Page 1: Installation And Operation
Installation and Operation Manual VCP-010-06(-07)-x Multi-Standard Video Cassette Player Document # 540236 VCP-010-06-x VCP-010-07-x a DeCrane Aircraft Company 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com... - Page 2 Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc Document # 540236, Rev IR, 11/2002...
-
Page 3: Table Of Contents
Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual Table of Contents Section Description Page GENERAL INFORMATION…………………………………... Introduction……………………………………………………... Purpose of the Equipment……………………………………. Operational Features………………………………………….. Optional Equipment……………………………………………. Technical Specifications………………………………………. Application……………………………………………………… INSTALLATION……………………………………………….. Prior to Installation…………………………………………….. Unpacking and Inspection…………………………………….. Cautions & Warnings………………………………………….. Wiring Requirements………………………………………….. - Page 4 Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual VCP-010-06(-07)-x Multi-Standard Video Cassette Player VCP-010-06-x VCP-010-07-x Document # 540236, Rev IR, 11/2002 Page 3 of 21...
-
Page 5: General Information
Purpose of the Equipment Audio International’s VCP-010-06(-07)-x is a high quality, multi-standard video cassette player. This unit plays versions of NTSC and PAL video cassettes. It does not support SECAM or MESECAM formats. -
Page 6: Optional Equipment
Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual Optional Equipment AI source equipment can be optionally controlled by infrared remote (AI-RCx-17xxxx). Playback options with this remote include visual search, pause, play, stop, fast forward, rewind, eject, and format. Contact your AI representative for details. - Page 7 NTSC and PAL. Typical Application 6.2.1 This system is fully compatible with Audio International’s proprietary RS-485 digital data bus system. It can be configured for IR remote control utilizing AI’s remote control unit AI-RCx-17xxxx and IFR-485.
- Page 8 Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual 6.2.2 The unit can also be configured for IR remote control utilizing AI’s remote control unit AI-RCx-17xxxx and IFR-9A. This following configuration utilizes a +5 VDC digital logic level for activation of infrared commands.
-
Page 9: Installation
Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual SECTION II - INSTALLATION Prior to Installation During the design and layout of the aircraft cabin, careful consideration of the location of this and all other audio/visual modules is necessary. Some of the items to be considered include: •... -
Page 10: Cautions & Warnings
International WITHIN 24 hours and a Return Request Authorization Number shall be obtained from AI. Refer to the front cover of this manual for address and telephone number of Audio International, Inc. Repackage the unit in its original packaging materials and return it to AI following instructions given by the AI representative. -
Page 11: Wiring Requirements
Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual Wiring Requirements Introduction The installing agency shall supply and fabricate all external cables. The length and routing of external cables should be carefully studied and planned before attempting installation of the equipment. Allow adequate space for installation of cable and connectors. -
Page 12: Physical Characteristics
Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual AI’s Proprietary RS-485 Data Bus 4.5.1 The VCP-010-06(-07)-x is designed to interface with other Audio International equipment via AI’s proprietary RS-485 serial data bus. The data bus shall be implemented using a twisted shielded pair cable in accordance with NEMA WC 27500 or equivalent. - Page 13 Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual The VCP-010-06(-07)-x utilizes one (1) 15-pin connector for electrical connections. This connector provides power, left/right audio output, data bus control, infrared input, and four (4) infrared strapping pins for alternate configuration of infrared digital command codes. Utilizing these infrared inputs, the VCP-010-06(-07)-x can be configured to accept up to four (4) different sets of infrared codes or eight (8) separate RS-485 addresses.
-
Page 14: Post-Installation Test
Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual Post-Installation Test Verify +28 VDC power has been connected to the unit. The audio signal output of the unit is generally connected to cabin speaker systems in addition to headphone locations. Verify all connections before supplying power to the unit. - Page 15 Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual Troubleshooting Chart Problem Possible Cause Solution Ø Faulty wiring • No power Verify +28 VDC power and audio/video input is present and recheck connections Ø Circuit breaker not • Turn circuit breaker to ‘ON’...
-
Page 16: Reference Drawings
Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the VCP-010-06-x. Document # 540236, Rev IR, 11/2002 Page 15 of 21... - Page 17 Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual Document # 540236, Rev IR, 11/2002 Page 16 of 21...
- Page 18 Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual The following diagrams show the unit dimensions, mounting locations, and connector locations for the VCP-010-07-x. Document # 540236, Rev IR, 11/2002 Page 17 of 21...
- Page 19 Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual Document # 540236, Rev IR, 11/2002 Page 18 of 21...
-
Page 20: Operation
Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual SECTION III – OPERATION General Information The VCP-010-06(-07)-x can be operated via front panel ‘buttons’ or optionally controlled by infrared remote or AI’s touch screen panel. Digital codes allow the unit to interface with an infrared handheld remote via an infrared receiver, IFR-9A or IFR-485. -
Page 21: To Load A Videocassette Tape Into Tape Slot
Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual ILLUSTRATION OF FRONT PANEL BUTTONS (Note that the VCP-010-07-x cover bezel is used for reference only; the button configuration is the same on all VCP-010-06(-07)-x models) To Load a Videocassette Tape into the Tape Slot Gently insert a videocassette tape into the cassette tape slot. -
Page 22: Front Panel Button Functions
Audio International, Inc. VCP-010-06(-07)-x Installation & Operation Manual Front Panel Button Functions Format Button – Press the FORMAT button to switch between PAL and NTSC output modes. Stop Button – Press the STOP button to stop videocassette tape playback. Rewind Button – While the tape is playing, press the REW button and the tape will reverse direction until the STOP or PLAY button is pressed.
