Page 1: User Manual
User Manual CATx Style KVM Switch 1U KVM Switch with CATx Connections Options : » KVM Over IP » Remote Console » 8, 16, or 32 port » Single or Multi-User... -
Page 2: Table Of Contents
Contents Safety Notice 1 Product Overview 1-1 Package Content (Standalone KVM) 1-2 Package Content (Integrated KVM) 1-3 CATx Style KVM Table 2 Installation 2-1 Before Installation 2-2 Unpacking the Unit 2-3 Installation Instructions (Standalone KVM) 2-4 KVM Port & CATx Dongle Connection 2-5 Cascading the KVM 2-6 Local and Remote Console Diagram 2-7 Connecting a Remote Console... -
Page 3: Safety Notice
Safety Notice Please read the following before using your Raloy unit: ■ Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth. ■ Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with temperatures not exceeding 40º... -
Page 4: Product Overview
1 Product Overview 1-1 Package Content (Standalone KVM) ■ 1 x KVM Unit ■ 1 x Mounting set w/ bracket & screws KVM unit ■ 1 x Power cord (for KVM) Local console KVM with Remote User ■ 1 x KVM Unit ■... -
Page 5: Catx Style Kvm Table
1-3 CATx Style KVM Table www.Raloy.com/support/downloads.html Multi-User Matrix Part Numbers Concurrent Users Local Remote Ports CATx21016* CATx21032* CATx31116* CATx31132* CATx32016* CATx32032* CATx42116* CATx42132* CATx41216* CATx41232* CATx43016* CATx43032* Single User Part Numbers Concurrent Users Local Remote Ports CATx10008* CATx10016* CATx10032* CATx10108*... -
Page 6: Installation
2-2 Unpacking the Unit The equipment comes with the standard parts shown in package content. Check and make sure they are included and in good condition. If anything is missing, or damaged, contact Raloy immediately. 2-3 Installation Instructions (Standalone KVM) Step ■... -
Page 7: Kvm Port & Catx Dongle Connection
2-4 KVM Port & CATx Dongle Connection USB Servers RDG-100SD DVI-USB dongle CAT 5 / 6 cable max. 40 meters DVI-D Cat6 KVM port PS/2 Servers USB Servers RDG-100S RDG-100 PS/2 VGA-USB dongle VGA-PS/2 dongle CAT 5 / 6 cable max. -
Page 8: Cascading The Kvm
2-5 Cascading the KVM Raloy KVMs CATx10008 / CATx10016 / CATx10032 can be cascaded. ■ Cascade up to 8 levels (256 servers max) ■ Cascade multiple KVM Switches with RCBC-6 cascade cable. RCBC-6 ■ 6ft Combo KVM cascade cable Master KVM... -
Page 9: Local And Remote Console Diagram
2-6 Local and Remote Console Diagram... -
Page 10: Connecting A Remote Console
2-7 Connecting a Remote Console Receiver Local Computer Monitor Remote I/O Front Power Rear Local Remote Mouse Button Button KVM switch The receiver provides a hotkey function for remote console. Monitor Remote Console RCE-6 Cat6 cable Local computer Combo cable up to 150m ( Optional setup ) KVM cable... -
Page 11: Operation
3 Operation 3-1 KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Power ON sequence 1. Turn on Rack Monitor (if applicable) 2. Turn on KVM switch 3. -
Page 12: Password
3-2 Password The password is enabled by default. The default password is “00000000” (Do not use “0” on number pad) ■ Enable password 1. Press the KVM hotkey Scroll Lock + Scroll Lock + U 2. Logout of the KVM by pressing the hotkey Scroll Lock + Scroll Lock + P 3. -
Page 13: On-Screen Display (Osd)
3-3 On-Screen Display (OSD) OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout of the OSD menu Previous menu Cancel / Quit Enter Complete / Switch to selected port Switch to previous or next port... -
Page 14: Ip Operations
3-4 IP Operations Please refer to the IP Manual for information on how to set-up and use the IP functions on compatible Raloy KVM Switches. The IP Manual can be found at www.Raloy.com/files/Raloy-KVM-IP-Manual.pdf 3-5 Hotkeys for KVM & Remote Console... -
Page 15: Product Specifications
4 Product Specifications 4-1 Specifications Table Product Information Dimensions (W x D x H) 443 x 171 x 90 mm (17.4 x 6.7 x 1.73 in.) Gross Weight 6.5 lbs / 3 kg Packaging Information Dimensions (W x D x H) 500 x 400 x 90 mm (19.7 x 15.7 x 3.5 in.) Gross Weight 11 lbs / 5 kg... -
Page 16: Resolution Support Information
4-2 Resolution Support Information Max 4:3 LCD Max 16:10 LCD Remote console 1600 x 1200 1440 x 900 Local console 1600 x 1200 1440 x 900 IP console 1600 x 1200 Cat6 Dongle EDID Resolution Resolutions Capable Hard-coded 16:10 1024 x 768 1280 x 1024 1600 x 1200 1440 x 900... -
Page 17: Important Information
IV. Raloy Extended Warranty Raloy also provides the option to extend your warranty service up to 60 Months, please contact our sales at sales@raloy.com for more warranty service and upgrade details. Disclaimer of Warranty... -
Page 18: What The Warranty Does Not Cover
The company reserves the right to modify product specifications without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2014 Raloy. All rights reserved.
