Switch 3300 XM —
Front View Detail
1x
13x
10BASE-T / 100BASE-TX Ports
10BASE-T/
100BASE-TX Ports

LEDs

Figure 1 Switch 3300 XM — front view
6x 7x
18x 19x
The Switch has 24 auto-negotiating 10BASE-T/100BASE-TX ports
configured as MDIX (cross-over). These ports can be set to 10BASE-T half
duplex, 10BASE-T full duplex, 100BASE-TX half duplex, 100BASE-TX full
duplex, or they can automatically detect the speed and duplex mode of a
link and provide the appropriate connection. The maximum segment
length is 100m (328ft) over Category 5 twisted pair cable.
As these ports are configured as MDIX (cross-over), you need to use a
cross-over cable to connect to devices whose ports are MDIX-only. See
"Choosing the Correct Cables"
Table 3 (overleaf) lists the LEDs visible on the front of the Switch, and
their states according to color. For information on using the LEDs for
problem solving, see
Switch 3300 XM — Front View Detail
10BASE-T / 100BASE-TX
12x
green = enabled, link OK
flashing green = disabled, link OK
1 2 3 4 5 6 7 8 9 10 11 12 Packet
1 2 3 4 5 6 7 8 9 10 11 12 Status
13 14 15 16 17 18 19 20 21 22 23 24 Packet
13 14 15 16 17 18 19 20 21 22 23 24 Status
24x
Port Status LEDs
on page 30
"Solving Problems Indicated by LEDs"
Unit
1 2
3 4
5 6
Power/Self Test
®
SuperStack II
7 8
Switch 3300 XM
Power / Self Test LED
Unit LED
for more information.
on page
13
31.
