1 Purpose of this manual
The purpose of this manual is to provide service engineers who are already familiar with the repair procedures
for traditional washing machines with information regarding appliances fitted with the EWM2000 EVO electronic
control system and produced in Porcia (Italy).
The electronic control system plus EWM2000EVO consists of a main electronic board and one
control/display board, "SIGMA LCD" version.
The following are described:
•
General characteristics
•
Control panel and washing programmes
•
Technical characteristics
•
Guide to the diagnostics
For detailed information concerning hydraulic circuit, structural characteristics of the appliances and
accessibility, please refer to Service Manual of washing machines and washer-dryers Series P6000/Nexus
(publication no. 599 35 23-17).
2 PRECAUTIONS
Electrical appliances must be serviced only by qualified Service Engineers.
Always remove the plug from the power socket before touching internal
components.
3 GENERAL SPECIFICATIONS
Programme selection
Serial port
Voltage requirement
Type of washing system
Type of rinsing system
Motor
Spin speed
Anti-unbalancing control
Water fill control
Detergent dispenser
Control of water level in tub
Door interlocks
Power of heating element
Temperature control
Audible signalling system
Sensors
SOI/DT 2005-01 dmm
16 positions with incorporated main switch
DAAS-EAP communications protocol up to 38400 baud
220/240V
50 Hz
Jet-system
Jet-system
Collector, with tachometric generator
900 ÷ 1600 rpm
FUCS
Solenoid valves
3 compartments: prewash/stain remover, washing, softener
4 compartments: prewash/stain remover, washing, softener,
bleach
Two anti-boiling pressure switches
Anti-overflow pressure switch, Aqua control system
Analog pressure switch
Traditional (with PTC)
Instantaneous (with or without microswitch)
Magnetic
Up to 1950 W
NTC sensor
Traditional, included on display board
Water level sensor
Turbidity sensor
5/67
599 36 82-57
