6. Touchscreen Display

Soundshield 4G features a 3.5" colour touchscreen that enables you to customise settings to
individual preferences.
This section explains how to use the features of the Soundshield 4G touchscreen.

6.1 Adjusting the touchscreen angle

The Soundshield 4G touchscreen angle can be adjusted for optimum viewing. Simply tilt the
touchscreen back and forth until it sits at your preferred angle.
As you adjust the touchscreen you will notice you have free range of up to 15° of forward tilt and 70°
backward tilt.
Note: Do not press directly onto the screen when adjusting the screen angle.

6.2 Basic gestures required for touchscreen interaction

Touch the screen with your finger to activate icons, scroll down a page, and select User Settings.
Single Tap
Briefly touch surface
with fingertip
Drag
Move fingertip over surface
without losing contact
Flick
Quickly brush
surface with fingertip

6.3 Standard Operation

During standard operation, the touchscreen displays the phone as the current target Audio Source.
The touchscreen also provides access to your Soundshield User Settings and Controls.
PC & Tel Audio
Source icon &
switching control
Headset/Handset
switching control
Settings icon
Volume level
Receive volume
level indicator
Receive volume
level control
Mute control
9
