- Page 1 OPERATOR'S MANUAL MODEL: PB19546LTX LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan-pro.com Do Not Throw Away 03076 WARNING: Read this Man u al and follow all Warnings and Safety Instructions. Fail ure to do so can...
-
Page 2: Safety Rules
Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. WARNING: In order to prevent ac ci - den tal starting when setting up, trans- port ing, ad just ing or making repairs, al ways dis con nect spark plug wire... -
Page 3: General Service
Safe Operation Practices for Ride-On Mowers III. CHILDREN Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the ma chine and the mowing activity. Never assume that children will remain where you last saw them. •... -
Page 4: Table Of Contents
PRODUCT SPECIFICATIONS Gasoline Capacity 1.50 Gallons and Type: Unleaded Regular Oil Type (API-SG-SL): SAE 30 (above 32°F) SAE 5W-30 (below 32°F) Oil Capacity: W/Filter: W/O Filter: 48 oz. Spark Plug: Champion RC12YC (Gap: .030") Ground Speed (MPH): Forward: Reverse: Charging System: 3 Amps Battery 5 Amps Headlights Battery:... -
Page 5: Unassembled Parts
UNASSEMBLED PARTS Steering Wheel Insert (1) Hex Bolt Steering Wheel Adapter (1) Seat Keys (2) Keys Steering Wheel (1) 5/16 Lock Washer Steering Boot Seat (1) Oil Drain Tube For Future Use (1) Large Flat Washer Steering Extension Shaft (1) Washer (1) Hex Bolt Slope Sheet... -
Page 6: Tools Required For Assembly
Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness. TOOLS REQUIRED FOR ASSEMBLY A socket wrench set will make assembly easier. - Page 7 INSTALL SEAT (See Figs. 2 and 3) • Remove bolt and flat washer se cur ing seat to cardboard packing and set aside for as sem bly of seat to tractor. Remove the cardboard packing and discard. • Connect switch to seat. •...
- Page 8 TO DRIVE TRACTOR OFF SKID (See Op- er a tion section for location and func tion of con trols) • Be sure all the above assembly steps have been com- plet ed. • Check engine oil level and fill fuel tank with gasoline. •...
-
Page 9: Operation
These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. REVERSE NEUTRAL REVERSE ENGINE ON ENGINE OFF OPERATION SYSTEM (ROS) OIL PRESSURE FUEL OVER TEMP LIGHT ATTACHMENT ATTACHMENT CLUTCH ENGAGED CLUTCH DISENGAGED LIGHTS ON FREE WHEEL (Automatic Models only) -
Page 10: Know Your Tractor
KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. THROTTLE/CHOKE THROTTLE/CHOKE CONTROL CONTROL... -
Page 11: How To Use Your Tractor
The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while operating your tractor or per form ing any adjustments or repairs. We rec om mend a wide vision safety mask over spectacles or stan dard safety glasses. -
Page 12: Before Starting The Engine
REVERSE OPERATION SYSTEM (ROS) Your tractor is equipped with a Reverse Operation System (ROS). Any attempt by the operator to travel in the reverse direction with the attachment clutch engaged will shut off the engine unless ignition key is placed in the ROS "ON" position. -
Page 13: Operation
ADD GASOLINE • Fill fuel tank to bottom of filler neck. Do not overfill. Use fresh, clean, regular un lead ed gasoline with a minimum of 87 octane. (Use of leaded gasoline will increase carbon and lead oxide deposits and reduce valve life). -
Page 14: Maintenance Schedule
MAINTENANCE SCHEDULE Check Brake Operation Check Tire Pressure Check Operator Presence & ROS Systems Check for Loose Fasteners Check/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Check Transaxle Cooling Check Mower Levelness Check V-Belts Check Engine Oil Level Change Engine Oil (with oil filter) Change Engine Oil (without oil filter) Clean Air Filter... -
Page 15: Maintenance
TRACTOR Always observe safety rules when per form ing any main- te nance. BRAKE OPERATION If tractor requires more than five (5) feet to stop at highest speed in high est gear on a level, dry concrete or paved surface, then brake must be checked and ad just ed. (See “TO ADJUST BRAKE”... -
Page 16: Engine Lubrication
TO SHARPEN BLADE (See Fig. 11) NOTE: We do not recommend sharpening blade - but if you do, be sure the blade is balanced. Care should be taken to keep the blade balanced. An un- bal anced blade will cause excessive vibration and even tual dam age to mower and engine. -
Page 17: Spark Plugs
TO CHANGE ENGINE OIL (See Figs. 12 and 13) Determine temperature range expected before oil change. All oil must meet API service classification SG-SL. • Be sure tractor is on level surface. • Oil will drain more freely when warm. •... -
Page 18: To Remove/Install Mower
SERVICE AND ADJUSTMENTS WARNING: TO AVOID SE RI OUS IN JU RY, BEFORE PERFORMING ANY SERVICE OR ADJUSTMENTS: • Depress clutch/brake pedal fully and set parking brake. • Place gearshift lever in neutral position. • Place attachment clutch in “DISENGAGED” position. •... -
Page 19: Service And Adjustments
SERVICE AND ADJUSTMENTS FIG. 16 • ATTACH REAR LIFT LINKS (C) - Lift rear corner of mower and position slot in link assembly over pin (D) on rear mower bracket and secure with washer and retainer spring. FIG. 17 • ATTACH FRONT LINK (E) - Work from left side of trac- tor. - Page 20 SERVICE AND ADJUSTMENTS TO LEVEL MOWER Make sure tires are properly inflated to the PSI shown on tires. If tires are over or under inflated, it may affect the appearance of your lawn and lead you to think the mower is not adjusted properly.
-
Page 21: To Replace Mower Blade Drive Belt
SERVICE AND ADJUSTMENTS TO REPLACE MOWER BLADE DRIVE BELT (See Fig. 24) The mower blade drive belt may be replaced without tools. Park the tractor on level surface. Engage parking brake. BELT REMOVAL - • Remove mower from tractor (See “TO REMOVE MOW ER”... - Page 22 SERVICE AND ADJUSTMENTS TRANSAXLE GEAR SHIFT LEVER NEU TRAL- ADJUSTMENT (See Fig. 26) The transaxle should be in neutral when the gear shift lever is in neutral (N) (lock gate) position. The adjustment is preset at the factory; however, if adjustment is needed, proceed as follows: •...
- Page 23 SERVICE AND ADJUSTMENTS REPLACING BATTERY ( See Figs. 29 and 30 WARNING: Do not short battery ter mi - nals by allowing a wrench or any other object to contact both terminals at the same time. Before connecting battery, remove metal bracelets, wristwatch bands, rings, etc.
-
Page 24: Storage
Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. WARNING: Never store the trac tor with gas o line in the tank inside a building where fumes may reach an open flame or spark. -
Page 25: Trou Ble Shoot Ing
TROUBLESHOOTING POINTS PROBLEM CAUSE Will not start Out of fuel. Engine not “CHOKED” properly. Engine flooded. Bad spark plug. Dirty air filter. Dirty fuel filter. Water in fuel. Loose or damaged wiring. Carburetor out of adjustment. Engine valves out of adjustment. Hard to start Dirty air filter. - Page 26 TROUBLESHOOTING POINTS PROBLEM CAUSE Engine dies when Reverse operation system tractor is shifted (ROS) is not "ON" while into reverse mower or other attachment is engaged. Engine continues to run Faulty operator-safety presence control system. when operator leaves seat with attachment clutch engaged Poor cut - uneven Worn, bent or loose blade.
-
Page 27: Schematic
TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 SCHEMATIC SCH11 NOTE YOUR TRACTOR IS EQUIPPED WITH A SPECIAL ALTERNATOR SYSTEM. THE LIGHTS ARE NOT CONNECTED TO THE BATTERY, BUT HAVE THEIR OWN ELECTRICAL SOURCE. BECAUSE OF THIS, THE BRIGHTNESS OF THE LIGHTS WILL CHANGE WITH ENGINE SPEED. - Page 28 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 ELECTRICAL T02S With 12V Outlet Option With Service Minder Option...
- Page 29 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 ELECTRICAL PART DESCRIPTION 163465 Battery 74760412 Bolt Hex Hd 1/4-20 unc x 3/4 193228 Box Battery 176138 Switch Interlock 183759 Harness Socket Light 4152J Bulb, Light # 1156 401662 Cable Battery 6 Ga.
- Page 30 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 CHASSIS Chassis-tex_elite-sv-pro_11...
- Page 31 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 CHASSIS PART DESCRIPTION 412282 Drawbar 197783X428 Dash 183393X428 Hood 183834X599 Lens Grille LH 183828 Grille 183835X599 Lens Grille RH 17060512 Screw 5/16-18 x 3/4 414872X428 Fender 412280 Drawbar Upper 17490508 Screw Thdrol 5/16-18 x 1/2 416358...
- Page 32 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 DRIVE...
- Page 33 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 DRIVE PART DESCRIPTION - - - - - - Transaxle, DANA D6800-1 123583X Key Square 19131316 Washer 13/32 x 13/16 x 16 Ga. 197297 Spring, Brake 197660 Rod Shift 409154x421 Knob 197455...
- Page 34 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-bs-1cyl-tex_4...
- Page 35 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 ENGINE NOTE: All component dimensions given in U.S. inches Engine Power Rating Information The gross power rating for individual gas engine models is labeled in accordance with SAE (Society of Automotive Engi- neers) code J11940 (Small Engine Power &...
- Page 36 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 STEERING steering-tex_LEGND2_14...
- Page 37 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 STEERING PART DESCRIPTION 186093X428 Wheel, Steering 184706 Axle Asm., Front 403087 Spindle Asm., LH 403088 Spindle Asm., RH 6266H Bearing, Race Thrust Harden 121748X Washer 25/32 x 1-5/8 x 16 Ga. 12000029 Ring, Klip #T5304-75 121232X...
- Page 38 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 SEAT seat-tex_6.5SL_2 PART DESCRIPTION 197514 Seat 180166 Bracket Pivot Fender 140675 Strap, Asm Fender 73800600 Nut, Lock W/Ins. 3/8-16 unc 124181X Spring, Seat Cprsn 171877 Bolt 5/16-18 unc x 3/4 w/Sems 196977 Pan, Seat 171852...
-
Page 39: Wheels And Tires
TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 DECALS PART DESCRIPTION 411658 Decal Oper 408834 Decal Eng. H.P . 186164 Decal Hood LH 408794 Decal Side Panel Logo 411174 Decal Lwr Dash 170563 Decal Warning, Keep Hand Away 413417 Decal Replacement 172740... -
Page 40: Mower Deck
TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 MOWER DECK 46_tex_lt_pred_12... - Page 41 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 MOWER DECK PART DESCRIPTION 405050x421 Mower Housing 405507 Cover Mandrel LH 405506 Cover Mandrel RH 195186 Arm Suspension 416358 Screw 10 x .750 BOS Thread 193003 Bolt/Washer asm 7/16-20 unf 405380 Blade, 46"...
- Page 42 TRACTOR - - MODEL NUMBER PB19546LTX (96042006600), PRODUCT NO. 960 42 00-66 MOWER LIFT lift-tex_5_r3 PART DESCRIPTION 195223 Shaft Asm., Lift 195231 Lever Asm., Lift Rh 196492X421 Grip, Lever 196314 Spring Torsion 194209 Pin Cotter 7/16 Bow Tie Lock 410710 Spring Lift Assist 19191912 Washer Clear Zinc...
-
Page 44: Limited Warranty
The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materi- als and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
