Velleman MONCOLHA Operation Manual

4" TFT LC MONITOR
MONCOLHA
OPERATION MANUAL
I.

Detailed Description

II.

Specifications

III. Descriptions Of The Functions Of The Front Rear-Panel
IV. Set Function Descriptions Of Pressing Keys
V. Drawing Of Wiring Applications : Basic Wiring
I. Detailed Description
This model completely uses digitised push buttons to adjust the colour,
contrast, tint, voices, brightness of 4" LCD monitor module and even setting
values, which will not be changed because of power failure. However, if an
original setting value is required, it can be recovered by pressing the "power"
& "mode" keys at the same time. Then release them both, pressing the
"mode" key for one second longer.
II. Specifications
LCD panel
Display resolution (dot)
Number of pixels
Active (mm)
Screen size (inch)
Dot pitch
System
Input signal
Back light
Power source
Operation temperature
Storage temperature
Power consumption
Dimensions
Weight
MONCOLHA
colour
480(W) x 234(W)
112320 dots
82.0(W) x 61.8(H)
4" (diagonal)
0.171(W) x 0.264(H)
PAL / NTSC
1Vp-p (Positive) 75Ω
CCFT back light
DC 12V ± 10%
-5°C ∼ +50°C
-25°C ∼ +70°C
8W max.
143(W) x 103(H) x 45(D)mm
500g
