- Page 1 Model ezTWO Owner’s Manual Tech Data: GSM 850/900/1800/1900 MHz Battery: Li-Ion 3.7V / 1000mAh Dimensions: 118.5 x 57.5 x 15.3mm Weight: 90 g M3 / T3 Hearing Aid Compatible...
-
Page 2: Table Of Contents
Table of Contents Safety Precautions Getting Started Turning on the Phone Setting up Voicemail Making a Call Answering an Incoming Call Disconnecting a Call Call Waiting Conference Call The Snapfōn® Home Screen Field Definitions Icons External Features High-Intensity LED Flashlight Keypad Lock Camera Launch Button +/- Button... - Page 3 Lanyard Connection Headphone Port Power Port Keypad Diagram of External Features Key Functions The Menu Phonebook Options Messaging Write Messages Inbox Draft Outbox Sent Delete Messages Call History Missed Calls Dialed Calls Received Calls Delete Call Logs...
- Page 4 Photos The Photo Album The Camera Camera Key Functions Settings Tone Settings Phone Settings Time and Date Language SIM Card Speed Dial Bluetooth SMS & VM Number Low Battery Restore Factory Settings SOS Settings Button Status Siren Contacts Text Messages Alarm Silent Mode...
- Page 5 Installing the Battery & SIM Card SIM Card Installation Diagram Battery Installation Diagram Warranty to the Original Purchaser Intended Usage Disposal FCC RF Exposure Information & Statement Address and Contact Info...
-
Page 6: Safety Precautions
Safety Precautions When using this unit, basic safety precautions should always be followed to reduce the risk of fire, electric shock, or personal injury. Read and understand all instructions. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. - Page 7 Do not expose the unit to extreme temperatures such as areas near a hot radiator or stove or in a hot car. Do not place lighted objects such as candles or cigarettes on the unit. Do not use this unit to report a gas leak in the vicinity of the leak. Power off...
-
Page 8: Getting Started
Getting Started Thanks for buying the Snapfōn® ezTWO! Please read this manual thoroughly before use. This section is intended for Snapfōn® customers who purchased their handset with a Snapfōn® service plan. If you purchased a handset without service, additional steps may be required. -
Page 9: Answering An Incoming Call
Answering an Incoming Call When the phone rings and/or vibrates, press the green Send/Answer button to answer the call. Disconnecting a Call Press the Red Power button to end a call at any time. Call Waiting While a call is engaged, press the Answer or Ignore Option Buttons when the second incoming call is displayed. -
Page 10: The Snapfōn® Home Screen
The Snapfōn® Home Screen Field Definitions 1. Signal Status Indicator 5. Time 2. Battery Charge Indicator 6. Date 3. Icons 7. Option Left 4. Cellular Service Type 8. Option Right... -
Page 11: Icons
Icons SOS Button Enabled Ring Only Vibrate & Ring Vibrate Only Alarm Set Missed Call You have Voicemail(s) Bluetooth You have SMS Text Message(s) Hands-Free Headset Keypad Lock Engaged Silent Mode Engaged... -
Page 12: External Features
External Features High-Intensity LED Flashlight Switch up: ON Switch down: OFF Keypad Lock Slide this switch to the down position to lock the keypad and prevent unintentional dialing. Slide it back up to unlock and use as normal. Calls can still be answered when the keypad is locked. Camera Launch Button Long press this button to launch the camera. -
Page 13: Headphone Port
Plug in a qualified Snapfōn® or Nokia 3.5mm headset to use your Snapfōn® ezTWO hands-free headset. Power Port The Snapfōn® ezTWO uses a mini-USB connection to charge the phone with your wall charger, car charger, or your computer’s USB port. -
Page 14: Diagram Of External Features
Diagram of External Features Lanyard Connection & Flashlight Camera Flashlight Camera & SOS Button Launch On/Off Volume Keypad Lock Up/Down On/Off USB Port & Headset Port... -
Page 15: Key Functions
Key Functions Button Function(s) Selects command displayed in the bottom left and bottom right corners Option Left / Right of the screen. Incoming Call: Press once to answer call. Outbound Call: Press once after entering a 7 or 10-digit phone number Send / Answer to place a call. -
Page 16: The Menu
The Menu Phonebook The Phonebook allows you to store up to 250 contacts to your SIM card. Contacts may be added manually with the “Add new contact” feature. To make a call from the Phonebook, simply move the white highlight bar over the contact’s name and press the green Send button. -
Page 17: Messaging
5. Send PIC – Allows you to send a picture in a text message (requires MMS data plan). 6. Delete – Deletes the contact permanently. Messaging The Messaging menu allows you to read and write both SMS text messages and MMS Multimedia Messages (MMS is only supported if your cellular service includes a data/MMS messaging-capable plan). -
Page 18: Inbox
Inbox The Inbox contains all the messages that have been sent to you. Draft The Draft folder contains all the text messages you have written but have not sent. Outbox The Outbox stores any messages you have attempted to send, but which did not actually successfully transmit. -
Page 19: Call History
Call History The Call History menu stores a record of all Missed, Dialed, and Received calls. Viewing any call list, you will have the option to return the call, see greater detail about the call, send the caller a SMS text message, add the caller to your Phonebook, or delete the call from the call record. -
Page 20: Received Calls
Received Calls Received Calls will display any calls made to your phone number, with the most recent at the top. Like the Missed and Dialed Call lists, you may redial one of these numbers by highlighting it and pressing the Send button, or you may see all of your options by pressing the Left Option button. -
Page 21: Photos
Rename, or Delete the picture, or Delete all to delete all photos stored in your camera (note – this can NOT be undone). The Camera The Snapfōn® ezTWO includes a .3 megapixel camera with a number of useful features. The following is a list of buttons and their associated functions. -
Page 22: Camera Key Functions
Camera Key Functions Button Function(s) Navigation Button Controls up to 2X zoom. Camera Button, Send (Green), Takes a picture. or 0 Button End / Power (Red) Exits the camera. +/- Button Control the exposure/brightness of an image before taking a picture. Select the desired Image Size before taking a picture (160x120, 320x240, or 640x480). -
Page 23: Settings
Settings Tone Settings The Tone Settings menu allows you to set the ring tone, alert type, and volume for incoming calls, voicemails, and incoming SMS text messages. It also allows you to turn the speaking keypad feature On/Off, and adjust its volume. Phone Settings The Phone Settings menu allows you to set the time &... -
Page 24: Language
Language The Snapfōn® ezTWO supports both English and Spanish. To change to Spanish rather than the default English, highlight and enter the language option, then highlight the language you prefer to use and press the left option button to save your selection. -
Page 25: Bluetooth
Bluetooth The Snapfōn® ezTWO includes Bluetooth technology to allow you to connect to other Bluetooth devices, such as your car or a hands-free headset. The Bluetooth menu is designed to be as easy to navigate as possible. • On/Off – Bluetooth may be turned on or off. -
Page 26: Sms & Vm Number
SMS & VM Number This menu option is to be used only in the event that your VM or SMS number must be changed due to a network or other error. In this case, please contact Snapfōn® or your service provider for assistance. -
Page 27: Sos Settings
SOS Settings The SOS Button is the feature that sets Snapfōn® apart from every other senior phone on the market. This button is capable of emitting a loud siren, sending text messages to as many as 4 contacts in your phonebook, and dialing the same contacts until it reaches either an answer or a voicemail box –... -
Page 28: Button Status
Button Status The button status option allows a user to completely turn their SOS button off, or back on. The button’s current status will be displayed in a light blue bubble when highlighted with the white bar. Also, when the SOS Button is on, you will see the bar. -
Page 29: Contacts
Contacts The Contacts feature allows you to select up to four (4) contacts from your Phonebook to alert in the event of an emergency. Important - If you have oneCall Mobile Monitoring, leave oneCall in the first position and NEVER delete it from your Phonebook. You may select any other three (3) contacts from your Phonebook for positions 2, 3, and 4. -
Page 30: Alarm
Alarm The Snapfōn® ezTWO includes an alarm which will allow you to set up to 4 different alarm times with their own individual characteristic tones. To set an alarm, go to the Alarm menu, highlight any of the 4 alarm positions, and press the left option button to Edit. -
Page 31: Silent Mode
Press the down arrow button again to select the Snooze time for the alarm with the +/- button (select from a range of 1-10 minutes). Press the down arrow button again to select the alert type for your alarm. The +/- button will select from either Vib(rate) only, Vib(rate) and ring, or Ring only. -
Page 32: Installing The Battery & Sim Card
Installing the BATTERY & SIM CARD The Snapfōn® ezTWO is a GSM phone, and requires a SIM card to operate. The SIM card is a small removable chip that stores your contacts and links the handset to your cellular service. -
Page 33: Sim Card Installation Diagram
Figure 1. SIM Card Installation Diagram Slide SIM Card (gold contact side facing down) under top edge of SIM TAB as shown. SIM TAB SIM TAB Slide SIM Card (gold contact side facing down) under SIM TAB toward bottom of phone until seated. -
Page 34: Battery Installation Diagram
Figure 2. Battery Installation Diagram Insert battery - logo side up with gold contacts facing down into the compartment at an angle as shown. Press top of battery down until flat into the compartment as shown. -
Page 35: Warranty To The Original Purchaser
RMA (Returned Merchandise Authorization) number should be present on the package or the shipment may be refused. The Snapfōn® ezTWO handset should be returned with all the accessories, with clear return shipping instructions that include your address, phone number, and a detailed description of the reason for the return. -
Page 36: Intended Usage
If a problem develops due to a third party battery, or charging adapter please contact the manufacturer of that accessory. EXCEPT AS PROVIDED HEREIN THERE ARE NO OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. -
Page 37: Fcc Rf Exposure Information & Statement
The SAR limit allowed by the FCC (USA) is 1.6 W/kg (watts per kilogram) averaged over one gram of tissue. The Snapfōn® ezTWO (FCC ID: ZXL-EZTWOB) has been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 0.749 W/kg and when properly... -
Page 38: Address And Contact Info
Such modifications or changes could void the user’s authority to operate the equipment. Please send all correspondence and RMA’s to: SeniorTech LLC 100 Cherokee Blvd Ste 216 Chattanooga, TN 37405 (800) 937-1532 website: www.snapfon.com email: customerservice@seniortechllc.com...
