Summary of Contents for Redrover SDM-080
-
Page 1: User Guide
SDM-080 User Guide... -
Page 2: Table Of Contents
High Resolution Stereoscopic 3D Monitor TRUE3Di Parts Included ..........3 Function for each part and button ..... 5 Installation guide ........8 Stereoscopic driver installation guide ..13 Check list after turn computer on ..... 26... -
Page 3: Parts Included
Parts Included... -
Page 4: Parts Included
TRUE3Di USER GUIDE Parts Included 8 ″ Monitor Power cable and adapter Polarized glasses ※ Parts included and its manufacturer may vary upon subject. -
Page 5: Function For Each Part And Button
Function for each part and button... -
Page 6: Function For Each Part And Button
TRUE3Di USER GUIDE Function for each part and button INPUT CH(+) CH(-) SEL/AUTO MENU POWER 3D MODE Corresponding buttons are on front of the bottom part 1. Function for each button ① Power button : turn on and off monitor ②... - Page 7 Function for each part and button POWER S-VIDEO Composite Component ⑤ CH (-) button : ☞ Move dwon selection when menu window is already open or decrease value or parameter of selection ⑥ Input button : Change the input type (PC, Component(YPbPr), RGB, Composite Video, S-Video, TV input) ⑦...
-
Page 8: Installation Guide
Installation guide... - Page 9 Installation guide Monitor and computer image which would be shown throughout this manual for the installation of monitor. (Images for computer shown here may differ from each user’ s computer.) Front image of a monitor and a computer Rear image of a monitor and a computer Front image of back panel.
- Page 10 TRUE3Di USER GUIDE 1. For Dual DVI output graphics card 1) When using 2 RGB-RGB cables to connect from computer to monitor ① Connect left DVI port from computer to left RGB port from monitor using RGB- RGB cable with gender. Connect right DVI port from computer to right RGB port from monitor using RGB-RGB cable with gender.
- Page 11 Installation guide 2. For RGB and DVI output graphics card 1) When using 2 RGB-RGB cables with one gender to connect from computer to monitor Connect cables as picture above...
-
Page 12: Power Cable
TRUE3Di USER GUIDE 3. Power cable 1) Power cable connection ▶ One power cable and one adaptor ▶ Connect power cable correctly to is included as picture above. adaptor. ▶ Connect cable to monitor DC 12V port. ▶ Connect plugs to power outlet. (when using a multi-tap, please make sure to check on/off switch) -
Page 13: Stereoscopic Driver Installation Guide
Stereoscopic driver installation guide... - Page 14 TRUE3Di USER GUIDE 1. (Uninstall) Existing graphics card driver Nvidia Stereo Driver installation guide for Windwos XP. There is not a driver for Windows Vista yet (Graphics card driver and stereographic driver for 91.31) ② ① ③ 1) ① Click “Start” button -> ② Click “Control Panel” button ->...
- Page 15 Stereoscopic driver installation guide 2) Click “Change/Remove” button to remove existing graphics card. 3) After uninstalling the driver, reboot the computer.
- Page 16 TRUE3Di USER GUIDE 2. Download and Install new driver Due to frequent update of the nVidia website, actual website look may be different from time to time. Please read carefully and download files. Install the driver from the CD provided with purchase of the monitor or download from Nvidia website (www.nvidia.com) and install the driver.
- Page 17 Stereoscopic driver installation guide 3) Click “WinXP/2k 32 bit” (To download and install 3D stereo driver, search as in previous step. Read next page.)
- Page 18 TRUE3Di USER GUIDE 4) Click “Primary Download Site” or one of “Mirror Site 1, 2 or 3. 5) Click “Accept” button on the license for customer use of nvidia software. 6) Click “Save” button on the download window...
- Page 19 Stereoscopic driver installation guide 7) Install the driver on the computer and reboot the computer. 8) Next step is to download 3D Stereo driver.
- Page 20 TRUE3Di USER GUIDE 3. Download and install 3D stereo driver 1) Hover mouse over “Download Drivers” from the top menu from the website and submenu comes up. Then click “Download Drivers” Click “GeForce 3D Stereo Driver” on other downloads and support 2) Click “Download Now”...
- Page 21 Stereoscopic driver installation guide 4. Change Display Properties 1) Right Click the desktop anywhere. Click “Properties” at the bottom of the menu. Click “Settings” tab on the right side of the menu. 2) Click “Advanced” button at the bottom of the menu. 3) Click “nVidia Graphics tab.
- Page 22 TRUE3Di USER GUIDE 5. Stereo driver Settings Proceed as following. DO NOT click “Apply” at anytime. These instructions must be done in specific order. Otherwise the device will not perform. (※ If something went wrong, reboot the computer in safe mode and uninstall graphics card driver and stereographic driver as well.
- Page 23 Stereoscopic driver installation guide 1) Click “Stereo Properties” from the left menu 2) Select “Enabled” from Stereo Enable Mode 3) Set the value to 10% on Stereo Separation bar 4) Select Dual VGA Output(Dep3D) in Stereo Type 5) Click “Stereo Setup & Test” from the left menu ①...
- Page 24 TRUE3Di USER GUIDE 6) Click “Stereo Compatibility & Settings” 7) Put check mark on “Force anti-aliasing always off in stereo” 8) Put check mark on “Force software Vertex Shaders in Stereo” 9) Click “OK”...
- Page 25 Stereoscopic driver installation guide Currently, there are some errors with Dual core CPU on few applications. It would be rectified with updated version of nVidia drivers. It is highly recommended to use single core CPU. When using a dual core CPU, force to turn off one core as below steps. 1) Right click “My Computer”...
-
Page 26: Check List After Turn Computer On
Check list after turn computer on... - Page 27 Check list after turn computer on Check monitor and computer according to below list (note - It may happen that due to alteration of specifications of monitor and(or) glasses, left and right image may be reversed. If happen, switch cables to make left to right and right to left.) 1.
- Page 28 TRUE3Di USER GUIDE ◀ Number 1 and 2 shows superimposed as shown. ◀ Number 2 shows on the top monitor left-right flipped as shown. It means that the settings are done properly. ◀ Turn off the 2D/3D switch button. Number 2 disappears and number 1 still shows on the front monitor.
- Page 29 Important safety instructions...
-
Page 30: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS: Important safety instructions shall be provided with each apparatus. These instructions shall be in a separate booklet or sheet, or be located before any operating instructions in an instruction for installation or use and supplied with the apparatus. This information shall be given in a language acceptable to the country where the apparatus is intended to be used. - Page 31 TRUE3Di USER GUIDE 13) Unplug this apparatus during lightning storms or when unused for long periods of time. 14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
-
Page 32: Important Information
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO IMPORTANT: Model No.: RAIN OR MOISTURE. To aid reporting in case of loss or theft, please record the TV's model and serial numbers in the space Serial No.: TRUE3Di USER GUIDE provided. - Page 33 MEMO...
- Page 34 Homepage : www.redrover.co.kr Webmaster@redrover.co.kr...
