English
Français
CITY MULTI Control System
Español
Smart ME Controller PAR-U02MEDA
Simple Operation Manual
Italiano
Português
Ελληνικά
Türkçe
Slovenščina
Hrvatski
Română
Prior to use, thoroughly read the instructions in this manual to use the product correctly.
Retain this manual for future reference.
Make sure that the CD-ROM, this manual, and Installation Manual are passed on to any
future users.
To ensure safety and proper operation of the remote controller, the remote controller should
only be installed by qualified personnel.
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric PAR-U02MEDA
Summary of Contents for Mitsubishi Electric PAR-U02MEDA
- Page 1 English Français CITY MULTI Control System Español Smart ME Controller PAR-U02MEDA Simple Operation Manual Italiano Português Ελληνικά Türkçe Slovenščina Hrvatski Română Prior to use, thoroughly read the instructions in this manual to use the product correctly. Retain this manual for future reference.
-
Page 3: Table Of Contents
Contents Safety precautions ..........4 Names and functions of controller components ..7 Controller interface ..............7 Screen configuration ...............8 Display ...................10 Basic operations ...........12 Troubleshooting ............15 Timer, Schedule, and Auto return ......16 Maintenance ............17 Product features ...........18... -
Page 4: Safety Precautions
Safety precautions • Thoroughly read the following safety precautions before using the unit. • Observe these precautions carefully to ensure safety. Indicates a risk of death or serious injury. WARNING Indicates a risk of serious injury or structural damage. CAUTION •... - Page 5 Properly dispose of the packing materials. Plastic This controller is designed for exclusive use with bags pose suffocation hazard to children. the Building Management System by Mitsubishi To avoid damage to the controller, do not Electric. The use of this controller for with other overtighten the screws.
- Page 6 Safety precautions The CD-ROM that is supplied with Smart ME Controller The CD-ROM can only be played on a CD-drive or a DVD-drive. Do not attempt to play the CD-ROM on an audio CD player as this may damage your ears and/ WARNING or speakers.
-
Page 7: Names And Functions Of Controller Components
Names and functions of controller components Controller interface ▌ 1 Occupancy Sensor The occupancy sensor detects vacancy for energy-save control. ▌ 2 Brightness Sensor The brightness sensor detects the brightness of the room for energy-save control. ▌ 3 Temperature & Humidity Sensor The sensor detects the room temperature and the relative humidity. -
Page 8: Screen Configuration
Names and functions of controller components Screen configuration General equipment screen Home screen This screen will not appear if no Advanced HVAC CONTROLLERs (AHC) are connected. Menu (User) screen... - Page 9 Names and functions of controller components Indoor unit setting screen Humidity setting screen The setting items that are not available This screen will not appear if no for the connected indoor unit will not Advanced HVAC CONTROLLERs appear on the display. (AHC) are connected.
-
Page 10: Display
Names and functions of controller components Display ▌ Home screen Basic * All icons are displayed for explanation. ▌ ▌ 1 [ON/OFF] button Touch to turn ON/OFF the indoor unit. Appears when the scheduled operation is being performed. ▌ 2 [Operation mode] button The icon appears when the timer operation is prohibited. - Page 11 Names and functions of controller components Advanced ▌ Appears when the operation is centrally controlled. ▌ Appears when the operation is locked. ▌ l Auto-OFF display Appears when the Auto-OFF timer is activated. ▌ Indicates the interlocked LOSSNAY unit (ventilator) setting. ▌...
-
Page 12: Basic Operations
Basic operations ▌ Operation mode icons : Cool : Dry : Fan : Auto : Heat : Auto_Cool : Auto_Heat ▌ Turning on and selecting operation mode Touch the 1 [ON/OFF] button. The LED indicator will light up. LOSSNAY units that are interlocked with indoor units will also turn on. Touch the 2 [Operation mode] button to go through the operation modes. - Page 13 Basic operations ▌ Fan speed Touch the button labeled 7 to Touch the button labeled p to display the Indoor unit setting go through the fan speeds. screen. * The number of available fan speeds depends on the indoor unit model. <Note>...
- Page 14 Basic operations ▌ Automatic cooling/heating operation <Auto (single set point)> When the room temperature rises above the set temperature, cooling operation starts. When the room temperature drops below the set temperature, heating operation starts. <Auto (dual set points)> When the room temperature rises above the cooling set temperature, cooling operation starts. When the room temperature drops below the heating set temperature, heating operation starts.
-
Page 15: Troubleshooting
Troubleshooting When an error occurs, the [Error information] screen will appear. Check the error status, stop the operation, and consult your dealer. Error code, error unit, M-NET address, and your dealer’s phone number will appear. The phone number will appear only if the information has been registered. -
Page 16: Timer, Schedule, And Auto Return
Timer, Schedule, and Auto return The settings for Timer, Schedule, and Auto return can be made. Touch the 3 [Menu] button to go to the Menu screen, and select the desired setting item. Refer to the remote controller Instruction Book for further information. ▌... -
Page 17: Maintenance
Maintenance ▌ Filter information will appear on the Home screen when it is time to clean the filters on indoor units. ▌ Resetting the filter sign Select [Filter Touch [Reset] to reset Touch [OK]. A confirmation screen information] from the the filter sign. -
Page 18: Product Features
Product features ▌ Energy-save control with the use of the built-in occupancy sensor Occupancy sensor Brightness sensor • Energy-save control will be performed when the occupancy sensor detects vacancy. • When the occupancy sensor detects no human movement for a certain period of time, this will be regarded as the vacancy. -
Page 19: Led Indicator
Product features ▌ LED Indicator • The LED indicator indicates the operation status by lighting and blinking with different colors and brightness (High/Low), or by turning off. • Indicator colors: Blue, Light blue, Purple, Red, Pink, Orange, Yellow, Green, Lime, and White LED Indicator Operation status LED indicator... - Page 20 • Electromagnetic Compatibility Directive 2004/108/EC • Restriction of Hazardous Substances 2011/65/EU HEAD OFFICE: TOKYO BLDG. , 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN Authorized representative in EU: MITSUBISHI ELECTRIC EUROPE B.V. HARMAN HOUSE, 1 GEORGE STREET, UXBRIDGE, MIDDLESEX UB8 1QQ, U.K.
