Schematic; Ignition Switch - Poulan Pro PB30 Operator's Manual

RIDING MOWER

SCHEMATIC

SCH24

IGNITION SWITCH

POSITION CIRCUIT
OFF M+G+A1
RUN/OVERRIDE
RUN
START B + S + A1
S
B
M
G A1
L
A2
BLUE
"MAKE"
B+A1
B+A1 L+A2
MODEL NUMBER PB30 (96025000400)
PRODUCT NUMBER 960 25 00-04
BATTERY
R E D
FUSE
WHITE
CLUTCH / BRAKE
(PEDAL UP)
BLACK
BLACK
REVERSE SWITCH
NOT IN REVERSE
BLACK
IGNITION
BLACK/WHITE
UNIT
FUEL SHUT-OFF
SOLENOID
CHARGING SYSTEM OUTPUT
3 AMP DC @ 3600 RPM
(IF EQUIPPED)
RED
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED CLIPS
WERE REMOVED FOR SERVICING OF
UNIT, THEY SHOULD BE RE-INSTALLED
TO PROPERLY SECURE YOUR WIRING.
29
RED
ATTACHMENT CLUTCH
(CLUTCH OFF)
BLACK
SEAT SWITCH
(NOT OCCUPIED)
GRAY
SHORTING CONNECTOR
SPARK PLUGS
GAP
(2 PLUGS
ON TWIN CYL. ENGINES)
28 VOLTS AC MIN. @ 3600 RPM
(CHARGING SYSTEM DISCONNECTED)
DIODE
STARTER
M
BLACK
GRAY
BLACK
STATOR
REMOVABLE
CONNECTIONS
NON-REMOVABLE
CONNECTIONS
