- Page 1 SPLIT TYPE INDOOR UNIT/OUTDOOR UNIT MODEL RAS-30CP1R/RAC-30CVP1 INDOOR UNIT OUTDOOR UNIT RAS-30CP1R RAC-30CVP1 Instruction manual Page 1~19 To obtain the best performance and ensure years of trouble free use, please read this instruction manual completely.
-
Page 2: Safety Precaution
SAFETY PRECAUTION Please read the “Safety Precaution” carefully before operating the unit to ensure correct usage of the unit. Pay special attention to signs of “ Warning” and “ Caution”. The “Warning” section contains matters which, if not observed strictly, may cause death or serious injury. The “Caution” section contains matters which may result in serious consequences if not observed properly. - Page 3 PRECAUTIONS DURING OPERATION The product shall be operated under the manufacturer specification and not for any other intended use. Do not attempt to operate the unit with wet hands, this could cause fatal accident. When operating the unit with burning equipments, regularly ventilate the room to avoid oxygen insufficiency.
-
Page 4: Names And Functions Of Each Part
So as to operate the whole unit. (Refer page 6) OUTDOOR UNIT AIR INLET (BACK, LEFT SIDE) AIR OUTLET Blow out warm air. MODEL NAME AND DIMENSIONS MODEL WIDTH (mm) HEIGHT (mm) DEPTH (mm) RAS-30CP1R 1400 RAC-30CVP1 – 4 –... -
Page 5: Indoor Unit Indicators
OPERATION INDICATOR TEMPORARY SWITCH Temporary Switch emporary Switch about 7mm about 7mm Press Press Non-conductor Stick Non-conductor Stick Use this switch to start and stop when the remote controller does not work. [Use non-conductor stick (example toothpick)] By pressing the temporary switch, the operation is done in previously set operation mode. -
Page 6: Names And Functions Of Remote Controller
4 meters. If indoor lighting is controlled electronically, the range of control may be shorter. Signal Transmission ON/OFF Button Transmission Sign HITACHI Press this button to start operation. The transmission sign blinks Press it again to stop operation. when a signal has been send. -
Page 7: Automatic Operation
AUTOMATIC OPERATION The device will automatically determine the operation mode either COOL or DEHUMIDIFY, depending on the initial room temperature. HITACHI Press the (START/STOP) button Operation start with a “beep”. Press the (START/STOP) button STOP Please make sure you have been selected the (Automatic) mode °C... -
Page 8: Circulation Operation
When the room temperature is higher than the thermostat set temperature, only the fan operates to circulate the upper hotter air downwards. This makes temperature distribution of the room evenly at heating. HITACHI Press the (START/STOP) button Operation start with a signal received sound “beep”. - Page 9 Explanation of the sleep timer The device will control the FAN SPEED and room temperature automatically so as to be quiet and good for people’s health. You can set the sleep timer to turn off after 1, 2, 3 or 7 hours. The FAN SPEED and room temperature will be controlled as shown below.
-
Page 10: Manual Operation
Please use below condition when you want to set the function mode, room temperature and fan speed by manually. DEHUMIDIFYING COOLING Room Temperature 16°C above Outdoor Temperature 22-42°C OPERATION MODE SELECTION HITACHI Every time you press the button, the mode will change as the below sequence (Auto) [ (Cool) [ (Dehumidify) [ (Circulation) °C... -
Page 11: Timer Reservation
OFF Timer Reservation Operation stop at setting time OFF TIME setting Select the OFF TIME by pressing the (OFF) HITACHI Button. Setting time will change according to the below sequence when you press the button. 0.5 hour interval 1 hour interval °C... -
Page 12: Adjusting The Air Deflectors
ADJUSTING THE AIR DEFLECTORS Adjustment of the conditioned air in the upward and downward directions. According to “Dehumidifying” or “Cooling” operation, the horizontal air deflector is automatically set to the proper angle suitable for each operation. The deflector can be swung up and down and also set to the desired angle using the “... -
Page 13: To Exchange Batteries In Remote Controller
HOW TO EXCHANGE THE BATTERIES IN THE REMOTE CONTROLLER Remove the cover as shown in the figure and take out the old batteries. Install the new batteries. Push and pull to the The direction of the batteries should match direction of arrow the marks in the case. -
Page 14: Air Filter
MAINTENANCE CAUTION Before the cleaning, stop operation and disconnect the power supply. AIR FILTER Clean the air filter, as it removes dust inside the room. In case the air filter is full of dust, the air flow will decrease and the cooling capacity will be reduced. Further, noise may occur. Be sure to clean the filter following the procedure below. -
Page 15: Regular Inspection
MAINTENANCE AT BEGINNING OF LONG OFF PERIOD Run the unit by setting the operation mode to (FAN) and the fan speed to HI for about half a day on a fine day, to dry the whole unit. Disconnect the power plug. Blow REGULAR INSPECTION PLEASE CHECK THE FOLLOWING POINTS EVERY EITHER HALF YEARLY... - Page 16 THE IDEAL WAYS OF OPERATION Suitable Room Temperature Install curtain or blinds Warning It is possible to Freezing temperature reduce heat is bad for health and a entering the waste of electric power. room through windows. Ventilation Effective Usage Of Timer At night, please use the “sleep timer operation Caution mode”, together with your wake up time in the...
- Page 17 FOR USER’S INFORMATION The Air Conditioner And The Heat Source In The Room Caution If the amount of heat in the room is above the cooling capability of the air conditioner (for example: more people entering the room, using heating equipments and etc.), the preset room temperature cannot be achieved.
- Page 18 AFTER SALE SERVICE AND WARRANTY WHEN ASKING FOR SERVICE, CHECK THE FOLLOWING POINTS. CONDITION CHECK THE FOLLOWING POINTS Is the fuse all right? When it does not operate Is the voltage extremely high or low? Is the power switch “ON”? Is the air filter blocked with dust? Does sunlight fall directly on the outdoor unit? Is the air flow of the outdoor unit obstructed?
