  • Page 1 1080P 3GSDI to 3GSDI Scaler GEF-3GSDI-2-3GSDIS User Manual www.gefenpro.com...
  • Page 3 ASKING FOR ASSISTANCE Technical Support: Telephone (818) 772-9100 (800) 545-6900 Fax (818) 772-9120 Technical Support Hours: 8:00 AM to 5:00 PM Monday through Friday, Pacific Time For 24 / 7 support, see the back of the product for the support number Write To: Gefen, LLC. c/o Customer Service 20600 Nordhoff St Chatsworth, CA 91311 www.gefenpro.com support@gefenpro.com Notice Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice. 3GSDI to 3GSDI Scaler is a trademark of Gefen, LLC HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing in the United States and other countries. © 2012 Gefen, LLC. All rights reserved. All trademarks are the property of their respective owners. Rev A1...

  • Page 4: Table Of Contents

    CONTENTS Introduction Operation Notes Features Panel Layout Panel Descriptions IR Remote Layout and Description IR Remote Control Installation Installing the Battery Setting the IR Channel Connecting The 3GSDI To 3GSDI Scaler Wiring Diagram Menu System General Menu 10 Patterns Menu 10 Output Menu 11 Input Menu 13 Picture Menu 15 Layout Menu 15 Aspect Menu 17 RS-232 Serial Control 18 RS-232 Commands 33 Supported Video and Graphics Formats 36 Rack Mount Safety Information 37 Mounting Plate Installation 38 Appendix A 38 Gamma LUT File Format...

  • Page 5: Introduction

    INTRODUCTION Congratulations on your purchase of the 3GSDI to 3GSDI Scaler. Your complete satisfaction is very important to us. GefenPRO In the realm of video distribution, certain features are invaluable in a commercial or broadcast environment. Accommodations such as a build-in power supply and flat black rack-mount enclosures set GefenPRO apart from our traditional products. Complex distribution units allow for professional DVI, 3G-SDI, and HDMI signals to be routed and converted easily and seamlessly, while being backed up by a renowned and dependable technical support team. Gefen invites you to explore the GefenPRO product line and hopes that you find the solution that fits your needs. The GefenPRO 3GSDI to 3GSDI Scaler The GefenPRO 3GSDI-2-3GSDIS provides high-performance scaling - including adjustable cadence detection, frame rate conversion, detail enhancement, and advanced noise reduction. It works with SDI, ED-SDI, HD-SDI, or 3G-SDI signals and supports resolutions up to 1080p Full HD and 2048 x 1080 (2K). This product can be used as a standalone frame synchronizer without scaling if desired. When frame synchronization is required, the video output of one source (or a reference signal) can be used to Genlock another input source. Genlock Mode, as well as all features of this scaler, can be controlled through the built-in menu system using the IR Remote Control or via RS-232 control. How It Works Connect SDI source devices to the SDI inputs and connect downstream equipment to the SDI outputs. Convenient SDI loop-through output connectors and an RCA Coax (S/PDIF) audio output allow monitoring of SDI video and audio. An external Genlock source may also be connected. Configuration may be done using the IR Remote and the On-Screen Display (OSD) menu, or via the RS-232 port. A USB port is also provided for future firmware upgrades.

  • Page 6: Operation Notes

    OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE 3GSDI TO 3GSDI SCALER • The built-in GUI (Graphical User Interface) or On-Screen Display (OSD) provides convenient operation of the Scaler. The supplied IR Remote control operates the OSD. See pages 9 - 16 for details on the OSD commands. • The IR Remote Control unit’s IR channel must be identical to that of the Scaler. See page 30 for details on configuring the IR Channel on the 3GSDI to 3GSDI Scaler. • The 3GSDI to 3GSDI Scaler supports many input and output resolutions. For a complete list of supported formats, see pages 33 - 35. • Supports SMPTE standards 259M, 292M, SMPTE 274M, SMPTE 296M, ITU-R BT.656 and ITU-R BT.601. Handles 3G-SDI SMPTE 425-A and 425-B / formats 1080p 50/59.94/60. • Internal software (firmware) may be upgraded via the built-in Serial or USB ports. Note that software updates performed on the USB port will be quicker due to its higher data transfer rate.

  • Page 7: Features

    FEATURES Features: • Digital audio output • Adjustable cadence detection • Advanced noise reduction and detail enhancement • Frame-rate conversion • Fully integrated sprite-based Menu System • Built-in pattern generator with Color Bars and Hatch Pattern • RS-232 Control • IR Remote Control (included) • Field-upgradeable firmware via USB port • Rack-mountable (rack ears included) Package Includes (1) GefenPRO 3GSDI to 3GSDI Scaler (1) IR Remote Control (1) AC Power Cord (1) Set of Rack Ears (1) Quick-Start Guide...

  • Page 8: Panel Layout

    PANEL LAYOUT...

  • Page 9: Panel Descriptions

    PANEL DESCRIPTIONS Receives signals from the included IR Remote Control unit. 3GSDI This LED will glow bright blue when 3GSDI signals are detected on the input. Power This LED will glow bright blue when the unit is powered. Connect a USB cable from a computer to this USB port when updating the firmware. Genlock Used to generator-lock (“genlock”) the video source with an external reference signal. Connect a BNC cable between the “genlock” device and the Genlock BNC connector. Coax Connect a Coax cable from this S/PDIF connector to an audio output device. In A, In B Connect BNC cables from the 3GSDI source to these connectors. Loop Out A, Loop Out B Connect BNC cables from these connectors to a local SDI monitoring display. The Loop Out connectors pass-through the source signal without any processing. Out A, Out B Connect BNC cables from these connectors to an SDI display. 10 Power Receptacle Connect the included AC power cord from this power receptacle to an available electrical outlet. 11 Power Switch Press this switch to power-on or power-off the scaler.

  • Page 10: Ir Remote Layout And Description

    IR REMOTE LAYOUT AND DESCRIPTIONS RMT-8HDS-IR 1. LED indicator - glows bright orange whenever a key is pressed, indicating the transmission of an IR command to the Scaler. The ENTER button activates a selected menu option in the On-Screen Display. LEFT direction key for menu navigation within the On-Screen Display. DOWN direction key for menu navigation within the On-Screen Display. Source - Cycles between available input sources. The selectable inputs are 3GSDI Input 1 and 3GSDI Input 2. Press once for Input 1; twice for Input 2. Output - Cycles through the available output resolutions. See pages 33 - 35 for a list of output resolutions. Menu - Displays the On-Screen Display menu system for control of the Scaler. RIGHT direction key for menu navigation within the On-Screen Display. UP direction key for menu navigation within the On-Screen Display.

  • Page 11: Ir Remote Control Installation

    Installing the Battery The Remote Control unit ships with two batteries. One battery is required for operation and the other battery is a spare. Remove the battery cover on the back of the IR Remote Control unit. Insert the included battery into the open battery slot. The positive (+) side of the battery should be facing up. Replace the battery cover. NOTE: An Activity Indicator that flashes quickly while holding down any one of the 8 buttons indicates a low battery. Replace the IR Remote Control battery as soon as possible. WARNING: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Channel 0 (default): Remote Channel 1: Remote Channel 2: Remote Channel 3: Battery slot DIP switches Setting the IR Channel The IR channel on the IR Remote Control must match the IR channel used by the 3GSDI to 3GSDI Scaler. For example, if both DIP switches on the IR Remote Control unit are set to IR channel 0 (both DIP switches down), then the 3GSDI to 3GSDI Scaler must also be set to IR channel 0. See page 30 for information on how to change the IR channel on the 3GSDI to 3GSDI Scaler.

  • Page 12: Connecting The 3Gsdi To 3Gsdi Scaler

    CONNECTING THE 3GSDI TO 3GSDI SCALER How to Connect the 3GSDI to 3GSDI Scaler Connect a 3GSDI source to the In A connector on the 3GSDI to 3GSDI Scaler. Connect the Out A port on the back of the Scaler to a 3GSDI display. The 3GSDI destination cab be mirrored by connecting a BNC cable from the Out B port to a secondary 3GSDI display. NOTE: In order to output dual link 1080p when using HD-SDI, both the Out A and Out B must be connected to the 3GSDI display. Connect a coax cable from the S/PDIF output to an external amplifier. If monitoring of the 3GSDI source is desired, connect a BNC cable from the Loop Out A connector to the 3GSDI display. The Loop Out connectors pass-through the source signal without any processing. Connect the included AC power cord from the power receptacle to an available electrical outlet. Power the 3GSDI to 3GSDI Scaler by pressing the power switch on the rear of the unit. Wiring Diagram for the 3GSDI to 3GSDI Scaler RS-232 CABLE S/PDIF CABLE...

  • Page 13: Menu System

    MENU SYSTEM General Menu Information To access the General Menu, press the Menu button on the IR Remote Control Unit. The General Menu will be the first menu displayed on contains information about the Scaler: • Host Firmware Version • Kernel Version • Configuration Version • FPGA Version • Remote Channel General > Language From the General Menu, press the ▼ button on the IR Remote Control Unit. Select the Language using the ► and ▼ buttons on the IR Remote Control Unit. Press the Menu button to exit the menu system. • English • French General > Save Configuration The Save Configuration feature is used to save the current configuration of the Scaler. Once the current configuration is saved, these settings will be restored each time the Scaler is powered. WARNING: This function will overwrite any previously saved configuration, including the factory default settings. To restore the factory default settings, press the following buttons in order: Left, Right, and OK buttons. Do not depress all three buttons simultaneously. General > Restore Default Configuration Restores the Scaler to factory default settings. Use this feature to restore default configu- rations if they have been overwritten by using the Save Configuration function.

  • Page 14: Patterns Menu

    MENU SYSTEM Patterns Menu Patterns > Color Bars Produces a color bar pattern, similar to a standard SMPTE bar pattern used for color calibration. Patterns > Hatch Pattern Produces a cross hatch pattern. This pattern can be used for “pin cushion” testing (curvature of the image on the screen) or color convergence / divergence. NOTE: When a pattern is produced, the current video image will be masked. Output Menu The 3GSDI output signal can be configured from the Output menu. The Output menu controls several functions, such as resolution, link configuration (single link or dual link), genlock reference, and genlock offset. Output > Output Format Selects the output resolution. See pages 33 - 35 for details on available output formats. Output > Link Configuration Selects the link configuration in respect to color space. When using dual link SDI or HD- SDI input, YCbCr or RGB can be selected. If 3G-SDI is used, A or B (4:2:2 only) can be selected. • Single Link YCbCr 4:2:2 (SD/HD/3G) • Single Link 1080p (3G Level B) •...

  • Page 15: Input Menu

    MENU SYSTEM Output > Genlock Reference This option enables or disabled the automatic genlock mode. • Disabled genlock • Video Input Uses the video input as the reference clock. • Ref Input Uses the clock attached to the Ref In connector on the back of the unit. Output > Genlock Offset This option provides the option to adjust the output lines and output pixels. • Output Lines • Output Pixels Input Menu Input > Input Video Format Selects the resolution and timing of the input format. By default, this is set to Auto Detect which automatically senses the resolution and timing of the input signal. The available resolutions under this menu are in SD and HD format. Input > Graphic Format Selects the resolution and timing of the input format. By default, this is set to Auto Detect which automatically senses the resolution and timing of the input signal. The available resolutions under this menu are in VESA format.
  • Page 16 MENU SYSTEM Input > Clean Aperture Allows adjustment of the input signal position. The clean aperture parameters allow an area within the production aperture to be defined. The minimum clean aperture size is 0 pixels by 0 lines. • Horizontal Size Adjusts the horizontal size of the image. • Vertical Size Adjusts the vertical size of the image. • Horizontal Position Adjusts the horizontal position of the image. • Vertical Position Adjusts the vertical position of the image. Input > Film Mode Automatically detects repeated field sequences present in interlaced signals, such as: 50 Hz or 60 Hz field sequences (no repeated fields), 60 Hz 3:2 pull-down, including broken / edited sequence detection, 60 Hz 2:2: pull-down, 50 Hz 2:2 pull-down, and Freeze frame. • Enable • Disable Input > Remote Channel This option changes the IR channel of the 3GSDI to 3GSDI Scaler to one of 4 different settings between 0 and 3. When the remote channel of the Scaler is changed, the DIP switches in the eight-button remote must be changed to the corresponding IR channel in order to operate the Scaler (see IR Remote Control Installation on page 7 for more information).

  • Page 17: Picture Menu

    MENU SYSTEM Input > Input Color Range The RGB output color range may be changed/set to limited (16-235) or to full (0-255). • Auto Uses the color range of the input signal. • 16 - 235 (Pass through) The input color range will be compressed from full-range (0 - 255) to limited-range. • 0 - 255 (Compress) The output color range will be expanded from limited-range (16 - 235) to full-range (0 - 255). Picture Menu Picture > Image Color Allows individual adjustment of the Red, Green, and Blue color components, brightness, and Black Level of the image. • Adjusts the saturation of the Red color component. • Green Adjusts the saturation of the Green color component. • Blue Adjusts the saturation of the Blue color component. • Brightness Red Adjusts the brightness of the Red color component. • Brightness Green Adjusts the brightness of the Green color component.
  • Page 18 MENU SYSTEM Picture > Gamma Correction • Default Sets the default Gamma settings. • sRGB Gamma correction used with PCs, cameras, and printers. • User Table This option is used with a user Gamma LUT. See pages 38 for details on using a Gamma Look Up Table. • Custom Table Use when defining a custom LUT. See pages 38 for details on using a Gamma Look Up Table. • Gamma Coeffecient Adjusts the Gamma coeffecient in the range from 0.3 to 3.0. The default Gamma value is 1.0. NOTE: When the Custom LUT (Look Up Table) is selected, the Gamma coefficient is used to calculate a new Gamma LUT. Picture > Detail Enhancement These parameters processes the input data in either progressive or interlaced format. Changes to the detail enhancement are implemented at the start of the next frame of video. Both of these parameters can be adjusted within the range or 0 - 100. • Detail Enhancement • Noise Threshold Picture >...

  • Page 19: Layout Menu

    MENU SYSTEM Layout Menu Layout > Size and Position Set the size and the position of the image. Note that this option is not available in the panoramic aspect mode. • Horizontal Size Sets horizontal size of the output signal. • Vertical Size Sets vertical size of the output signal. • Horizontal Position Sets horizontal position of the output signal. • Vertical Position Sets vertical size of the output signal. Aspect Menu Aspect > Full Screen Stretches the output signal to fill the display. Aspect > Letter / Pillar Box Sets the aspect ration to fit a letter or pillar box format.
  • Page 20 MENU SYSTEM Aspect > Extract This a function allows the Scaler to zoom in on a subset of the input video signal. This feature allow you to zoom on one selected section of the input picture. • Extract Size Selects the size of the subset to be extracted in percentage of the input. • Horizontal Position Moves the picture left or right (within the original input full size input). • Vertical Position Moves the picture up or down (within the original input full size input). Aspect > Through This function defines a sub-window that is always centered on the screen. The position is the relative position of the window within the full picture. This feature allow you to display one selected section of the input picture without modifying its size. • Horizontal Size Adjusts the size of the sub-window horizontally. • Vertical Size Adjusts the size of the sub-window vertically. • Horizontal Position Horizontally adjusts the relative position of the window within the full picture. • Vertical Position Vertically adjusts the relative position of the window within the full picture. NOTE: When changing the input format, the Scaler will try and apply the current settings to the new input format. If this is not possible (e.g. the value is beyond the zoom limit), then the default value (100% size) will be used.
  • Page 21 RS-232 SERIAL CONTROL DE-9 Connector DE-9 DA-15 RS-232 Controller Scaler TXD TXD DB-25 Only TXD, RXD, and GND are used. DC-37 RS232 Settings Baud rate ........................115200 Data bits ..........................8 Parity bits ........................None DD-50 Stop bits ..........................1 Flow Control ........................None IMPORTANT: When sending RS-232 commands, a carriage return must be included at the end of the command. A space must be included between the command and the parameter.

  • Page 22: Rs-232 Commands

    RS-232 COMMANDS Function Description #aspect Sets the aspect ratio of the output signal #autolock Enables or disables the automatic genlock mode #blacklev Sets the black level (RGB/Y) of the output signal #bright Sets the brightness value for a specific color #cleanaper Sets the clean aperture level for position and size #contrast Sets the contrast level for a specific color Sets the enhancement value #enhance #extract Sets the extract aspect mode #filmmode Enables / disables film mode #gamma Sets the Gamma correction mode #help Lists all available commands Sets the input format of the image #input #key Execute the remote button actions as a string #language Sets the current language of the OSD #linkconfin Changes the input link configuration #linkconfout Changes the output link configuration Displays a list of all available commands on this Scaler #list #motionthres Sets the intraframe motion detection threshold #noisereduc Sets the noise reduction value #noisethres...
  • Page 23 RS-232 COMMANDS #aspect Command The #aspect command sets the aspect ratio of the output signal. Syntax: #aspect param1 Parameters: param1 IR channel [1 ... 5] Value Meaning Full Screen Letter / Pillar Box Panoramic Extract (Uses default value) Through (Uses default Value) Notes: If the Extract or Through mode is selected, the default values are set. To modify the param- eters for Extract or Through mode refer to these commands in this manual.
  • Page 24 RS-232 COMMANDS #autolock Command The #autolock command enables / disables the Auto Genlock Mode. The Syntax: #autolock param1 Parameters: param1 IR channel [0 ... 2] Value Meaning Disable (Default value) Video Input Reference Reference Input #blacklev Command The #blacklev command sets the black level (RGB/Y) of the output signal. The default value is 0. Syntax: #blacklev param1 Parameters: param1 Level value [0 ... 1023]...
  • Page 25 RS-232 COMMANDS #bright Command The #bright command sets the brightness value for a specific color. The default value for param2 is 50. Syntax: #bright param1 param2 Parameters: param1 Color name [0 ... 2] Value Meaning Green Blue param2 Color value [0 ... 100] #cleanaper Command The #cleanaper command sets the clean aperture level for each position and size. The default value for param1 and param2 is 100. The default value for param3 and param4 is 50. Syntax: #cleanaper param1 param2 param3 param4 Parameters: Horizontal size [1 ... 100] param1 param2 Vertical size [1 ... 100] param3 Horizontal position [1 ... 100] param4...
  • Page 26 RS-232 COMMANDS #contrast Command The #contrast command sets the contrast level for a specific color. The default value for param2 is 50. Syntax: #CONTRAST param1 param2 Parameters: param1 Color name [0 ... 2] Value Meaning Green Blue param2 Contrast value [0 ... 100] #enhance Command The #enhance command sets the enhancement value. The default value is 0. Syntax: #enhance param1 Parameters: param1 Enhancement value [0 ... 100]...
  • Page 27 RS-232 COMMANDS #extract Command The #extract command sets the extract aspect mode. The default value for param1 is 100. The default value for param2 and param3 is 50. Syntax: #extract param1 param2 param3 Parameters: param1 Extract size percentage [1 ... 100] param2 Horizontal position [1 ... 100] Vertical position [1 ... 100] param3 #filmmode Command The #filmmode command enables / disables film mode. The default value is 0. See page 12 for more information on film mode. Syntax: #filmmode param1 Parameters: param1 Value [0 ... 1] Value Meaning Disable Enable...
  • Page 28 RS-232 COMMANDS #gamma Command The #gamma command sets the gamma correction mode. Syntax: #gamma param1 param2 Parameters: param1 Gamma correction mode [0 ... 3] Value Meaning Default sRGB Custom User table param2 Mode [1, 3 ... 30] Value Meaning 3 - 30 Set for Custom mode Set for User table Notes: If the Custom mode is used (param1 = 2), then set the gamma coefficient value in the sec- ond parameter. The default value is 1. If User Table is used, then set the second param- eter to 1 to set the user table currently saved in EEPROM memory. To write a new gamma LUT (Look-Up Table) file, you must use the updater with the following command: updater %comport% GAMMA [filename].csv If the Default or sRGB modes are used, then set the second parameter to 0. See page 38 for more information on using the gamma LUT format.
  • Page 29 RS-232 COMMANDS #help Command The #help command displays the list of available RS-232 commands. Syntax: #help Parameters: None #input Command The #input command sets the input format of the image. Refer to the Supported Video and Graphics Formats table on pages 33 - 35. Syntax: #input param1 Parameters: param1 Input format [see format table]...
  • Page 30 RS-232 COMMANDS #key Command The #key command simulates the pressing of buttons on the IR Remote Control unit by spooling the name or the key (as a string) to the serial port. The full name of the button may be specified or the first letter of the button. Only one button can be specified at a time. Syntax: #key param1 Parameters: param1 Value [String] Value Meaning menu (or m) Menu button up (or u) Up button down (or d) Down button left (or l) Left button right (or r) Right button enter (or e) Enter button source (or s) Source button output (or o) Output button Examples: The following are equivalent commands that simulate pressing the Menu button on the IR Remote Control unit: #key menu #key m...
  • Page 31 RS-232 COMMANDS #language Command The #language command sets the current language of the built-in menu system. Syntax: #language param1 Parameters: param1 Language [0 ... 1] Value Meaning English French #linkconfin Command The #linkconfin command changes the input link configuration. The default value for param1 is 0. Syntax: #linkconfin param1 Parameters: param1 Mode [0 ... 3] Value Meaning Single Link Dual Link YCbCr (4:4:4) Dual Link RGB (4:4:4) Dual Link 1080p/576p/480p...
  • Page 32 RS-232 COMMANDS #linkconfout Command The #linkconfout command changes the output link configuration. The default value for param1 is 0. Syntax: #linkconfout param1 Parameters: param1 Mode [0 ... 3] Value Meaning Single Link Dual Link YCbCr (4:4:4) Dual Link RGB (4:4:4) Dual Link 1080p/576p/480p #list Command The #list command displays the list of all the available commands that can be executed on the serial port. It also gives the number of parameters that each command requires. Syntax: #list Parameters: None #motionthres Command The #motionthres command sets the motion threshold value. The default value of param1 is 4. Syntax: #motionthres param1 Parameters: param1 Value [0 ... 15]...
  • Page 33 RS-232 COMMANDS #noisereduc Command The #noisereduc command sets the noise reduction value. The default value for param1 is 0. Syntax: #noisereduc param1 Parameters: param1 Value [0 - 100] #noisethres Command The #noisethres command sets the noise threshold. The default value for param1 is 0. Syntax: #noisethres param1 Parameters: param1 Value [0 ... 100] #output Command The #output command sets the output format of the image. Refer to the Supported Video and Graphics Formats table on pages 33 - 35. Syntax: #output param1 Parameters: param1 Value [see output table]...
  • Page 34 RS-232 COMMANDS #pattern Command The #pattern command selects the test patter image on the output port. Syntax: #pattern param1 Parameters: param1 Pattern [0 ... 3] Value Meaning No pattern Color bar Cross hatch #rb Command The #rb command resets the 3GSDI to 3GSDI Scaler. Syntax: Parameters: None #remotechan Command The #remotechan command sets the IR remote control channel. Syntax: #remotechan param1 Parameters: param1 Channel [0 ... 3]...
  • Page 35 RS-232 COMMANDS #restore Command The #restore command restores all of the default parameters. Syntax: #restore Parameters: None #save Command The #save command saves all the current parameters in the PROM. These parameters will be reloaded upon the next boot-up. Syntax: #save Parameters: None #sizepos Function The #sizepos command sets the size and the position of the image. This option is not available in the panoramic aspect mode. Syntax: #sizepos param1 param2 param3 param4 Parameters: param1 Horizontal size [1 ... 100] param2 Vertical size [1 ... 100] param3 Horizontal position [0 ... 100] Vertical position [0 ... 100] param4 Note: The default value for param1 is the current horizontal resolution.
  • Page 36 RS-232 COMMANDS #through Function The #through command defines a sub-window that is always centered on the screen. The position is the relative position of the window within the full picture. This feature allow you to display one selected section of the input picture without modifying its size. Syntax: #through param1 param2 param3 param4 Parameters: param1 Horizontal size [1 ... 100] Vertical size [1 ... 100] param2 param3 Horizontal position [0 ... 100] param4 Vertical position [0 ... 100] #version Function The #version command returns the version of the Host Firmware, the Kernel and the configuration (in that order). Syntax: #version Parameters: None...

  • Page 37: Supported Video And Graphics Formats

    SUPPORTED VIDEO AND GRAPHICS FORMATS Supported Video and Graphics Formats The following table contains all supported video and graphic formats supported by the GefenPRO 3GSDI to 3GSDI Scaler. The Value column are parameters used by the RS-232 #output command (see page 29). Input Output Format Value Format Value 480i 480i 480p @ 59.94 480p @ 59.94 576i 576p @ 50 576p 720p @ 23.98 720p @ 23.9 720p @ 24 720p @ 24 720p @ 25 720p @ 25 720p @ 29.97 720p @ 29.97 720p @ 30 720p @ 30 720p @ 50 720p @ 50 720p @ 60 720p @ 60 720p @ 59.94...
  • Page 38 SUPPORTED VIDEO AND GRAPHICS FORMATS Input Output Format Value Format Value 1080sf @ 24 2K-p @ 24 1080sf @ 25 640 x 350 @ 85 1080sf @ 29.97 640 x 400 @ 85 1080sf @ 30 640 x 480 @ 60 2K-p @ 23.98 640 x 480 @ 75 2K-p @ 24 640 x 480 @ 85 2K-sf @ 23.98 800 x 600 @ 60 2K-sf @ 24 800 x 600 @ 75 Auto Detect 800 x 600 @ 85 640 x 350 @ 85 1024 x 768 @ 60 640 x 400 @ 85 1024 x 768 @ 75 640 x 480 @ 60 1024 x 768 @ 85 640 x 480 @ 75 1280 x 854 640 x 480 @ 85 1152 x 864 @ 75 800 x 600 @ 60 1280 x 768 @ 60 800 x 600 @ 75 1280 x 960 @ 60...
  • Page 39 SUPPORTED VIDEO AND GRAPHICS FORMATS Input Output Format Value Format Value 1600 x 1024 1600 x 1200 @ 60 1600 x 1200 @ 65 1600 x 1200 @ 70 1600 x 1200 @ 75 1680 x 1050 @ 60 1920 x 1200 @ 60 2048 x 1080...

  • Page 40: Rack Mount Safety Information

    RACK MOUNT SAFETY INFORMATION Maximum recommended ambient temperature: 45 ˚C Increase the air flow to maintain the temperature inside the rack. Install the product evenly to avoid mechanical overload.

  • Page 41: Mounting Plate Installation

    MOUNTING PLATE INSTALLATION Rack mount ears are provided for installation of this unit into a 1U rack mount space. Locate the side screws on the unit. Remove the front 2 screws that are located closest to the front of the unit. Using the removed screws, screw the rack mounting bracket into the unit. Repeat the procedure on the opposite side of the unit. Front of unit Rear of unit...

  • Page 42: Gamma Lut File Format

    APPENDIX A Gamma LUT File Format The Gamma Look Up Table can be programmed using the GefenUpdater.exe program from the Gefen software package. To do this, following the instructions below: Create the Gamma LUT. Create a standard ASCII text file with the following line: GefenUpdater GAMMA filename.csv where filename.csv is the name of the Gamma LUT file. Save the file as UpdateGamma.bat. Make sure that the GefenUpdater.exe file resides in the same directory (or is in the path) as the UpdateGamma.bat file. Connect a USB cable from the computer to the HD to 3GSDI Scaler. Power on the HD to 3GSDI Scaler. Once the Scaler has powered up, run the UpdateGamma.bat file. The LUT is a standard .CSV file. Each line contains Red, Green and Blue values separate by comma ”,”. A value must be between 0 and 1023. A file must contain 1024 lines: 1023,0,0 (Line 1) 1023,0,0 1023,0,0 1023,0,0 1023,0,0 1023,0,0 1023,0,0 … … 1023,0,0 (Line 1024)

  • Page 43: Specifications

    SPECIFICATIONS Input Video Bandwidth..................2 x 2.97 Gbps Output Video Bandwidth................... 2 x 2.97 Gbps SDI Inputs...................... (2) BNC, female SDI Outputs....................(2) BNC, female Genlock Input....................(1) BNC, female Digital Audio S/PDIF Output................(1) RCA, female USB Port....................(1) Type B, female RS-232 Port....................(1) DB-9, female AC Inlet........................ (1) IEC type Power Supply.................... 110/220V (internal) Dimensions (W x H x D)....... 16.8” x 1.75” x 7” (428mm x 44.5mm x 178mm) Shipping Weight....................6 lbs (2.72 kg)

  • Page 44: Warranty

    WARRANTY Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notified within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications. Equipment that fails under conditions other than those covered will be repaired at the current price of parts and labor in effect at the time of repair. Such repairs are warranted for ninety (90) days from the day of reshipment to the Buyer. This warranty is in lieu of all other warranties expressed or implied, including without limitation, any implied warranty or merchantability or fitness for any particular purpose, all of which are expressly disclaimed. Proof of sale may be required in order to claim warranty. Customers outside the US are responsible for shipping charges to and from Gefen. Copper cables are limited to a 30 day warranty and cables must be in their original condition. The information in this manual has been carefully checked and is believed to be accurate. However, Gefen assumes no responsibility for any inaccuracies that may be contained in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. The technical information contained herein regarding the features and specifications is subject to change without notice. For the latest warranty coverage information, refer to the Warranty and Return Policy under the Support section of the Gefen Web site at www.gefen.com. PRODUCT REGISTRATION Please register your product online by visiting the Register Product page under the Support section of the Gefen Web site.
  • Page 48 Rev A1 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefenpro.com support@gefenpro.com...
