Russell Hobbs STYLEVIA RHM2026B User Manual

20l digital microwave
Hide thumbs
Table of Contents

Advertisement

Quick Links

STYLEVIA 20L Digital Microwave
User Guide
Model Number:
RHM2026 (B) (C)
For Customer Services & Spare Parts please call 0345 209 7461
Or visit us at mda.russellhobbs.com
PLEASE RETAIN
FOR FUTURE REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STYLEVIA RHM2026B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Russell Hobbs STYLEVIA RHM2026B

Summary of Contents for Russell Hobbs STYLEVIA RHM2026B

  • Page 1 STYLEVIA 20L Digital Microwave User Guide Model Number: RHM2026 (B) (C) For Customer Services & Spare Parts please call 0345 209 7461 Or visit us at mda.russellhobbs.com PLEASE RETAIN FOR FUTURE REFERENCE...

  • Page 2: Table Of Contents

    CONTENTS Page(s) Safety instructions About your microwave 10-11 Product information Unpacking the microwave Product overview Microwave oven installation 15-16 Turntable installation 17-18 Control panel How to use the microwave 20-25 Cooking tips Cleaning the microwave Troubleshooting 28-31 Guarantee & customer services Spare parts Connection to the mains supply 34-35...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • This appliance is intended to be used in the household and general domestic applications. It is not intended to be used in industrial or commercial applications. •...
  • Page 4 SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • A minimum clearance of 7.5cm is required between the oven and any adjacent walls. Leave a minimum clearance of 30cm above the oven. • Use only cookware and utensils that are approved for use in a microwave oven.
  • Page 5 SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns. Do not heat baby bottles with the teat left on. Remove it if replacing the bottle back into the oven.
  • Page 6 SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • To avoid fire, electric shock, or injury, never immerse the microwave, cord, or plug in water or liquid. • Do not use attachments not recommended by the manufacturer. Only use thermometers approved for use in microwaves.
  • Page 7 SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • When heating or cooking food or liquid, remember that there are certain foods (such as, jam, Christmas pudding, and mincemeat) which heat up very quickly. • Do not cook any food surrounded by a membrane, such as egg yolks, potatoes, chicken livers, sausages, ready meals and so on without piercing them several times with a fork.
  • Page 8 SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • Do not use melamine dishes as they contain a material which will absorb microwave energy. This may cause the dishes to crack or burn, and will slow down the cooking speed. •...
  • Page 9 SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • On the right hand wall of the cavity is the waveguide cover, microwaves are passed through this to enable your food to cook. It is important that this waveguide cover is kept clean at all times. To do this wipe with mild detergent and water, then dry.

  • Page 10: About Your Microwave

    ABOUT YOUR MICROWAVE Thank you for purchasing your Russell Hobbs microwave oven. The Russell Hobbs RHM2026 microwave has a sleek and stylish contemporary design, boasting an attractive mirror finish door. As well as an appealing look, this appliance also boasts impressive functionality, with 800 watts of microwave power providing quick and convenient cooking in your home.
  • Page 11 ABOUT YOUR MICROWAVE How do microwaves work? Microwaves are high-frequency electromagnetic waves similar to radio waves. While radio waves may vary in length from one metre to many kilometres, microwaves are very short (less than 12.5 centimetres.) Microwaves do not make any heat themselves but cause water molecules in food to vibrate.

  • Page 12: Product Information

    PRODUCT INFORMATION Rated Voltage 230-240V~/50Hz Rated Output Power 750-800W (Microwave) Oven Capacity 20L* *Internal volume is calculated by measuring maximum width, depth and height. Actual capacity for holding food is less.

  • Page 13: Unpacking The Microwave

    UNPACKING THE MICROWAVE Before you use your microwave oven 1. Remove all the packaging. Do not remove the large piece of plastic from the right hand side of the cavity wall (Refer to the below image). This is called a waveguide cover and allows the microwaves to pass through to cook the food.

  • Page 14: Product Overview

    PRODUCT OVERVIEW Oven door handle Screen display Safety interlock latches Control panel - buttons and dial Door assembly and window Turntable coupling Oven cavity 10. Turntable ring Microwave top 11. Glass turntable Plastic waveguide cover (do not remove)

  • Page 15: Microwave Oven Installation

    MICROWAVE OVEN INSTALLATION • Place the oven as far away from radios and televisions as possible. Using the oven may cause interference with the reception. • Plug the oven into a suitable 13 amp mains socket, make sure the voltage is the same as on the rating label (do not use extension cables or mains socket adaptors.) •...
  • Page 16 MICROWAVE OVEN INSTALLATION The minimum installation height is 85cm. A minimum clearance of 7.5cm is required between the oven and any adjacent walls. Leave a minimum clearance of 30cm above the oven. WARNING: DO NOT install the oven over a cooker or other heat or steam producing appliance as this will damage the microwave oven.

  • Page 17: Turntable Installation

    TURNTABLE INSTALLATION • Before first use, check that any securing tape and all packaging has been removed from the glass tray and turntable ring assembly. • These parts must never be restricted from rotating. • Never place the glass tray upside down. •...
  • Page 18 TURNTABLE INSTALLATION The glass tray, turntable ring, and turntable coupling assembly must always be used during cooking (as shown below). • Do not place the food directly onto the glass tray, always place on or in suitable microwaveable cookware. Please check that crockery is microwave safe before using. •...

  • Page 19: Control Panel

    CONTROL PANEL Screen Display Cooking time, power, action indicators, and clock time are displayed. Power Press this button a number of times to set a cooking power level. Weight/Time Defrost Press this button to input weight or time for defrosting. Kitchen Timer Press this button to use the timer function.

  • Page 20: How To Use The Microwave

    HOW TO USE THE MICROWAVE Setting the clock (24 hour) When the microwave is plugged in and first turned on the display will show ‘0:00’, and the buzzer will ring once. Follow the below example of setting the clock to 8:30 (AM): Press the 'Clock' button once.
  • Page 21 HOW TO USE THE MICROWAVE Microwave cooking Once you have correctly installed the unit, turned on the power and set the clock, you are ready to start cooking. Your microwave has 5 power levels, the lowest at 10%, then 30%, 50%, 80%, up to 100% (or full power.) Most recipes are cooked on full power –...
  • Page 22 HOW TO USE THE MICROWAVE Pausing cooking If you want to pause the cooking to turn over or stir contents, simply open the door, then close again and press the ‘Start/+30Sec./Confirm’ button to continue the cycle. If you wish to stop cooking with time left on the display, take out the contents, close the door and press the ‘Stop/Clear’...
  • Page 23 HOW TO USE THE MICROWAVE Auto cooking function As a digital microwave, the appliance features a default cooking menu, automatically calculating the cooking time based on the type of food and weight. 1. In a waiting state, turn the 'Time/Weight/Auto Menu' dial clockwise. This will display: ‘A-1 –...
  • Page 24 HOW TO USE THE MICROWAVE Multi-sequence cooking function For some recipes, results may be better if you wish to cook on different power levels for different times, for one dish. This can be used to set a maximum of two different stages. The buzzer will ring once after each stage and the next stage will then begin.
  • Page 25 HOW TO USE THE MICROWAVE Checking functions During the cooking cycle, press the ‘Power’ button and the current power will be displayed for 2-3 seconds. During the cooking cycle, press the ‘Clock’ button to check the current time. It will be displayed for 2-3 seconds.

  • Page 26: Cooking Tips

    COOKING TIPS Defrosting tips Microwaves penetrate around 4cm into most food. To maximize defrosting effectiveness follow the below guidelines: 1. For thick foods, turn regularly during operation in order to defrost evenly. 2. If food weighs over 500g, it is advised to turn at least 2 times. 3.

  • Page 27: Cleaning The Microwave

    CLEANING THE MICROWAVE Before you clean the oven, turn it off and unplug it. Keep the inside of the oven clean. When food or liquids stick to the oven walls, wipe with a damp cloth. We recommend that you do not use harsh detergent or abrasives.

  • Page 28: Troubleshooting

    TROUBLESHOOTING WARNING: To reduce the risk of personal injury, always unplug the microwave before performing maintenance or trouble shooting checks. The microwave oven may cause interference to your radio, TV or similar equipment. If this happens, you stop the interference by moving the radio, TV or equipment as far away from your microwave oven as possible.
  • Page 29 TROUBLESHOOTING Problem Potential reason Potential solution Spillages or splashes can burn and catch fire, all food that is put into the microwave should be appropriately covered. All spillages or splashes must be cleaned, and all areas of microwave cleaned after each use. Burnt on food debris in the microwave, on the waveguide and the behind the waveguide can cause the microwave to 'spark'.
  • Page 30 TROUBLESHOOTING Problem Potential reason Potential solution By the very nature of how a microwave works, it ‘excites’ the water molecules in the food it is heating, causing them to move about and generate heat from within the food. Often when the food heats up it reaches the point where steam is released.
  • Page 31 TROUBLESHOOTING Problem Potential reason Potential solution Check that the glass turntable has been placed 1. Glass turntable fitted correctly on the turntable and is not stopping the door incorrectly from shutting correctly. Door not shutting/ If the microwave is within its warranty period, please locking 2.

  • Page 32: Guarantee & Customer Services

    GUARANTEE & CUSTOMER SERVICES At Russell Hobbs, we take all our customer feedback seriously. Feel free to contact our Customer Service Team on 0345 209 7461 who will be more than happy to assist you, Or visit us at mda.russellhobbs.com This product is guaranteed for 12 months from the date of the original purchase.

  • Page 33: Spare Parts

    SPARE PARTS To check the availability of the following spare parts, simply contact our friendly Customer Service team on 0345 209 7461. Turntable coupling Turntable ring Glass turntable...

  • Page 34: Connection To The Mains Supply

    CONNECTION TO THE MAINS SUPPLY WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of 230-240V~ 50Hz. Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 13A plug complying with BS1363. If this plug is unsuitable or needs to be replaced, refer to customer services.
  • Page 35 CONNECTION TO THE MAINS SUPPLY For UK use only – PLUG • As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: •...

  • Page 36: Disposal Information

    Made by Product Care Trading Limited under license from Spectrum Brands (UK) Limited. Product Care Trading Limited, Wigan, WN2 4AY/ PCT (NI) Ltd, Belfast, BT5 5AD. Russell Hobbs is the registered trademark of Spectrum Brands (UK) Ltd. Russell Hobbs Support: call 0345 209 7461 or visit: mda.russellhobbs.com The ‘wheelie bin’...

This manual is also suitable for:

Stylevia rhm2026c
