Retrofit Kit Technical Information

Ikegami has introduced four retrofit kits and two accessory items to improve the ruggedness

and ease of operation of the SE-79D.

1) Improved camera to lens alignment and locking retrofit kit

Replaces thumbscrews with socket head bolts, and replaces lens locking lever

on camera with longer type.

This kit can be installed by customers. The kit includes socket head bolts, lens

locking lever, labels, hex keys, and instructions.

Part # SE-79D-OP1

Price: $280

Socket Head Bolts

Long Locking Lever

Table of Contents

Do you have a question about the SE-79D and is the answer not in the manual?

Page 1 Retrofit Kit Technical Information Ikegami has introduced four retrofit kits and two accessory items to improve the ruggedness and ease of operation of the SE-79D. 1) Improved camera to lens alignment and locking retrofit kit Part # SE-79D-OP1 Price: $280 Replaces thumbscrews with socket head bolts, and replaces lens locking lever on camera with longer type.
Page 2 Lens supporter is machined to fit the new harness and add a cover plate. The SE must be sent to New Jersey for Ikegami installation of this retrofit kit. Ikegami installation cost is included in the price.
Page 3 3) Improved VFL-900 tilt mechanism retrofit kit Part # SE-79D OP3 Price: $1400 Adds a new pivot point near the center-of-gravity of the VFL-900 for free tilting of the viewfinder with minimal friction. This kit can be installed by customers. The kit includes new tilt bracket, friction pivot replacement parts, counter weight, and instructions.
Page 4 VFL-900, removes the DC/DC converter from the pan & tilt platform, and adds a new connector block on the pan & tilt platform. The SE must be sent to New Jersey for Ikegami installation of this retrofit kit. Ikegami installation cost is included in the price.
