Technical Data - Power Craft High-pressure cleaner Operating Instructions Manual

Power supply
Voltage
Type of current
Connected load
Supply fusing (time-lag)
Safety class
Water connection
Supply temperature (max.)
Supply volume (min.)
Supply pressure
Supply hose
- length, min.
- diameter, min.
Performance data
Pressure (max.)
Working Pressure
Flow volume
Cleaning agent suction
Recoil force of handgun at working pressure ........................ 16 N
Sound level,
Guaranteed sound power level, L
Appliance vibrations
Subject to modification

Technical Data

.......................................... 240 V
........................................ 1~50 Hz
........................................... 2,1 kW
............................................ 13 A
................................... 1, IPX 5
............................................ 40 °C
(10 l/min) ........................... 600 l/h
(12 bar) .............................. 1,2 MPa
........................................... 7.5 m
........................................... 1/2 inch
(150 bar) ............................. 15 MPa
(120 bar) ............................. 12 MPa
(450 l/h) .............................. 7,5 l/min
(0,3 l/min) ............................ 20 l/h
L (EN60704-1) ................ 74 dB(A)
PA
(2000/14/EC) ................ 87 dB(A)
WA
(ISO 5349) ....................... 2,14 m/s²
13
