Related Manuals for Husqvarna 1153177-26
Summary of Contents for Husqvarna 1153177-26
- Page 1 Operator′s manual 395XP, 395XPG Please read the operator’s manual carefully and make sure you understand the instructions before using the machine. E E E E n n n n g g g g l l l l i i i i s s s s h h h h...
-
Page 2: Symbols On The Machine
Symbols on the machine: WARNING! Chain saws can be dangerous! Careless or incorrect use can result in serious or fatal injury to the operator or others. Please read the operator’s manual carefully and make sure you understand the instructions before using the machine. -
Page 3: Table Of Contents
Contents KEY TO SYMBOLS Symbols on the machine: ... 2 Symbols in the operator’s manual: ... 2 CONTENTS Contents ... 3 INTRODUCTION Dear Customer, ... 4 WHAT IS WHAT? What is what on the chain saw? ... 5 GENERAL SAFETY PRECAUTIONS Before using a new chain saw ... -
Page 4: Introduction
Congratulations on your choice to buy a Husqvarna product! Husqvarna is based on a tradition that dates back to 1689, when the Swedish King Karl XI ordered the construction of a factory on the banks of the Husqvarna River, for production of muskets. -
Page 5: What Is What
10 Stop switch (Ignition on/off switch.) 11 Fuel tank 12 Muffler 13 Bar tip sprocket 14 Chain 15 Bar WHAT IS WHAT? Husqvarna XXXX XXXX XXXXXXX Husqvarna AB Huskvarna, SWEDEN 16 Spike bumper 17 Chain catcher (Catches chain if it jumps or breaks.) -
Page 6: General Safety Precautions
GENERAL SAFETY PRECAUTIONS Before using a new chain saw • Please read this manual carefully. • Check that the cutting equipment is correctly fitted and adjusted. See instructions under the heading Assembly. • Refuel and start the chain saw. See the instructions under the headings Fuel Handling and Starting and Stopping. -
Page 7: Always Use Common Sense
GENERAL SAFETY PRECAUTIONS Always use common sense It is not possible to cover every conceivable situation you can face when using a chain saw. Always exercise care and use your common sense. Avoid all situations which you consider to be beyond your capability. If you still feel uncertain about operating procedures after reading these instructions, you should consult an expert before continuing. - Page 8 GENERAL SAFETY PRECAUTIONS • The chain brake (A) can either be activated manually (by your left hand) or automatically by the inertia release mechanism. • The brake is applied when the front hand guard (B) is pushed forwards. • This movement activates a spring-loaded mechanism that tightens the brake band (C) around the engine drive system (D) (clutch drum).
-
Page 9: Chain Catcher
GENERAL SAFETY PRECAUTIONS of the front hand guard, the chain brake can only be activated by the inertia action. Will my hand always activate the chain brake during a kickback? No. It takes a certain force to move the hand guard forward. -
Page 10: Cutting Equipment
GENERAL SAFETY PRECAUTIONS Vibration damping system Your machine is equipped with a vibration damping system that is designed to minimize vibration and make operation easier. The machine′s vibration damping system reduces the transfer of vibration between the engine unit/cutting equipment and the machine′s handle unit. The body of the chain saw, including the cutting equipment, is insulated from the handles by vibration damping units. - Page 11 To maintain the safety features of the cutting equipment, you should replace a worn or damaged bar or chain with a bar and chain combinations recommended by Husqvarna. See instructions under the heading Technical Data for a list of replacement bar and chain combinations we recommend.
-
Page 12: Sharpening Your Chain And Adjusting Depth Gauge Setting
GENERAL SAFETY PRECAUTIONS Chain • Chain pitch (inches) • Drive link width (mm/inches) • Number of drive links. Sharpening your chain and adjusting depth gauge setting General information on sharpening cutting teeth • Never use a blunt chain. When the chain is blunt you have to exert more pressure to force the bar through the wood and the chips will be very small. -
Page 13: Tensioning The Chain
GENERAL SAFETY PRECAUTIONS • File all the teeth to the same length. When the length of the cutting teeth is reduced to 4 mm (0.16") the chain is worn out and should be replaced. General advice on adjusting depth gauge setting •... -
Page 14: Lubricating Cutting Equipment
GENERAL SAFETY PRECAUTIONS Lubricating cutting equipment WARNING! Poor lubrication of cutting equipment may cause the chain to snap, which could lead to serious, even fatal injuries. Chain oil Chain oil must demonstrate good adhesion to the chain and also maintain its flow characteristics regardless of whether it is warm summer or cold winter weather. - Page 15 GENERAL SAFETY PRECAUTIONS Chain drive sprocket The clutch drum is fitted with one of the following drive sprockets: A Spur sprocket (the chain sprocket is welded on the drum) B Rim sprocket (replaceable) Regularly check the degree of wear on the drive sprocket. Replace if wear is excessive.
-
Page 16: Assembly
Fitting the bar and chain WARNING! Always wear gloves, when working with the chain. Check that the chain brake is in disengaged position by moving the front hand guard towards the front handle. Remove the bar nuts and remove the clutch cover (chain brake). -
Page 17: Fuel Handling
When working with continuous high revs (e.g. limbing) a higher octane is recommended. Environment fuel HUSQVARNA recommends the use of alkylate fuel, either Aspen two-stroke fuel or environmental fuel for four-stroke engines blended with two-stroke oil as set out below. Note... -
Page 18: Fuelling
Fuelling WARNING! Taking the following precautions, will lessen the risk of fire: Do not smoke and do not place any hot objects in the vicinity of fuel. Always stop the engine and let it cool for a few minutes before refuelling. When refuelling, open the fuel cap slowly so that any excess pressure is released gently. -
Page 19: Starting And Stopping
Starting and stopping WARNING! Note the following before starting: Never start a chain saw unless the bar, chain and all covers are fitted correctly. Otherwise the clutch can come loose and cause personal injuries. Place the machine on firm ground. Make sure you have a secure footing and that the chain cannot touch anything. -
Page 20: Starting And Stopping
unnecessary wear to the clutch, clutch drum and brake band. WARNING! Long term inhalation of the engine’s exhaust fumes, chain oil mist and dust from sawdust can represent a health risk. • Never start a chain saw unless the bar, chain and all covers are fitted correctly. -
Page 21: Working Techniques
Before use: Check that the chain brake works correctly and is not damaged. Check that the rear right hand guard is not damaged. Check that the throttle lockout works correctly and is not damaged. Check that the stop switch works correctly and is not damaged. -
Page 22: General Rules
Before moving your chain saw switch off the engine and lock the chain using the chain brake. Carry the chain saw with the bar and chain pointing backwards. Fit a guard to the bar before transporting the chain saw or carrying it for any distance. When you put the chain saw on the ground, lock the saw chain using the chain brake and ensure you have a constant view of the machine. -
Page 23: Basic Cutting Technique
ladder, in a tree or where you do not have firm ground to stand on. Always use a fast cutting speed, i.e. full throttle. Take great care when you cut with the top edge of the bar, i.e. when cutting from the underside of the object. This is known as cutting on the push stroke. - Page 24 Two factors decide whether the chain will jam or the object that you are cutting will split: the first is how the object is supported before and after cutting, and the second is whether it is in tension. In most cases you can avoid these problems by cutting in two stages;...
-
Page 25: Tree Felling Technique
Tree felling technique IMPORTANT! It takes a lot of experience to fell a tree. Inexperienced users of chain saws should not fell trees. Do not attempt any task that you feel unsure of! Safe distance The safe distance between a tree that is to be felled and anyone else working nearby is at least 2 1/2 tree lengths. - Page 26 Felling WARNING! Unless you have special training we advise you not to fell trees with a diameter larger than the bar length of your saw! Felling is done using three cuts. First you make the directional cuts, which consist of the top cut and the bottom cut, then you finish with the felling cut.
-
Page 27: How To Avoid Kickback
There are methods for felling trees with a diameter larger than the bar length. However these methods involve a much greater risk that the kickback zone of the bar will come into contact with the tree. Freeing a tree that has fallen badly Freeing a ”trapped tree”... - Page 28 Kickback always occurs in the cutting plane of the bar. Normally the chain saw and bar are thrown backwards and upwards towards the user. However, the chain saw may move in a different direction depending on the way it was being used when the kickback zone of the bar touched the object.
-
Page 29: Maintenance
Contact your servicing dealer (retailer) if you are uncertain of which type of carburettor your chain saw is equipped with. Carburettor with movement limiters Your Husqvarna product has been designed and manufactured to specifications that reduce harmful emissions. MAINTENANCE Function, Basic settings, Fine adjustment... -
Page 30: Carburettor Without Movement Limiters
Rec. idle speed: 2500 rpm WARNING! Contact your servicing dealer, if the idle speed setting cannot be adjusted so that the chain stops. Do not use the chain saw until it has been properly adjusted or repaired. Fine adjustment When the machine has been ”run-in” the carburettor should be finely adjusted. - Page 31 • The carburettor has three adjustment controls: - L = Low speed jet - H = High speed jet - T = Idle adjustment screw • The T-screw regulates the throttle setting at idle speed. If the T-screw is turned clockwise this gives a higher idle speed;...
-
Page 32: Checking, Maintaining And Servicing Chain Saw Safety Equipment
procedure with the H-jet turned a further 1/4 turn anti- clockwise. • You have now run the machine at settings of H =±0, H=+1/4, H=+1/2 relative to the basic settings. At full throttle the engine has sounded different for each setting. -
Page 33: Throttle Lockout
Checking the inertia brake release Place the chain saw, with the engine switched off, on a stump or other stable surface. Release the front handle and let the saw fall by its own weight, rotating around the rear handle towards the stump. When the bar hits the stump the brake should be applied. -
Page 34: Muffler
Chain catcher Check that the chain catcher is not damaged and is firmly attached to the body of the chain saw. Right hand guard Check that the right hand guard is not damaged and that there are no visible defects, such as cracks. Vibration damping system Regularly check the vibration damping units for cracks or deformation. -
Page 35: Starter
Starter WARNING! When the recoil spring is wound up in the starter housing it is under tension and can, if handled carelessly, pop out and cause personal injury. Care must be exercised when replacing the return spring or the starter cord. Wear protective glasses and protective gloves. -
Page 36: Air Filter
A damaged air filter must always be replaced. A HUSQVARNA chain saw can be equipped with different types of air filter according to working conditions, weather, season, etc. Contact your dealer for advice. -
Page 37: Needle Bearing Lubrication
1 1/2 turns from the closed position. Bar 28" and longer: 1 3/4 turns from the closed position. These recommendations apply to Husqvarna’s chain oil, for other chain oils increase the oil flow by one step. WARNING! The engine must not be running when making adjustments. -
Page 38: Winter Use
Winter use Running problems can occur when using the machine in the cold and snowy conditions caused by: • Too low engine temperature. • Icing of the air filter and carburettor. Special measures are therefore often required: • Partly mask the air inlet on the starter to increase the working temperature of the engine. -
Page 39: Maintenance Schedule
Maintenance schedule The following is a list of the maintenance that must be performed on the machine. Most of the items are described in the Maintenance section. Daily maintenance Clean the outside of the machine. Check that the components of the throttle control work safely. -
Page 40: Technical Data
Technical data Engine Cylinder displacement, cm Cylinder bore, mm Stroke, mm Idle speed, rpm Recommended max. speed, rpm Power, kW/ rpm Ignition system Spark plug Electrode gap, mm Fuel and lubrication system Fuel tank capacity, litre Oil pump capacity at 9,000 rpm, ml/min Oil tank capacity, litre Type of oil pump Weight... -
Page 41: Bar And Chain Combinations
Bar and chain combinations The following cutting attachments are approved for the model Husqvarna 395XP. Length, inch Pitch, inch Gauge, mm 0,404 0,404 0,404 0,404 Saw chain filing and file gauges TECHNICAL DATA Max. nose radius 34 mm 34 mm... -
Page 42: Ec-Declaration Of Conformity
Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel +46-36-146500, declares under sole responsibility that the chain saw Husqvarna 395XP/XPG from 2009’s serial numbers and onwards (the year is clearly stated in plain text on the type plate with subsequent serial number), is in conformity with the requirements of the COUNCIL’S DIRECTIVES: - of May 17, 2006 "relating to machinery"... - Page 44 Original instructions 1153177-26 ´®z+U1h¶6d¨ ´®z+U1h¶6d¨ 2010-02-03...
