- Page 1 User Manual MODEL QD6523ZH Outdoor Intelligent Pan-Tilt-Zoom Dome Camera with 23x Optical Zoom and Internal Heater...
-
Page 2: Table Of Contents
Q-See Product Warranty Questions or Comments? Contact Us © 2013 Q-See. Reproduction in whole or in part without written permission is prohibited. All rights reserved. This manual and software and hardware described herein, in whole or in part, may not be reproduced, translated, or reduced to any machine-readable form without prior written approval. -
Page 3: Introduction
Camera can be controlled with an optional keyboard For your safety and to protect your camera To prevent damage to your Q-See product or injury to yourself or to others, read BEFORE INSTALLING and understand the following safety precautions in their entirety before installing or using this equipment. -
Page 4: Setting Baud Rate And Address
On 9600bps the QD6523ZH, there are a total of 12 DIP switches.The first eight are for setting the address of the camera.The next block of four switches controls the baud... -
Page 5: Connecting The Camera
You will need to consult your DVR’s manual for this procedure, These wires may be ignored if an alarm will not be used. but a sample screen (from a Q-See QT-series DVR) is shown immediately above. -
Page 6: Installing The Camera
BEFORE INSTALLING YOUR CAMERA INSTALLING THE CAMERA Use the included torx (star) wrench to loosen When installing your camera, it is important to select a proper site not only for field the three housing bolts to open the lens cover. of view, but for other considerations as well: We have also included fabric gloves with your Distance from viewing/recording device. -
Page 7: Operation
On both control panels there are controls for zoom, focus and iris (light level). The QD6523ZH has a 23x optical zoom lens which will adjust between 3.9 and 89.7mm. The camera has an auto-focus feature but the user can also adjust it to bring a specific item into focus. -
Page 8: System Setting Menu
ADDITIONAL SETTINGS USING THE CAMERA’S ON-SCREEN MENU EXAMPLE 1: SETTING A CRUISE This example is based on using a QT-Series DVR without an attached PTZ The QD6532Z offers additional features that can be accessed through the DVR’s keyboard. Your DVR’s specific commands may differ slightly. Please consult your PTZ menu, but which are actually programmed on the camera itself. -
Page 9: Display Setting Menu
DISPLAY SETTING MENU Exposure Setting: There are also two pages in this menu for the multiple settings You can determine what shows up on screen as the camera operates. It is that can be made to optimize the video image. Settings can be changed using the important to consider that whatever text the camera displays will appear in the left and right directional arrows. -
Page 10: Function Setting Menu
Focus Setup: In this menu, you can turn off the autofocus feature of your camera To mask off an area: PRIVACY NO as well as limit the range that it will focus on and its sensitivity. As the camera does STEP 1. -
Page 11: Troubleshooting
TROUBLESHOOTING Commands from the DVR can interfere with actions CAUTION! programmed through the internal menu. This conflict can cause the camera to freeze or damage it. Problem Solution No picture or unstable image Check both the power and video connections to the camera. Alarm Number: Each alarm must have its own number. -
Page 12: Specifications
Q-SEE PRODUCT WARRANTY SPECIFICATIONS Q-See is proud to back all of our products with a conditional service warranty Specification covering all hardware for 12 months from the date of purchase. Additionally, our Camera Image Sensor 1/4” EXviewHAD CCD II products also come with a free exchange policy that covers all manufacturing Eective Pixels NTSC: 976(H) ×... - Page 13 Digital Peripheral Solutions, Inc. 8015 E. Crystal Drive Anaheim, CA 92807...
