  • Page 1 SDM-190M SDM-240 SDM-400 User Guide...

  • Page 3: Table Of Contents

    High Resolution Stereoscopic 3D Monitor True3Di............4 Hazardous.parts......... .6 Included.parts..........12 Button.functions.description......14 Installation.guide.........16 Graphics.card.Installation.guide....20 OSD.settings.-.Monitor.menu.settings..23 Important.safety.instructions...... .37 Trouble.shooting.........41...

  • Page 4: True3Di

    True3Di...
  • Page 5 True3Di USER GUIDE We.appreciate.users.who.decide.to.use.True3Di.product.. SYSTEM REQUIREMENTS CPU.:.Pentium4-.3G.(over) M/B-Intel.chipset(i845,915P,945...etc.) RAM.-.1GB.DDR.or.DDR2 HDD.-.160GB.(over) VGA.-.NVIDIA.G-Force6000Series.7000Series, ..Quadro.FX.Series POWER.-.350W.(over) SPECIFICATIONS Model SDM-190M SDM-240 SDM-400 Aspect.ratio SXGA WUXGA WUXGA Resolution 1280.X.1024 1920.x.1200 1920.x.1080 Active.Display.area.(mm,.typ) 376.32(H)*301.056(V) 518.4(H)*324.0(V) 885.6(H)*498.15(V) Pixel.Pitch(mm) 0.294(H)*0.294(W) 0.270(H)*0.270(W) 0.46725(H)*0.46125(W) Brightness.(nits) 300.cd/㎡ 400cd/㎡ 500cd/㎡ 1000 Contrast.Ratio(typ.) 700.:.1 1000.:.1 3000.:.1...

  • Page 6: Hazardous.parts

    Hazardous Parts...
  • Page 7 True3Di USER GUIDE ※ Caution ● Graphic card ▶Quadro FX series for Open GL Stereo Software ▶ Geforce 6000 and 7000 series for DirectX Stereo Software ● As using two graphic cards ▶ Please use the same graphic cards for the Quadro FX series. If different versions of the graphic cards are used, 3D stereo will not work properly.
  • Page 8 True3Di USER GUIDE ● Disconnect the power cable from the outlet when lightning or thunder is nearby or occurring. ▶ It may cause a fire and/or electric shock. ● Do not drag or move the monitor in any direction holding the power cable or any other cables.
  • Page 9 True3Di USER GUIDE Warnings relating installation ● Do not install or place the monitor at the edge of the shelf. Make sure the monitor is installed or placed fully inside the given space. ▶ It may drop or fall to cause damage or serious injury. ●...
  • Page 10 True3Di USER GUIDE ● Install or place the monitor at least 10 cm (5 inch) from the wall for optimum level of ventilation. ▶ It may reduce or damage the life of the parts or board. ● Disconnect the power cable and other connected cables if connected from the outlet and monitor when removing the monitor to different locations.
  • Page 11 True3Di USER GUIDE ● Do not watch the monitor for too long at a close distance. ▶ Make sure to rest at least 5 minutes after each hour. ● Do not let anyone to climb on top of the monitor. ▶...

  • Page 12: Included.parts

    Included Parts...
  • Page 13 True3Di USER GUIDE Included Parts Cleaner (19inch,24inch,40inch) RGB to Component cable DVI cable (24inch,40inch) (19inch,24inch,40inch) AC/DC adapter Power cable Polarized glasses (19inch) (19inch,24inch,40inch) 19inch,24inch(45 /135 polarized) 40inch(0 polarized) ※ Parts included and its manufacturer may vary upon subject. ※ It is possible to change the included quantity and manufacturer of parts.

  • Page 14: Button.functions.description

    Button Function description...
  • Page 15 True3Di USER GUIDE Function descriptions on each part Front lower side 2D / 3D switch button Power button and OSD setting buttons Button which enables a person to Menu buttons which enables to change switch between 2D and 3D view. configurations and value.

  • Page 16: Installation.guide

    Installation guide...
  • Page 17 True3Di USER GUIDE Monitor and computer images which are shown throughout this manual for the installation of the monitor Front image of a monitor and a computer Rear image of a monitor and a computer The Above picture shows the Video input ports on the rear side of monitor and the VGA ports for the graphic card installed in computer.
  • Page 18 True3Di USER GUIDE 1. For Dual DVI output graphics card 1) When using 2 DVI-DVI cables to connect from the computer to themonitor Connect left the DVI port① from the computer to the Main DVI-I port① from the monitor using a DVI-I cable. Connect the right DVI port② from the computer to the SUB DVI-I port②...
  • Page 19 True3Di USER GUIDE 2) Check 3D switch button ◀ 2D/3D switch button is shown. (When switching from 2D to 3D, press and hold the button for 3 seconds, then it will light up.) ◀ If it lights up, monitor is now showing in 3D view mode.

  • Page 20: Graphics.card.installation.guide

    Graphics Card Installation guide...
  • Page 21 Quadro graphics card is only for operating stereo based on Open GL. ※ If you use the program based on games or directX, please contact Redrover technical support center, sales@redrover.co.kr Hover the mouse over “Download Drivers” from the top menu from the website and a submenu will come up.
  • Page 22 True3Di USER GUIDE Click “Set up multiple display” from the left list. Then click “The same on both displays (Clone) from “1. Choose the nView display mode to use” question. Click “Manage 3D settings” . Then turn on “Stereo - Enable” from the right list Change “Stereo - Display mode”...

  • Page 23: Osd Settings Monitor Menu Settings

    OSD Settings Monitor Menu Settings...
  • Page 24 True3Di USER GUIDE 1. OSD Buttons(19inch) ① 2. Button Description ① 3D_Power: Power on/off button for the upper monitor. ② LED light for displaying the status of the upper monitor. ③ Input: Selection of input signals. ④ Menu: Activate OSD Menu & Delete OSD Menu. ⑤...
  • Page 25 True3Di USER GUIDE 3. Monitor menu Settings 1) Picture Mode - Press Menu button (④) - Press Enter (⑦) to select. Then press up (⑤) and down (⑥) buttons to select desired sub-menu. - Press Enter (⑦) to select desired sub-menu. Then change its value by pressing up (⑤) and down (⑥) buttons.
  • Page 26 True3Di USER GUIDE 2) Option Mode - Press Menu button (④). Then “Picture OSD” shows. - Press up (⑤) and down (⑥) buttons to select “Option Menu” - Press Enter (⑦) to select “Option Mode” . Then press up (⑤) and down (⑥) buttons to select desired sub-menu.
  • Page 27 True3Di USER GUIDE 1. OSD setting - Monitor menu setting (24inch,40inch) (24inch) ⑨ ⑧ ⑦ ⑥ ⑤ ④ ③ ② ① 2. Button Description ① Power : Power on/off switch monitors. ② LED Button for displaying the status of the Monitor. ③...
  • Page 28 True3Di USER GUIDE The chosen OSD settings will be stored in the memory. The OSD menu can be cleared from The chosen OSD settings will be stored in memory. The OSD menu can be cleared from the screen from the the screen from the screen by moving the selection bar to the EXIT MENU icon and pressing screen by moving the selection bar to the EXIT MENU icon pressing the SEL button otherwise it will be the SEL button.
  • Page 29 True3Di USER GUIDE BackLight PICTURE SETUP SCREEN ICON ICON ICON ICON P i c t u r e B a c k L i g h t 0 ~ 100 P S M U s e r B r i g h t n e s s C o n t r a s t C o l o r S h a r p n e s s...
  • Page 30 True3Di USER GUIDE Brightness/Contrast/Color/Sharpness PICTURE SETUP SCREEN ICON ICON ICON ICON P i c t u r e P S M U s e r B r i g h t n e s s 0 ~ 100 C o n t r a s t C o l o r S h a r p n e s s T i n t...
  • Page 31 True3Di USER GUIDE On/Off On/Off =PIP PICTURE SETUP SCREEN ICON ICON ICON ICON P I P / P O P / P B P O n / O f f P I P S o u r c e V i d e o S w a p O f f P I P...
  • Page 32 True3Di USER GUIDE Source PICTURE SETUP SCREEN ICON ICON ICON ICON P I P / P O P / P B P O n / O f f P I P S o u r c e V i d e o S w a p O f f P I P...
  • Page 33 True3Di USER GUIDE PIP position PICTURE SETUP SCREEN ICON ICON ICON ICON P I P / P O P / P B P O n / O f f P I P S o u r c e V i d e o S w a p O f f P I P...
  • Page 34 True3Di USER GUIDE Language PICTURE SETUP SCREEN ICON ICON ICON ICON S e t u p L a n g u a g e E n g l i s h English T r a n s p a r e n c y Deutsch A R C 1 6 : 9...
  • Page 35 True3Di USER GUIDE SET ID On/Off SET ID On/Off PICTURE SETUP SCREEN PICTURE SETUP SCREEN ICON ICON ICON ICON ICON ICON ICON ICON S e t u p S e t u p L a n g u a g e E n g l i s h L a n g u a g e E n g l i s h...
  • Page 36 True3Di USER GUIDE Language PICTURE SETUP SCREEN ICON ICON ICON ICON S e t u p L a n g u a g e E n g l i s h English T r a n s p a r e n c y Deutsch A R C 1 6 : 9...

  • Page 37: Important.safety.instructions

    Important safety instructions...
  • Page 38 True3Di USER GUIDE IMPORTANT SAFETY INSTRUCTIONS: Important safety instructions shall be provided with each apparatus. These instructions shall be in a separate booklet or sheet, or be located before any operating instructions in an instruction for installation or use and supplied with the apparatus. This information shall be given in a language acceptable to the country where the apparatus is intended to be used.
  • Page 39 True3Di USER GUIDE 13) Unplug this apparatus during lightning storms or when unused for long periods of time. 14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
  • Page 40 IMPORTANT INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC True3Di USER GUIDE SHOCK, DO NOT EXPOSE THIS PRODUCT TO IMPORTANT: Model No.: RAIN OR MOISTURE. To aid reporting in case of loss or theft, please record the TV's model and serial numbers in the space Serial No.: provided.

  • Page 41: Trouble.shooting

    Trouble Shooting...
  • Page 42 True3Di USER GUIDE Trouble Shooting 1. No image is shown on the screen after the computer is turned on. 1) When the graphics card is inserted loosely into the card slot on the motherboard, take out the graphics card from the slot to check if it is clean and re-insert it tightly.
  • Page 43 True3Di USER GUIDE Service 1. Free of service charge Free repair service is valid until the warranty expires when the monitor has been used with no factory defects or any other initial problems. 2. Service charge following reasons would require service charge (labor fee, part fee, service fee) 1) After warranty has expired 2) Before warranty has expired - Natural disaster or act of God (fire, flood, lightning, earthquake and other natural...
  • Page 44 Homepage : www.redrover.co.kr Webmaster@redrover.co.kr...
