Page 1: Installation And Operation
Installation and Operation Manual VCP-015-02-x Multi-Standard Video Cassette Player Document # 540228 a DeCrane Aircraft Company 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com... - Page 2 Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc Document # 540228, Rev A, 05/2003...
-
Page 3: Table Of Contents
Audio International, Inc. VCP-015-02-x Installation & Operation Manual Table of Contents Section Description Page GENERAL INFORMATION………………………………….. Introduction……………………………………………………... Purpose of the Equipment……………………………………. Operational Features………………………………………….. Optional Equipment……………………………………………. Technical Specifications………………………………………. Application……………………………………………………… INSTALLATION……………………………………………….. Prior to Installation…………………………………………….. Unpacking and Inspection…………………………………….. Cautions & Warnings………………………………………….. Wiring Requirements………………………………………….. -
Page 4: General Information
Play, Stop, Fast-Forward, Reverse, Pause, Stop, and Eject. The VCP-015-02-x can be mounted in a cabinet or bulkhead. A unique strapping feature allows up to eight (8) similar devices to be used in the same system at the same time while maintaining independent control of each. -
Page 5: Optional Equipment
VCP-015-02-x Installation & Operation Manual Optional Equipment Users can optionally control the VCP-015-02-x by infrared remote or AI’s touch screen panel. Some remote controls possess functions not duplicated by the unit’s front panel buttons, such as Set-Up. While the VCP-015-02-x functions as... - Page 6 Audio International, Inc. VCP-015-02-x Installation & Operation Manual Typical Application 6.2.1 This system is fully compatible with Audio International’s proprietary RS-485 digital data bus system. It can be configured for IR remote control utilizing AI’s remote control unit AI-RCx-17xxxx and IFR-485.
-
Page 7: Installation
Subsection 9.0 for mounting hole diameters and configurations. All headphone amplifiers and line level amplifiers shall be located no more than three (3) feet away from the VCP-015-02-x. Long low-level audio runs may introduce noise into the audio signal. Avoid installing the unit where it will be exposed to excessive heat, moisture, splashing liquids, dusty areas, direct sunlight, or angled/inclined installations. -
Page 8: Cautions & Warnings
International WITHIN 24 hours and a Return Request Authorization Number shall be obtained from AI. Refer to the front cover of this manual for address and telephone number of Audio International, Inc. Repackage the unit in its original packaging materials and return it to AI following instructions given by the AI representative. -
Page 9: Wiring Requirements
Audio International, Inc. VCP-015-02-x Installation & Operation Manual 3.10 DO NOT leave cassette tapes loaded in the unit with no power applied. 3.11 NO scheduled maintenance is required to ensure airworthiness. 3.12 DO NOT insert any screw more than 0.25 inch into the case. Mounting holes on the unit provide multiple anchoring points. -
Page 10: Physical Characteristics
Audio International, Inc. VCP-015-02-x Installation & Operation Manual Audio Wires All audio connections require 22 AWG, MINIMUM twisted, shielded cable with the cable shields properly grounded at the source. Twisted shielded pair cable shall be in accordance with NEMA WC 27500 or equivalent. -
Page 11: Electrical Characteristics
Video Heads Infrared Signal Input +5 VDC digital logic level The VCP-015-02-x utilizes one (1) 15-pin connector for electrical connections. This connector provides power, left/right audio output, data bus control, infrared input, and eight (8) infrared strapping pins for alternate configuration of infrared digital command codes to allow up to eight (8) VCP-015-02-x in the same system. -
Page 12: Post-Installation Test
Verify all connections before supplying power to the unit. Verify video inputs are available to the system. Load the VCP-015-02-x with a videocassette tape. Use the front panel controls or the hand-held remote control unit to select PLAY. Check for a picture on the appropriate monitor. -
Page 13: Instructions For Continued Airworthiness
Audio International, Inc. VCP-015-02-x Installation & Operation Manual Instructions for Continued Airworthiness Unit Maintenance • Ensure the unit is not exposed to excessive heat, moisture, splashing liquids, dusty areas, direct sunlight, or angled/inclined installations. Any of these conditions may damage the unit. - Page 14 Audio International, Inc. VCP-015-02-x Installation & Operation Manual Troubleshooting Chart Problem Possible Cause Solution Ø Faulty wiring • No power Verify +28 VDC power and audio/video input is present. Recheck connections. Ø Circuit breaker not • Turn circuit breaker to ‘ON’...
-
Page 15: Reference Drawings
Audio International, Inc. VCP-015-02-x Installation & Operation Manual Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the VCP-015-02-x. Document # 540228, Rev A, 05/2003 Page 14 of 18... - Page 16 Audio International, Inc. VCP-015-02-x Installation & Operation Manual Document # 540228, Rev A, 05/2003 Page 15 of 18...
-
Page 17: Operation
SECTION III – OPERATION General Information The VCP-015-02-x can be operated via front panel ‘buttons’ or optionally controlled by infrared remote or AI’s touch screen panel. Digital codes allow the unit to interface with an infrared handheld remote via an infrared receiver, IFR-9A or IFR-485. -
Page 18: To Load A Videocassette Tape Into Tape Slot
To Load a Videocassette Tape into the Tape Slot Gently insert a videocassette tape into the cassette tape slot. Apply only slight pressure to the side edge of the tape. The VCP-015-02-x will gently ‘pull’ the tape into the player. Power turns ‘ON’ automatically when the cassette tape is inserted into the slot. -
Page 19: Operating Instructions
STOP or PLAY is pressed. Pressing REW during rewind mode accelerates the rewinding process. When the VCP-015-02-x reaches the end of the videocassette, the unit will automatically STOP and enter REW mode. Once the unit has rewound the cassette, the unit will STOP. Press EJECT to unload the videocassette tape.
