Summary of Contents for Zenoah G5000
- Page 1 G5000 115 32 01-10 (001) OWNER’S MANUAL CHAIN SAW G5000 Original Language GB-1...
- Page 2 G5000 EXPLANATION OF SYMBOLS AND SAFETY WARNINGS Read operator's instruction Wear head, eye and ear book before operating this protection. machine. Use the chain saw Warning! Danger of with two hands. kickback. Read, understand and Never touch hot surface. follow all warnings.
-
Page 3: Table Of Contents
Directive 2006/42/EC on machinery and to Directive 2004/108/EC on electromagnetic compatibility and to the regulations governing transposition internal control production. Manufacturer Husqvarna Zenoah Co., Ltd. 1-9 Minamidai, Kawagoe, Saitama, Japan DECLARES THAT THE DESIGN OF THE MACHINE DESCRIBED BELOW. Description... -
Page 4: For Safe Operation
G5000 1. For safe operation WARNING This chainsaw has been especially designed for tree maintenance and should therefore only be used by trained operators when working on trees. 1. Never operate a chain saw when you are fatigued, ill, or upset, or under the influence of medication that may 10. - Page 5 G5000 20. Operate the chain saw only in well handle, and the left hand on the front ventilated areas. Never start or run handle, when the engine is running. the engine inside a closed room or Use a firm grip with thumbs and fin-...
-
Page 6: Explanation Of Symbols On The Machine
G5000 2. Explanation of Symbols on the Machine WARNING • For safe operation and maintenance, symbols are carved in relief on the machine. According to these indications, please be careful not to make any mistake. The port to refuel “MIX GASOLINE”... -
Page 7: Installing Guide Bar And Saw Chain
G5000 3. Installing Guide Bar and Saw Chain A standard saw unit package contains the items as illustrated. Plug wrench Power unit (Hexagon socket (S13/S19) + Slotted driver) Screwdriver for carburetor adjustment (Slotted driver) Bar protector Guide bar Spike and mountaing screws... -
Page 8: Fuel And Chain Oil
2-cycle gasoline engine use. 2. Move at least 10 feet (3 meters) away from the If Zenoah oil is not available, use an anti-oxidant added fueling point before starting the engine. quality oil expressly labeled for air-cooled 2-cycle 3. -
Page 9: Operating The Engine
G5000 5. Operating the Engine WARNING WARNING • Keep clear of the saw chain as it will start rotating • It is very dangerous to run a chainsaw that mounts upon starting of engine. broken parts or lacks any parts. - Page 10 NOTE When using the unit at times when it is snowing. Zenoah recommends that you also use a snow protector effec- tive in preventing the air filter from freezing (e.g., the separately-sold Z2881-98610 snow protector).
-
Page 11: Sawing
G5000 6. Sawing 2 seconds and pushing the front WARNING hand guard forward. The chain • Before proceeding to your job, should stop immediately with the en- read the section “For Safe Op- gine at full speed. If the chain is slow eration”. -
Page 12: Maintenance
G5000 A log lying on the ground First check to which side the limb is bent. Then make the initial cut from the bent side and finish by sawing from the opposite side. WARNING • Be alert to the springing back of a cut limb. -
Page 13: Maintenance Of Saw Chain And Guide Bar
G5000 2. Fuel filter 4. Spark plug (a) Using a wire hook, take out the filter from the filler port. 0.6 ~ 0.7 mm BPMR7A Fuel filter Clean the electrodes with a wire brush and reset the gap to 0.65 mm as necessary. -
Page 14: Troubleshooting Guide
Filing angle No gap WARNING Chain tilts Side plate angle • This saw is equipped with one of the following low kickback bar/chain combinations: Zenoah Part Number Top plate cutting angle Bar Size Guide Bar Saw Chain 3644-52113 848CC21B60 ■ Guide Bar... -
Page 15: Specifications
UNITS WHICH HAVE BEEN DAMAGED BY NEGLI- THE PURCHASER SHALL BEAR COSTS OF TRANS- GENCE OF INSTRUCTION LISTED IN THE OWNER/ PORTING THE UNIT TO AND FROM THE ZENOAH OPERATOR MANUAL FOR PROPER USE AND MAIN- DEALER. TENANCE OF THE UNITS ACCIDENT MISHANDLING,...
