- Page 1 Microwave USER’S GUIDE Model No: RHM3006 For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Contents Page Safety instructions …………………………….……….. Product overview ………………………………..….. About this microwave oven ……………………………….…….. Unpacking the microwave ……………………………………… Microwave oven installation ……………………………………… Turn table installation ……………………………………… Control panel ……………………………………… Using the microwave oven ……………………………………… Cleaning and care ……………………………………… Important utensil information ………………………………………... -
Page 3: Safety Instructions
Safety instructions IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. WARNING: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of... - Page 4 Safety instructions IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person. WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation than a that involves the removal of a cover which gives protection against exposure to microwave...
- Page 5 Safety instructions • Food containing a mixture of fat and water (for example, stock) should stand for 30 to 60 seconds in the oven after it has been turned off. This is to allow the mixture to settle and to prevent it from bubbling when a spoon is placed in it, or a stock cube is added.
- Page 6 Safety instructions • The microwave is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, wheat bags, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire. • If smoke is emitted , switch off or unplug the appliance and keep the door closed in order to stifle any flames.
- Page 7 Safety instructions • Before you clean the oven, turn it off and unplug it. • Keep the inside of the oven clean. When food or liquids stick to the oven walls, wipe with a damp cloth. We recommend that you do not use harsh detergent or abrasives.
- Page 8 Safety instructions • Do not use metal pans or dishes with metal handles. • Do not use anything with a metal trim. • Do not use paper covered wire twist-ties on plastic bags. • Do not use melamine dishes as they contain a material which will absorb microwave energy.
-
Page 9: Product Overview
Product overview Control panel (including door release button) Turntable shaft Turntable ring assembly Glass turntable Observation window Door assembly G. Safety interlock latches H. Waveguide cover Oven cavity Ventilation slots Grill rack and baking tray to be used for grilling and convection cooking only. WARNING: Do not use the oven when empty or for warming plates. -
Page 10: About This Microwave Oven
About this microwave oven Microwaves are high-frequency electromagnetic waves similar to radio waves. While radio waves may vary in length from one metre to many kilometres, microwaves are very short (less than 12.5 centimetres). Microwaves do not make any heat themselves but only cause water molecules in food to vibrate. -
Page 11: Unpacking The Microwave
Unpacking the microwave Before you use your microwave oven 1. Remove all the packaging. Do not remove the small piece of card from the right hand side of the cavity wall. This is called a wave-guide cover and allows the microwaves to pass through to cook the food. Please ensure you keep this cover clean at all times. -
Page 12: Microwave Oven Installation
Microwave oven installation • Select a level surface that provides enough space for the outlet vents. • The minimum installation height is 85cm. • A minimum clearance of 20 cm is required between the oven and any adjacent walls. Leave a minimum clearance of 30cm above the oven. The rear surface of appliance should be placed against a wall. -
Page 13: Turn Table Installation
Turn table installation • Before first use, check that any securing tape has been removed from the glass tray and turntable ring assembly. These parts must never be restricted from rotating. • Never place the glass tray upside down. • Both the glass tray and turntable ring assembly must always be used during cooking. -
Page 14: Control Panel
Control panel MENU ACTION SCREEN Cooking time, power, action indicators, and clock time are displayed. MICROWAVE Press this button to use the microwave function. GRILL/COMBI Press this button to use the grill and combination cooking. The grill element is located on the top of the cavity. -
Page 15: Using The Microwave Oven
Using the microwave oven Clock Setting When the microwave oven is first turned on, the oven will display "0:00", the buzzer will ring once. 1) Press “CLOCK/TIMER” to choose hours or minutes for alteration. The hour figures will flash. When altering the hours the ‘’0’’ on the Left Hand Side will flash. - Page 16 Using the microwave oven Microwave Cooking 1) Press the “MICROWAVE“ button once, and “P100” will display and flash. 2) Turn the “TIMER/WEIGHT/AUTO” to select the microwave power. "P100", "P80","P50", "P30","P10"will be displayed. Press the “MICROWAVE“ button to scroll through the power levels. 3) Press “START/+30SEC/CONFIRM“...
- Page 17 Using the microwave oven Quick Start cooking 1) Press the "START/+30SEC./CONFIRM" key to cook with 100% power level for 30 seconds. Each press on the same key can increases the cooking time by 30 seconds. The maximum cooking time is 95 minutes. 2) During the microwave, grill, convection and combination cooking process, press the "START/+30SEC./CONFIRM"...
- Page 18 Using the microwave oven Grill Cooking 1) Press the “GRILL/COMBI” button once, and “G-1” will display. 2) Press the “START/+30 SEC./CONFIRM“ button to confirm. 2) Turn “TIMER/WEIGHT/AUTO” to adjust the cooking time. (The time setting should be 0:05- 95:00.) 3) Press “START/+30 SEC./CONFIRM“ button to start the cooking process. Note: Half way through the grill time, the unit will sound twice to tell you to turn the food over.
- Page 19 Using the microwave oven Convection Cooking (with preheating function) The convection cooking allows you to cook food using the unit as a traditional oven, the microwave function is not used. It is recommended that you preheat the oven to the appropriate temperature before placing the food in the oven.
- Page 20 Using the microwave oven Convection Cooking (Without pre-heating function) 1) Press the “CONVECTION” button once, and “140”, the cooking temperature will flash. 2) Turn the “TIMER/WEIGHT/AUTO” dial to select the desired convection function temperature. Note: the temperature can be chosen from 140 degrees to 230 degrees, in 10 degree intervals.
- Page 21 Using the microwave oven Defrosting by Weight 1) Press " WEIGHT/TIME DEFROST" button once, the oven will display "d- ". 2) Turn the “TIMER/WEIGHT/AUTO” dial to select the weight of the food. At the same time, "g" will illuminate in red. The weight should be set between 100-2000g.
- Page 22 Using the microwave oven Display Weight ( ) g Power A1 Pizza A2 Potato 1 (230g) 100% 2 (460g) 3 (690g) A3 Meat 100% A4 Fish A5 Vegetable 100% A6 Beverage 1 (240ml) 100% 2 (480ml) 3 (720ml) A7 Pasta 50 (add 450ml of water) 100 (add 800ml of water) 150 (add 1200ml of...
- Page 23 Using the microwave oven Child lock Lock on: In waiting state, press "STOP/CLEAR" for 3 seconds, there will be a long "beep" as the lock activates a red key will illuminate in the display. LED will display current time or 0:00. Lock off: In locked state, press "STOP/CLEAR"...
-
Page 24: Cleaning And Care
Cleaning and care • Before you clean the oven, turn it off and unplug it. • Keep the inside of the oven clean. When food or liquids stick to the oven walls, wipe with a damp cloth. We recommend that you do not use harsh detergent or abrasives. -
Page 25: Important Utensil Information
Important utensil information • Do not use metal pans or dishes with metal handles. • Do not use anything with a metal trim. • Do not use paper covered wire twist-ties on plastic bags. • Do not use melamine dishes as they contain a material which will absorb microwave energy. -
Page 26: Connection To The Mains Supply
Connection to the mains supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of 230-240V~ 50H . Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 13A plug complying with BS1363. If this plug is unsuitable or needs to be replaced, please note the following: Important: The wires in the mains lead are coloured in accordance with the following code:... - Page 27 Connection to the mains supply For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which...
-
Page 28: Problem Solving & Plug
Problems solving & plug Problem solving The microwave oven may cause interference to your radio, TV or similar equipment. If it does, you can get rid of the interference by moving the radio, TV or equipment as far away from your microwave oven as possible. -
Page 29: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the store. The following conditions apply: •... -
Page 30: Technical Specification
Technical Specification 230V – 240V ~ 50Hz Rated Voltage Rated Input Power(Microwave) 14 0-1450 W 850- 900W Rated Output Power(Microwave) 1000-1100W Rated Power (Grill) 2300- 2500W Rated Power (Convection) Oven Capacity Turntable Diameter 315 mm mm x mm x External Dimensions(HxWxD) 18.64 kg Net Weight;... -
Page 31: Spare Parts
Spare parts The following spare parts are available from www.productcareuk.com Glass turntable Turntable coupling Wave Guide cover For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com... - Page 32 Notes For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com...
- Page 33 Notes For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com...
- Page 34 Notes For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com...
- Page 35 Notes For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com...
- Page 36 For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com Revision 1 This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
