Summary of Contents for Galaxy Audio G-440
- Page 1 G-SERIES USER'S MANUAL G-SERIES AMPLIFIERS G-440, G-850, G-1200 G-440 G-850 G-1200...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions before using the product. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8. -
Page 4: Table Of Contents
The G-SERIES circuitry and selected components offer excellent sound quality and high fidelity audio reproduction. The compact design improves the price/performance ratio, while the rugged metal chassis guarantees maximum sturdiness. The G-SERIES amplifiers are available in three models. G-440 G-440 2 x 210 watts @ 4 ohms G-850... -
Page 5: Instructions And Installation
INSTRUCTIONS AND INSTALLATION ATTENTION !!! The G-SERIES amplifiers generate high voltage on output. To avoid the risk of electric shocks. DO NOT TOUCH any bare wires when the unit is switched on. This manual contains important information for correct safe use, read it carefully before using your amplifier. - Page 6 In the event of breakdown All user-adjustable parts are external and easily accessible. Never open the amplifier: you could run the risk of serious electric shocks. In the event of breakdown, contact Galaxy Audio. 1 (316) 263-2852 or at service@galaxyaudio.com...
-
Page 7: Sound Reinforcement Basics
Polarity will not affect the Z, but can affect the quality and volume of the sound. If you are having problems with any of these applications use Galaxy Audio's CRICKET Polarity and Continuity Test Set to check the polarity of your cables. -
Page 8: Sound Reinforcement Basics
SOUND REINFORCEMENT BASICS EXAMPLE 2 USING GALAXY HOT SPOTS: As long as all of the speakers have the same impedance rating, the equivalent impedance of the system is the rated impedance of one speaker divided by the number of equivalent speakers. -
Page 9: Front Panel
FRONT PANEL G-440 POWER ON/OFF BRIDGE LED for indicating the work mode of the amplifier. This LED will light when the bridge switch at rear panel on the bridge position. INPUT ATTENUATORS Input gain potentiometers, with 40 detented steps, attenuate the level of the external signal sent to the respective channels of the amplifier. -
Page 10: Rear Panel
REAR PANEL INPUTS Each channel has (1) balanced XLRF and (1) balanced TRS ¼" input connector. These can receive balanced or unbalanced line level signals. LINK The XLRF and TRS ¼" channel connectors are wired in parallel to facilitate daisy chaining of channels. -
Page 11: Connection Examples
CONNECTION EXAMPLES... - Page 12 CONNECTION EXAMPLES...
-
Page 13: Connection Cables
CONNECTION CABLES The following diagrams show the wiring of the connectors that can be used with G-Series amplifiers. To connect the mixer outputs to the amplifiers inputs, make certain to always use balanced signal cables: the use of unbalanced cables could cause annoying hum and noise. To connect the amplifier to the loudspeaker enclosures always use stranded twisted pair cables. -
Page 14: Specifications
SPECIFICATIONS POWER SPECIFICATIONS G-440 G-850 G-1200 8 ohm 2 x 145 2 x 240 2 x 400 Rated Power Output 4 ohm 2 x 210 2 x 340 2 x 660 1KHz, THD < 0.5% Bridge 8 ohm 1200 ELECTRICAL... - Page 16 G-SERIES AMPLIFIERS USER'S MANUAL ONE YEAR LIMITED WARRANTY WARRANTY Information can be viewed online at http://www.galaxyaudio.com/warranty.php 1-800-369-7768 www.galaxyaudio.com Specifications in this manual are subject to change without notice. © Copyright Galaxy Audio 2012 Printed in China V10092012...
