EDGE-180M USB GSM Modem User Manual Includes both SMS and Voice call alert setup instructions Help Version updated till firmware 404i Copyright © 2012, AKCess Pro Co., Ltd.. - Page 2 Audio Cable for Voice Call Alerts (AKCP) When setting up Voice Call Alerts on the base unit you will need to connect the custom AKCP Audio cable from this jack on the modem to the base unit. This cable is shipped with the modem.
- Page 3 You can download the latest firmware from our web site after setting up your support page. If you’re not sure how to do this please contact support@akcp.com. You will first physically connect the USB modem to the base units USB port located on the back of the unit using the USB extension cable provided with the modem.
- Page 4 Next connect the opposite end of the USB cable (female end) to the male USB connector on the EDGE-180M modem as shown above. Next you will connect the Audio In and Audio Out from the Audio Cable included with the USB modem as shown above.
- Page 5 EDGE 180M USB Modem Manual IMPORTANT NOTE: There are two types of audio cables for the EDGE-180M modem. The “mono” type as shown above and the “stereo” type as shown below. You need to use the “mono” type audio cable if your base unit is a securityProbe 5E, 5E- X20 or 5E-X60 (above).
- Page 6 EDGE 180M USB Modem Manual NOTE: It is always a good idea to test the SIM card in mobile phone or on your PC to ensure the SIM is working properly before installing the modem on your base unit. Setting up the EDGE-180 GSM Modem in the base units web interface SMS Alerts –...
- Page 7 EDGE 180M USB Modem Manual In the next screen you will name your action and add your mobile phone number, or your list of mobile phone numbers that your SMS alert will be sent to. You can add multiple numbers in the call list. There is no limit to the amount of numbers you can add, however the more numbers you had the longer it will take to finish sending the alert out as the SMS action will call to the first number and after finishing will call to the second number and so on.
- Page 8 USB port. You can leave the port speed as Auto and disregard the Delay Times settings, then choose the EDGE-180M from the Initialization String drop down list and click “Next” as shown above.
- Page 9 EDGE 180M USB Modem Manual On the next screen you can setup the Maximum Times to Resend which is 5. You can also set the Resend Intervals and the Resend on Server Timeout in case there was a problem connecting to the GSM service. Clicking on the “Finish” button will save your new SMS action and complete the wizard.
- Page 10 EDGE 180M USB Modem Manual In the next screen you will select the Telephone Call action from the Select an Action Type drop down list as shown above, then click the Next button. In the next screen you will name your action and add your phone number, or your list of phone numbers that your Voice Call alert will be sent to.
- Page 11 EDGE 180M USB Modem Manual In the next screen shown above there are multiple settings for your voice call. What you can do is adjust each of these to your liking, then save the alert and use the “Test Action” feature with your audio cable connection disconnected from the unit so this will play out the speaker on the unit so you can listen and adjust the voice call.
- Page 12 EDGE 180M USB Modem Manual You can also choose to play a custom WAV file when the phone call is received by chooseing the “WAV file in the Sound in the call option as shown above. After choosing the WAV file option you will then see the screen shown above where you can add your custom WAV sound by clicking on the “Add Your Own Sound”...
- Page 13 EDGE 180M USB Modem Manual After clicking on the Next button the next screen shown above will allow you to setup how the phone call will be acknowledged. If you did choose the WAV file option then you would need to turn On the Recipient Acknowledgement option and select whether to have the WAV file played after the acknowledgment or have it played when the connection is established.
- Page 14 In the next screen of the wizard you will select the USB modem from the drop down list (noting the (Not Connected) is hidden. Then choose the EDGE-180M modem from the Voice Modem Chipset drop down list and clicking the “Next” button to continue as shown in the screen shot above.
- Page 15 “Link Sensor to Action” Wizard located in the Notifications page. Please contact support@akcp.com if you have any further technical questions or problems setting up your modem or your alerts.
