C5/F5-Series EasyConnect
RFID Long Range Reader
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C5 Series Easy Connect and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Motion C5 Series Easy Connect

  • Page 1 C5/F5-Series EasyConnect RFID Long Range Reader User’s Guide...
  • Page 2 The information in this document is provided “as is” and is subject to change For Mobile/ (MHz) without notice. Motion is not liable for errors or omissions in this document. Q3QUHFRFID Portable Motion Computing, Inc. has made every effort to identify trademarked Equipment properties and owners on this page.
  • Page 3: Table Of Contents

    Using Motion RFID Wedge ........
  • Page 4: Chapter 1 Getting Started

    Getting Started TheC5/F5-Series EasyConnect RFID Long Range Reader is designed specifically for Motion Computing’s C5/F5-Series Tablet PCs. This solution delivers the mobility and productivity of a handheld RFID Reader device with the flexibility and functionality of a powerful PC. With the 3G connectivity of our C5/F5-series Tablet PCs, the RFID Long Range Reader provides scanning capabilities in even the most remote locations.
  • Page 5: Package Contents

    Package contents 1. C5/F5-Series EasyConnect RFID Long Range Reader 2. One set of rubber feet for the clip-on installation option 3. One set of plastic feet for the semi-permanent installation option 4. Two M2 x 18 Phillips-head screws for semi-permanent installation of feet Tools/supplies needed You’ll need a Phillips-head screwdriver for attaching the screws if you choose the semi- permanent installation option.
  • Page 6: Overview Of The C5/F5-Series Easyconnect Rfid Long Range Reader

    Overview of the C5/F5-Series EasyConnect RFID Long Range Reader The C5/F5- Series EasyConnect RFID Long Range Reader’s docking connector and guide posts attach to the bottom of the C5/F5-Series Tablet PC. RFID Long Range Reader Docking connector Guide posts C5/F5-Series Tablet PC Guide holes RFID Long Range Reader and C5/F5-Series Tablet PC Chapter 1...
  • Page 7: Attaching The C5/F5-Series Easyconnect Rfid Long Range Reader

    Attaching the C5/F5-Series EasyConnect RFID Long Range Reader Before installing the C5/F5-Series EasyConnect RFID Long Range Reader, you’ll need to remove the two feet on the back of the Tablet PC to properly attach the reader. This step is required for either the clip-on or semi-permanent installation option. Remove these feet before you install the feet for the RFID Long Range Reader.
  • Page 8: Semi-Permanent Installation

    4. To remove the RFID Long Range Reader, insert your finger in the slot at the top of the reader, pull back the tab, and slide the reader off the Tablet PC. Semi-permanent installation If you want to install the RFID Long Range Reader so that it stays attached to your Tablet PC for frequent, long-term use, you can opt for semi-permanent installation.
  • Page 9: Chapter 2 Using Your Rfid

    5. After your tablet restarts, you’ll be prompted to choose your Language and Region settings. Note: If you’re using Windows® 8 on your Tablet PC, you’ll either need to tap the Motion RFID Wedge tile on the Windows® 8 Start Screen or switch to the Windows® Desktop to view this prompt and enter your Language and Region settings.
  • Page 10: Using Motion Rfid Wedge

    3. From the Windows® desktop, tap the Motion RFID Wedge icon in the taskbar. 4. Select Display Wedge Settings from the pop-up menu to open the Motion RFID Wedge application and configure your reader options or enable the RFID Long Range Reader.
  • Page 11 The following configuration options are available in Motion RFID Wedge Settings: • Reader(s) Found—Contains a list of the RFID Reader(s) found in your Tablet PC. • Type—RFID tag types you can choose for your scans. You can also opt for auto- detection of RFID tags.
  • Page 12: Reader(S) Found

    This drop-down list will contain any RFID Reader(s) Motion RFID Wedge finds in your Tablet PC. Typically, the Motion RFID Long Range Reader will be the only reader listed in this menu. If more than one RFID Reader is detected, select the Motion RFID Reader from the list.
  • Page 13: Using The C5/F5-Series Easyconnect

    4. Tap the Enable Reader button and position your Tablet PC in front of the RFID tag with the Tablet PC screen facing you as shown in the illustration below. 5. Press the button on the Tablet PC that you selected during installation of the Motion RFID Wedge application to initiate an RFID scan.
  • Page 14: Motion Rfid Wedge Apis

    Motion RFID Wedge APIs You can customize your C5/F5-Series EasyConnect RFID Long Range Reader for specialized communication with your Tablet PC by utilizing APIs that are available for your reader. Go here: https://skyetek.zendesk.com/forums/21812122-API-s to access the APIs. Chapter 2 Using your RFID Long Range Reader...
  • Page 15: Chapter 3 Troubleshooting

    If you don’t find the information you’re looking for in this section, go to Motion Computing Support. Enterprise users should contact their support organization for assistance with resolving application or connectivity issues.
