- Page 1 PATRON E9 ELECTRIC FAN HEATER (12/00) IMPORTANT READ AND UNDERSTAND THIS MANUAL BEFORE ASSEMBLING, STARTING OR SERVICING THE HEATER. IMPROPER USE OF HEATER CAN CAUSE SERIOUS INJURY. KEEP THIS MANUAL FOR FUTURE REFERENCE. FOR PROFESSIONAL USE ONLY Patron E9 - 12/00...
- Page 2 15. Avoid use of an extension cord because it may overheat and cause a risk of fire. How- ever, if you have to use an extension cord, the cord shall be a three (3) wire grounded cord (check minimum size from specifications) Patron E9 - 12/00...
-
Page 3: Limited Warranty
This warranty does not oblige Patron Products to bear the cost of labour in replacing any assembly, unit or com- ponent or part thereof, nor does the company assume any liability for secondary charges, expenses of removal or installing, freight or damages. -
Page 4: Operation
4. Turn the toggle switch into position “off” 5. Disconnect the power supply plug NOTE! THE HEATER IS EQUIPPED WITH AN OVERHEAT LIMIT SWITCH WHICH MAY CAUSE THE HEATER TO STOP. CHECK AND REMOVE THE CAUSE FOR OVERHEATING BEFORE RE- STARTING. Patron E9 - 12/00... -
Page 5: Maintenance
Extension cord min. 3×8 AWG Ambient thermostat Temp. range 32 ... 100 °F (0 ... 40 °C) Length inches 23.0 (585 mm) Width inches 11.8 (300 mm) Height inches 18.3 (465 mm) Weight 39.9 (18.1 kg) Patron E9 - 12/00... -
Page 6: Exploded View
EXPLODED VIEW Pos. Patron E9 - Code # bottom plate plaque de fond 4008001 front panel panneau avant 4008002 rear panel panneau arriere 4008003 outer mantle carcasse 4008004 inner mantle cheminee interieure 4008005 handle poignee 80100 heating element (3 pcs) -
Page 7: Wiring Diagram
WIRING DIAGRAM Pos. Patron E9 - Code # contactor contacteurs 22570 fan motor motor du ventilateur 14201 R1...3 heating element element 42800 toggle switch interrupteur 26900 room thermostat thermostat ambiant 20210 overheat limit switch disjoncteur de surchauffe 21200 terminal block... - Page 8 PATRON PRODUCTS INC. USA: 60 Clyde Avenue Suite # 4, Buffalo, NY 14215 Canada: 12-110 Ironside Crescent, Scarborough, Ontario M1X 1M2 Patron E9 - 12/00...
