Model : XHG-3529-W/B
How to use recess mount housing
Components
recess mount housing
Thank you for purchasing our product.
Before attempting to connect or operate this product,
Anchor bolt tightening position
position de serrage de boulon d'ancrage
posicion de ajuste de tornillo de anclaje
Center / Centre / Centro
To be symmetrically placed
from the center
A placer symetriquenent par
rapport au centre
instalar simetricamente a la
perforcion del techo
225
Model : XHG-3529-W/B
How to use
please read these instructions carefully and save this
manual for future use.
How to use Adaptor
D
A
B
E
B
A
D
46.0
A
A
B
E
A
Advertisement
Related Manuals for Ikegami XHG-3529
Summary of Contents for Ikegami XHG-3529
- Page 1 Model : XHG-3529-W/B How to use recess mount housing Thank you for purchasing our product. Before attempting to connect or operate this product, Model : XHG-3529-W/B please read these instructions carefully and save this manual for future use. How to use recess mount housing...
- Page 2 INSTALLATION Put the template on the right part of ceiling for installation Fix the adapter to the recess mount with M3 screws and make a hole through the spacers. Then, fix the camera to the adapter with M4 screws(o-ring attached) as picture shows. Please draw outside service wire from the hole of ceiling.
