User Manual
HVE-6501T/6501R
HDMI over IP PoE Transmitter/Receiver
HVE-6601T/6601R
HDMI Video Wall over IP PoE Transmitter / Receiver
Quick Installation Guide
Package Contents
HVE-6501T:
Power Adapter
CD Manual/Utility
Quick Installation Guide
HVE-6601T:
Power Adapter
RS-232 Y-Cable
CD Manual/Utility
Quick Installation Guide
This guide covers only the most common situations. All detailed
information is described in the user manual
LevelOne
HVE-6501R:
Power Adapter
CD Manual/Utility
Quick Installation Guide
HVE-6601R:
Power Adapter
CD Manual/Utility
Quick Installation Guide
V1.0
Page1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LevelOne HVE-6501T
Summary of Contents for LevelOne HVE-6501T
- Page 1 LevelOne HVE-6501T/6501R HDMI over IP PoE Transmitter/Receiver HVE-6601T/6601R HDMI Video Wall over IP PoE Transmitter / Receiver V1.0 Quick Installation Guide Package Contents HVE-6501T: HVE-6501R: Power Adapter Power Adapter CD Manual/Utility CD Manual/Utility Quick Installation Guide Quick Installation Guide HVE-6601T:...
- Page 2 HVE-6501 Application: 1T+3R (Figure 1) HVE-6601 Application: 2T+4R (Figure 2) Page2...
- Page 3 Quick Installation on HVE-6501 : HVE-6501T Transmitter DC5V or PoE: Connect it to the external AC adapter which plugs into an electrical outlet. Or via 802.3af PoE PSE to GIGA LAN port. GIGA LAN: Connect directly to a Receiver or to a Gigabit IGMP Ethernet Switch using CAT5e/6 cable.
- Page 4 HVE-6501R Receiver DC5V/PoE: Connect to the supplied AC adapter and plug into an electrical outlet. Or via 802.3af PoE PSE to GIGA LAN port. GIGA LAN: Connect directly to a Transmitter or to a Gigabit IGMP Ethernet Switch using CAT5e/6 cable. HDMI OUT: Connect to an HDMI display device with an HDMI M-M cable.
- Page 5 Quick Installation on HVE-6601 : HVE-6601T Transmitter (Video Wall) DC5V/PoE: Connect it to the external AC adapter which plugs into an electrical outlet. Or via 802.3af PoE PSE to GIGA LAN port. GIGA LAN: Connect directly to a Receiver or to a Gigabit IGMP Ethernet Switch using CAT5e/6 cable.
- Page 6 HVE-6601R Receiver (Video Wall) DC5V/PoE: Connect to the supplied AC adapter and plug into an electrical outlet. Or via 802.3af PoE PSE to GIGA LAN port. GIGA LAN: Connect directly to a Transmitter or to a Gigabit IGMP Ethernet Switch using CAT5e/6 cable. HDMI OUT: Connect to an HDMI display device with an HDMI M-M cable.
- Page 7 Video Wall setting procedure (example 2x2) Prepare host(HVE-6601T) x 2 and client x 4(HVE-6601R). Follow “Figure 2” to construct the whole system. Reboot all devices. Ensure that all remote displays and all network cables are connected correctly. (Video source is required at this step) If the control PC (Windows OS) doesn’t install bonjour SDK yet, please install it.
- Page 8 Notice: How to get the best HDMI display results Many factors influence the quality and reliability of an HDMI® signal distribution installation. The following are the main factors to consider, and basic precautions that will ensure the best possible performance. 1.
