STAINLESS OUTDOOR GAS FIREPLACE SYSTEM
OWNER'S OPERATION AND INSTALLATION MANUAL
REMOTE CONTROL READY
NATURAL GAS MODELS (V)O36NRb SERIES AND
(V)O42NRb SERIES
PROPANE/LP GAS MODELS (V)O36PRb SERIES AND
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
WARNING: For Outdoor Use Only.
WARNING: Fireplace must be operated only with
doors fully open.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
PFS
C
(V)O42PRb SERIES
For more information, visit www.fmiproducts.com
®
US
Advertisement
Table of Contents
Related Manuals for FMI V 042NRB SERIES
Summary of Contents for FMI V 042NRB SERIES
- Page 1 STAINLESS OUTDOOR GAS FIREPLACE SYSTEM OWNER’S OPERATION AND INSTALLATION MANUAL ® REMOTE CONTROL READY NATURAL GAS MODELS (V)O36NRb SERIES AND (V)O42NRb SERIES PROPANE/LP GAS MODELS (V)O36PRb SERIES AND (V)O42PRb SERIES WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TAbLE OF CONTENTS Safety ..............2 Specifications ............ 15 Local Codes............3 Wiring Diagram ..........15 Product Features ..........4 Replacement Parts ..........16 Locating Fireplace ..........4 Service Hints ............. 16 Product Specifications ......... 4 Technical Service..........16 Installation ............5 Accessories ............ -
Page 3: Local Codes
SAFETY Continued 5. Do not use this fireplace as a wood burning You must operate this fireplace fireplace. Use only the logs provided with with the fireplace screen in place. the fireplace. Do not burn solid fuels in this Make sure fireplace screen is in fireplace. -
Page 4: Product Features
PRODUCT FEATURES LOCATING FIREPLACE REFRACTORY bRICK LINER PLANNING Your fireplace features a concrete refractory Plan where you will install the fireplace. This brick liner. As with all concrete liners, this liner will save time and money later when you in- may develop slight cracks when exposed to stall the fireplace. -
Page 5: Installation
INSTALLATION OUTDOOR ENCLOSURE IMPORTANT: Make sure fireplace is level. If fire- place is not level, log set will not work properly. REqUIREMENTS Use dimensions shown for rough openings Must conform to one of the following condi- to create the easiest installation (see Built-In tions: Fireplace Installation, page 6). - Page 6 INSTALLATION Continued Facing material above firebox Table 1 must be of noncombustible material. A 12" concrete board Rough Opening Dimensions for built-in Mantel Shelf Note: Any portion projecting the width of the of the mantel shelf must NOT fireplace is supplied. Installation extend beyond this profile.
- Page 7 INSTALLATION Continued Notches INSTALLING DRAIN PAN DP36/DP42 on Hood The fireplace enclosure must allow for ad- equate drainage and fresh air ventilation. It is recommended that a sealed, corrosion resistant catch pan with provision for drainage be installed under fireplace within fireplace enclosure (see Accessories, page 16).
- Page 8 INSTALLATION • Do not operate this appliance if glass doors are broken or damaged. Continued • Do not use abrasive liquids or cleaners for cleaning of glass and door trims. Any WARNING: Fireplace must household glass cleaner should suffice. be operated only with doors fully Do not clean doors when hot, allow the opened.
- Page 9 INSTALLATION • The bottom openings must be 180° op- posing and be placed 5" (12.7 cm) above Continued bottom floor. For propane/LP units, the installer must • There must be 2" (5 cm) minimum clear- supply an external regulator. The external ance from the floor to ground level of regulator will reduce incoming gas pressure.
- Page 10 INSTALLATION CAUTION: Make sure exter- Continued nal regulator has been installed We recommend that you install a sediment between propane/LP supply trap in supply line as shown in Figure 13. Lo- and appliance. See guidelines cate sediment trap where it is within reach for under Connecting to Gas Sup- cleaning.
- Page 11 INSTALLATION Continued PLACEMENT OF LOOSE EMBERS Equipment Propane/LP Shutoff Valve Supply Tank CAUTION: Do not place any loose embers around pilot assembly. Two bags of loose embers are provided with this unit. For this installation use the embers that are approximately 1" square in size. If needed, larger embers can be broken to size.
-
Page 12: Operation
OPERATION FOR YOUR SAFETY If you then smell gas, STOP! Follow "B" in the safety information in column 1. If you READ BEFORE LIGHTING don't smell gas, go on the next step. WARNING: If you do not fol- 6. Press in and turn control knob counter- clockwise to the PILOT position. -
Page 13: Inspecting Burners
OPERATION Note: The burner may light if hand-held re- mote was on when selector switch was last Continued turned off. You can now turn the burner on and HAND-HELD off with the hand-held remote control unit. REMOTE OPERATION IMPORTANT: Do not leave the selector switch in the REMOTE or ON position when the pilot NOTICE: You must light the pilot is not lit. -
Page 14: Cleaning And Maintenance
OPTIONAL hAND-hELD REMOTE CONTROL ACCESSORIES Remote-Ready Models Only (MRC) NOTICE: Use only alkaline bat- teries (included with MRC). Figure 20 - Disconnecting Jumper Wires From Control Valve Installing Receiver 1. Disconnect jumper wires from the control Requires 4-AA 1.5V valve (see Figure 20). alkaline batteries 2. -
Page 15: Specifications
SAFETY DEVICE High Temperature Limit Switch 3. Carefully pull limit plate out and press the reset button. The high temperature limit switch is located in- side the upper right hand corner of the firebox. 4. Mount limit switch plate back using two This feature will prevent the fireplace from screws previously removed. -
Page 16: Replacement Parts
• pilot will not stay lit installation, operation, or troubleshooting. • burner will have delayed ignition If so, contact FMI PRODUCTS, LLC at • fireplace will not produce specified heat 1-866-328-4537. When calling please have • propane/LP gas supply may be low if using... -
Page 17: Troubleshooting
TROUbLEShOOTING WARNING: Turn off heater and let cool before servicing. Only a qualified service person should service and repair heater. CAUTION: Never use a wire, needle or similar object to clean pilot. This can damage pilot unit. Note: All troubleshooting items are listed in order of operation. ObSERVED PRObLEM POSSIBLE CAUSE REMEDY... - Page 18 TROUbLEShOOTING Continued ObSERVED PRObLEM POSSIBLE CAUSE REMEDY Pilot lights but flame goes 1. Gas control knob not fully 1. Press in gas control knob out when control knob is pressed in fully released 2. Gas control knob not 2. After pilot lights, keep gas pressed in long enough control knob pressed in 30 seconds...
- Page 19 TROUbLEShOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions.
-
Page 20: Parts
PARTS MODELS VO36NRb, VO36PRb, VO36NRRb, VO36PRRb, VO36NRHb, VO36PRHb, VO36NRRHb, VO36PRRHb, O36NRb, O36PRb, O36NRHb, O36PRHB, O36NRRB, O36PRRB, O36NRRHB AND O36PRRHB www.fmiproducts.com 125343-01A... - Page 21 PARTS This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 16 of this manual. NO. PART NO. DESCRIPTION QTY. 123164-01 Refractory, Bottom Rear (White) • • • • •...
- Page 22 PARTS MODELS VO42NRb, VO42PRb, VO42NRRb, VO42PRRb, VO42NRHb, VO42PRHb, VO42NRRHb, VO42PRRHb, O42NRb, O42PRb, O42NRHb, O42PRHB, O42NRRB, O42PRRB, O42NRRHB AND O42PRRHB www.fmiproducts.com 125343-01A...
- Page 23 PARTS This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 16 of this manual. NO. PART NO. DESCRIPTION QTY. 123160-01 Refractory, Bottom Rear (White) • • • • •...
-
Page 24: Warranty
This is FMI PRODUCTS, LLC’s exclusive warranty, and to the full extent allowed by law; this express war- ranty excludes any and all other warranties, express or implied, written or verbal and limits the duration of...
