IN-DASH APP/DVD RECEIVER
ICS-X8
QUICK REFERENCE GUIDE
Kurzanleitung
GUIDE DE RÉFÉRENCE RAPIDE
GUÍA DE REFERENCIA RÁPIDA
GUIDA RAPIDA
SNABBGUIDE
SNELSTARTGIDS
КРАТКОЕ СПРАВОЧНОЕ РУКОВОДСТВО
SKRÓCONA INSTRUKCJA DLA UŻYTKOWNIKA
R
EN
DE
FR
ES
IT
SE
NL
RU
PL
GR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICS-X8 and is the answer not in the manual?

Questions and answers

Related Manuals for Alpine ICS-X8

Summary of Contents for Alpine ICS-X8

  • Page 1 FOR CAR USE ONLY/NUR FÜR AUTOMOBIL GEBRAUCH/POUR APPLICATION AUTOMOBILE UNIQUEMENT/ PARA USO EN AUTOMÓVILES/SOLO PER L’UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK/ALLEEN VOOR GEBRUIK IN DE AUTO/ТОЛЬКО ДЛЯ ИСПОЛЬЗОВАНИЯ В АВТОМОБИЛЯХ/DO UŻYCIA TYLKO W SAMOCHODZIE/ IN-DASH APP/DVD RECEIVER ICS-X8 QUICK REFERENCE GUIDE Kurzanleitung GUIDE DE RÉFÉRENCE RAPIDE GUÍA DE REFERENCIA RÁPIDA...

  • Page 3: Table Of Contents

    For details on all functions, refer to the Owner’s Manual stored in the supplied CD-ROM. (As it is data CD, the CD cannot be used for playing back music and images on the player.) If required, an ALPINE dealer will readily provide you with a print out of the Owner’s Manual contained in the CD-ROM.

  • Page 4: Warning

    Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL HEAR Center for repairing.

  • Page 5: Getting Started

    Owner’s manual Touch operation, Location of Controls, Turning Power On or Off Getting Started Touch operation You can operate the system by using the touch panel on the screen. Common onscreen buttons : Returns to the previous screen. Depending on the function, this button may cancel the operations performed on the screen.

  • Page 6: Home Screen And Favorites

    Owner’s manual Home Screen and Favorites Home Screen and Favorites You can easily switch to the application of your choice from the Home Screen or Favorites. The Home Screen displays icons for applications usable with this unit. Favorites is a shortcut function that displays up to 4 icons on the screen you are using.

  • Page 7: Using The Media View Button

    Owner’s manual Using the Media View button Using the Media View button You can switch between the Navigation screen and the main screen for the current media source with just one touch. Media View button Press Media screen Owner’s manual Date/Time Setting Setting the Time Press the Home button.

  • Page 8: Radio Operation

    Owner’s manual Radio, RDS Radio Operation Preset No. Indicator Band display Frequency display Info area Increases frequency Decreases frequency Preset button Displays the preset stations with Switches band a short touch. Touch for at least 2 seconds to Displays the Audio Setup memorise the current station as screen a preset station.

  • Page 9: Dvd Operation

    Owner’s manual DVD Operation When you touch the DVD playback screen, the DVD operation screen is displayed. The following is an example of the DVD-VIDEO operation screen. Operation button 1/2 Title no. Chapter no. DVD information display Finds the beginning of the current chapter/Finds a previous chapter within Finds the beginning of...

  • Page 10: Ipod/Iphone Operation (Optional)

    Owner’s manual iPod/iPhone (Optional) iPod/iPhone Operation (Optional) An iPod/iPhone can be connected to this unit by using the cable (KCU-461iV) (sold separately). You can connect a video-capable iPod to enjoy not only Music but also Video files. Audio mode Displays the search screen Current song no./Total song no.

  • Page 11: Usb Memory Operation (Optional)

    Nokia Drive and Nokia Music applications are made available by connecting compatible Nokia phones to the ICS-X8. The Nokia phone require a specific software to support this feature. To obtain more details about the underlying technology and the compatible phones, please visit www.alpine-europe.com , www.nokia.com.

  • Page 12: Hands-Free Phone Control

    Owner’s manual BLUETOOTH Setting, BLUETOOTH Operation Hands-Free Phone Control Hands-free calls are possible when using an HFP (Hands-Free Profile) compatible mobile phone with the ICS-X8. How to connect to a BLUETOOTH Audio: Sets for use as an Audio device. HFT: Sets for use as a Hands Free Device.

  • Page 13: Installation

    X8 to the fuse box, make sure the fuse for the intended • driver’s view and operations are not obstructed. circuit of the ICS-X8 has the appropriate amperage. • microphone is located where the driver’s voice Failure to do so may result in damage to the unit and/or can be easily picked up (on the sun visor, etc.).
  • Page 14 • If the switched power (ignition) lead of the ICS-X8 is connected directly to the positive (+) post of the vehicle’s battery, the ICS-X8 draws some current (several hundred milliamperes) even when its switch is placed in the OFF position, and the...

  • Page 15: Connections

    Owner’s manual Connections Connections Connections 1/2 Antenna ISO Antenna Plug REMOTE OUT To remote input lead (Brown) REMOTE IN To remote output lead (Brown) REVERSE To plus side of the back lamp signal lead of the car (Orange/White) CAMERA1 To Rear camera CAMERA2 Not used CAMERA SW...
  • Page 16 Connections 2/2 GPS Antenna (Sold separately) KAE-100GPS Nokia Phone (Sold separately) Nokia cable (Included) USB extension cable (I type) iPod/iPhone (Included) (Sold separately) USB Memory (Sold separately) USB extension cable (L type) (Included) Connection kit KCU-461iV (Sold separately) iPod VIDEO AV extension cable (Included with KCU-461iV) REMOTE TURN-ON To amplifier or equalizer (Blue/White)

  • Page 17: Specifications

    Owner’s manual Specifications Specifications MONITOR SECTION Channel Separation 85 dB (at 1 kHz) Signal system NTSC/PAL Screen Size 7.0” Horizontal resolution 500 lines or greater LCD Type Transparent type TN LCD Video output level 1Vp-p (75 ohms) Operation System TFT active matrix Video S/N ratio DVD: 60 dB Number of Picture Elements...
  • Page 18 The BLUETOOTH ® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Alpine Electronics, Inc. is under licence. • “MPEG Layer-3 audio coding technology licenced from Fraunhofer IIS and Thomson. ”...
  • Page 20 Viale C. Colombo 8, 20090 Trezzano Phone 1-800-ALPINE-1 (1-800-257-4631) Sul Naviglio (MI), Italy 1-888-NAV-HELP (1-888-628-4357) Phone 02-484781 ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ELECTRONICS DE ESPAÑA, S.A. 161-165 Princes Highway, Portal de Gamarra 36, Pabellón, 32 Hallam Victoria 3803, Australia...
