule, Audio) MANUAL MANUAL...

  • Page 45: Viewer

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 6 6 6 6 - - - - 3. Viewer 3. Viewer 3. Viewer 3. Viewer DVR connection setup DVR connection setup : Input network information to connect. DVR connection setup DVR connection setup (IP / PORT / ID / PW) System information...

  • Page 46: Search

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 6 6 6 6 - - - - 4. 4. 4. 4. Search Search Search Search DVR connection setup : Input network information to connect. DVR connection setup DVR connection setup DVR connection setup (IP / PORT / ID / PW) Screen display...

  • Page 47: Backup

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 6 6 6 6 - - - - 5. Backup 5. Backup 5. Backup 5. Backup 1) To execute BACKUP, input IP Address & Port and click ‘Connect Test’ button. 2) After Connect Test is done, you can see ‘Success Connect Test!’...
  • Page 48 4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 3) Now you set ‘Start Backup Time’, ‘End Backup Time’, ‘Save File Path’, ‘File Size’ and click ‘Apply’. 4) After finishing time setting, click ‘Start Backup’ to start backup. Then, you can see the backup file on the path that you chose.

  • Page 49: Player

    4Ch H.264 hardware codec - Network DVR CHAP 6. IRS 6 6 6 6 - - - - 6. Player 6. Player 6. Player 6. Player Time display Time display : Displays current time. Time display Time display Recorded data display Recorded data display : Displays start time &...
  • Page 50 4Ch H.264 hardware codec - Network DVR CHAP 6. IRS Image EDIT Click “EDIT” to go to image edit mode. EDIT TOOL : EDIT TOOL : User can adjust color tone of copied images using this buttons. EDIT TOOL : EDIT TOOL : - Contrast : make bright part of image brighter and dart part of image darker...
  • Page 51 4Ch H.264 hardware codec - Network DVR CHAP 6. IRS AVI SAVE Click “AVI SAVE” to go to AVI saving mode. OPTION : OPTION : OPTION : OPTION : Used to save data in AVI file format. - CHANNEL : Selects channel - FRAMERATE : Decides frames per second of data to be saved.

  • Page 52: Ddns Web-Server

    4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server CHAP 7. DDNS Web CHAP 7. DDNS Web- - - - server server CHAP 7. DDNS Web CHAP 7. DDNS Web server server 7 7 7 7 - - - - 1. Registering DVR for DDNS 1.
  • Page 53 4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server 3) Please click confirm after inputting DVR information (DVR Name and MAC Address only). Then, Click “Confirm” button. 4) Now, DVR is listed on DDNS web server without IP and Port number. ※...

  • Page 54: Ddns Set Up In Dvr

    4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server 7 7 7 7 - - - - 2. DDNS set up in DVR 2. DDNS set up in DVR 2. DDNS set up in DVR 2. DDNS set up in DVR * The following setting is a sample for a cable modem connected to DVR directly.
  • Page 55 4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server 4) Set DDNS ON/OFF ‘ON’. IP address which is assigned from DHCP server is automatically input on DNS SERVER. DDNS SETUP DDNS SETUP DDNS SETUP DDNS SETUP DDNS ENABLE DNS SERVER 168.126.063.001 INTERVAL...
  • Page 56 4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server 6) Go to your computer again after you see “SUCCESS TO REGISTER DVR INFO” and then Click ‘refresh’ button. Then, DDNS server automatically catches your DVR’s IP address and Port number.
  • Page 57 4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server ③ ③ ③ ③ ④ ④ ④ ④ ⑤ ⑤ ⑤ ⑤ Click Click Click Click ⑥ ⑥ ⑥ ⑥ www.h264ip.com Leave this check box empty ⑦ ⑦ ⑦ ⑦...

  • Page 58: Web Program

    4Ch H.264 hardware codec - Network DVR CHAP 7. DDNS Web-server 7 7 7 7 - - - - 3. Web program 3. Web program 3. Web program 3. Web program Some functions of IRS (Integrated Remote Station) such as Viewer, Search, Backup and Player are also available on the web.

  • Page 59: Chap. 8 Frequently Asked Questions

    4Ch H.264 hardware codec - Network DVR CHAP 8. FAQ CHAP 8. Frequently Asked Questions CHAP 8. Frequently Asked Questions CHAP 8. Frequently Asked Questions CHAP 8. Frequently Asked Questions F A Q How do I determine my PC’s TCP/IP settings? For Windows 98/ME Users 1.
  • Page 60 4Ch H.264 hardware codec - Network DVR CHAP 8. FAQ How do I How do I “ PING How do I How do I PING PING” an IP address ? PING an IP address ? an IP address ? an IP address ? 1.
  • Page 61 4Ch H.264 hardware codec - Network DVR CHAP 8. FAQ How do I choose a private IP address : Below lists the ranges for private addresses. Private Class A address space : 10.0.0.0 – 10.255.255.255 Private Class B address space : 172.16.0.0 – 172.31.255.255 Private Class C address space : 192.168.0.0 –...

  • Page 62: Chap. 9 Specifications

    4Ch H.264 hardware codec - Network DVR CHAP 9. Specifications CHAP 9. Specifications • H.264 Hardware Codec • Real time live display in all channels • Triplex ( Playback / Recording / Ethernet ) • Web monitoring • Easy control by Remote Controller and Mouse •...
  • Page 63 4Ch H.264 hardware codec - Network DVR MEMO MEMO :...
  • Page 64 4Ch H.264 hardware codec - Network DVR MEMO MEMO :...
  • Page 65 4Ch H.264 hardware codec - Network DVR MEMO MEMO :...
  • Page 66 4Ch H.264 hardware codec - Network DVR L39ME0150 Rev.0...
