Page 1: Cover Page
Guide to Operations Multi-Standard Video Cassette Player Model #’s: VCP-015-01-x Document #560040 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988... - Page 2 READ THIS MANUAL COMPLETELY BEFORE OPERATING YOUR VIDEO CASSETTE PLAYER If you have any questions, please contact Audio International, Inc. See the last page of this booklet for the nearest AI representative. Document #560040, Rev. IR, Model No.: VCP-015-01-x...
- Page 3 AUDIO INTERNATIONAL, INC. 8/99 (This page intentionally left blank) Document #560040, Rev. IR, Model No.: VCP-015-01-x...
-
Page 4: Table Of Contents
PROPRIETARY NOTICE: Despite any6 copyright notice, the data and information disclosed herein is unpublished and contains confidential, proprietary design owned by Audio International Incorporated. Neither this data nor the data contained herein shall be reproduced, used or disclosed to anyone without the written authorization of Audio International Incorporated. -
Page 5: Product Features
AUDIO INTERNATIONAL, INC. 8/99 PRODUCT FEATURES • Custom Design for Aircraft: Operates directly from 28 VDC Compact, lightweight package Meets DO-160C, Section 21 Category Z EMI standards • Multiple Control Options: Optional infrared remote controllable RS-485 digital data bus compatible •... -
Page 6: Warnings
AUDIO INTERNATIONAL, INC. 8/99 WARNINGS • DO NOT attempt to open the case. Refer servicing to qualified personnel. • DO NOT place foreign objects into openings. Contact with foreign objects may result in dangerous voltage or STOP electric shock. •... -
Page 7: Cautions
AUDIO INTERNATIONAL, INC. 8/99 CAUTIONS • DO NOT use this unit other than for its intended purpose. Doing so might lead to electric shock or injury or damage to the equipment. • DO NOT use near water, moisture, or volatile sprays. Do... -
Page 8: Introduction
AUDIO INTERNATIONAL, INC. 8/99 INTRODUCTION • The names and functions of the VCP-015-01-x front panel are as follows: Stop Button - To stop the tape. Reverse Button - To rewind the tape or to start a reverse visual search. Play Button... -
Page 9: Illustration Of Vcp-015-01-X
AUDIO INTERNATIONAL, INC. 8/99 ILLUSTRATION OF FRONT PANEL Tape Insertion Slot Refer to Page 8 for names and functions Document #560040, Rev. IR, Model No.: VCP-015-01-x... -
Page 10: Viewing A Tape
AUDIO INTERNATIONAL, INC. 8/99 VIEWING A TAPE NOTE: If VCP is powered down while a cassette tape is left loaded in the unit, the tape must be ejected and reinserted before normal operations of the unit. Insert a cassette into the tape slot. - Page 11 AUDIO INTERNATIONAL, INC. 8/99 While the tape is playing, press the button for less than one second and the tape will reverse search or fast-forward search until the button is pressed. Pressing the button for greater than one second and the tape will continue to “search” until the button is released.
-
Page 12: Output System Setting
AUDIO INTERNATIONAL, INC. 8/99 OUTPUT SYSTEM SETTING According to the OUTPUT SYSTEM setting, the color system of signals to the monitor or video distribution system changes as follows: Color system of OUTPUT Output signals’ input/playback SYSTEM color systems signals Setting*... -
Page 13: Convenient Functions
AUDIO INTERNATIONAL, INC. 8/99 CONVENIENT FUNCTIONS • Automatic Playback – When a cassette without erasure prevention tabs is inserted, playback begins automatically. • When the VCP reaches the end of the cassette, the video player will automatically rewind the cassette. -
Page 14: Troubleshooting Guide
AUDIO INTERNATIONAL, INC. 8/99 TROUBLESHOOTING GUIDE PROBLEM CAUSE SOLUTION No Power Faulty wiring Connect to 28 VDC. Check connections. Circuit breaker not ON Turn circuit breaker to ON position. Picture is unclear Video heads may be dirty. Use a commercial head cleaner. -
Page 15: Authorized Representatives
AUDIO INTERNATIONAL, INC. 8/99 AUTHORIZED REPRESENTATIVES Audio International, Inc. Audio International, Inc. – Home Office – Midwest Operations 7300 Industry Drive 8925 West Maple Street, Suite #1 North Little Rock, AR 72117 Wichita, KS 67209 Phone (501) 955-2929 Phone (316) 729-6499...
