Summary of Contents for Electrolux Washing machine

  • Page 1 User Manual Washing Machine...

  • Page 2: Table Of Contents

    Thank you for selecting our appliance We wish you lots of enjoyment with your new appliance and we hope that you will consider our brand again when purchasing household appliances. Please read this user manual carefully and keep it throughout the product life cycle as a reference document.

  • Page 3: Safety Information

    Safety Information In the interest of your safety and to ensure Do not place detergent, bleach or fabric ● the correct use, before installing and first softener containers on top of the appliance. using the appliance, read this user manual They can damage the finish or controls.

  • Page 4: Child Safety

    Child Safety If the machine is installed in a location ● subject to frost, please read the «dangers of This appliance is not intended for use by ● freezing» chapter. people (including children) with reduced Any plumbing work required to install this ●...

  • Page 5: Description Of The Appliance

    Description Of The Appliance Detergent dispenser drawer Control panel Drum lamp Door opening handle Adjustable feet Drum Lamp The drum light will turn on when the appliance door is opened and remain lighted for 3 minutes or until the door is closed. Detergent Dispenser Drawer «Detergent Wash»: Compartment for main wash.

  • Page 6: Control Panel

    Control Panel Information Henceforth, the programme selector dial, the display, the different buttons and the door pilot light will be indicated in all the book with the relevant numbers given in this picture. 90° 1100 60° 40° 30° Programme Selector The programme selector dial allows to select a wash programme.
  • Page 7 By pressing this button you can select one of the following options: SIGNAL VOLUME: A signal will sound when setting a wash programme, in case of wrong selection and in the event of operating problems and at the end of the programme. This signal has a three- level-adjustable volume or can be turned off.

  • Page 8: Display

    DOOR LOCK: Light on: The door cannot be opened. ● Light blinking: The door lock is releasing. The appliance has ● been probably set to pause. Light off: The door can be opened. ● Door Lock Pilot Light Note and Programme Do not try to force the door open when DOOR LOCK light is on.

  • Page 9: Programme Table

    Programme Table Washing Programmes / Suitable Temperature / Available Detergent Spin Speed /Cycle Description / Load capacity / Type of Options Compartment Laundry NO SPIN COTTON/DEEP CLEAN RINSE HOLD 90° - 60° - 40°C SIGNAL VOLUME Detergent Wash Spin speed: 1100-900-400 EASY IRON Main wash - Rinses - Long spin EXTRA RINSE...
  • Page 10 AFFINITY_EN_NO BRAND.qxd 11/07/2008 13.39 Page 10 Programme table Washing Programmes / Suitable Temperature / Available Detergent Spin Speed /Cycle Description / Load capacity / Type of Options Compartment Laundry WOOL/ HANDWASH 40° - 30° - Cold NO SPIN Spin speed: 900-400 RINSE HOLD Detergent Wash Main wash - Rinses - Short spin...

  • Page 11: Washing Hints

    Washing Hints Sorting The Laundry Maximum Loads Follow the wash code symbols on each Recommended loads are indicated in the garment label and the manufacturer’s washing «Programme Table». instructions. Sort the laundry as follows: whites, General rules: coloureds, synthetics, delicates, woollens. Cotton, linen: drum full but not too tightly packed;...

  • Page 12: Detergents And Additives

    All commonly available washing machine Dried grease stains: moisten with turpentine, detergents may be used in this appliance: lay the garment on a soft surface and dab the powder detergents for all types of fabric, ●...

  • Page 13: Quantity Of Detergent To Be Used

    Quantity Of Detergent To Be Used Degrees Of Water Hardness The type and quantity of detergent will depend Follow the product manufacturers’ instructions on the type of fabric, load size, degree of on quantities to use. soiling and hardness of the water used. Use less detergent if: Water hardness is classified in so-called you are washing a small load,...

  • Page 14: Operating Sequence

    Operating Sequence 1. Sort laundry into loads that can be washed together See «Washing Hints» for more details. 2. Pretreat stains and heavy soil See «Washing Hints» for more details. Load the laundry Open the door by If required, pour fabric softener into the carefully pulling the compartment marked , and the bleach...
  • Page 15 Note: To provide the best care for your laundry, lit to indicate that the appliance starts operating not every setting or option is available with and the door is locked. every programme. If a setting or option is not The appliance will not operate with the door available, its pilot light will not light up.

  • Page 16: Care And Cleaning

    • at the end of programme, the display and all pressing button . In case of water high level the pilot lights go off and it will be possible to and temperature, you must first empty out the open the door, or water and then open the door (please read «At the end of the programme»).
  • Page 17 For Other Inside Cleaning • Dry around the appliance door opening, flexible gasket,and door glass. These areas should always be clean to ensure a water tight seal. • When extremely soiled items have been washed, a dirty residue may remain on the Figure 4 Figure 3 drum.

  • Page 18: What To Do If

    What to do if... IMPORTANT! Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Centre, please carry out the checks listed below. During appliance operation it is possible that few acoustic signals sound to indicate that the appliance is not working.
  • Page 19 Malfunction Possible Cause / Solution The drain hose is squashed or kinked. • Check the drain hose connection. The option RINSE HOLD or NO SPIN programme has been selected. The appliance does not empty and/or • Select the SPIN ONLY programme. does not spin: •...
  • Page 20 Malfunction Possible Cause / Solution The transit bolts and packing have not been removed. • Check the correct installation of the appliance. The support feet have not been adjusted. • Check the correct levelling of the appliance. The appliance vibrates or is noisy: The laundry is not evenly distributed in the drum.

  • Page 21: Consumption Values

    AFFINITY_EN_NO BRAND.qxd 11/07/2008 13.39 Page 21 Consumption values Only cold water loading Energy Programme Water Programme consumption consumption duration (in litres) (in kWh) Cotton 90°C Cotton 60°C Cotton 60° + Eco (*) Cotton 40°C Synthetics 60°C 0.85 Synthetics 40°C Delicates 40°C Wool 40°C Information: The consumption data shown on this chart is to be considered purely indicative, as it may vary depending on the quantity and type of laundry, on the inlet water temperature and on the...

  • Page 22: Installation Instruction

    Dimensions (27”) 68.58 (23¾”) (6¾”) (24”) (8½”) 17.15 60.33 60.96 21.59 (2½”) 6.35 (33½”) 85.09 BACK SIDE (22”) (2 ”) (3 ”) 55.88 (23”) 9.21 6.67 ”) 58.42 65.09 (inches) ”) 71.76 (27”) 68.58 Installation instruction 3. Carefully return the appliance to an upright Unpacking position.
  • Page 23 6. Remove the 4 plugs from the literature pack Water inlet located in the drum and install them in the Do not use the hose from your previous holes vacated by the packaging spacers. appliance to connect to the water supply. Positioning Install the appliance on a flat hard floor.
  • Page 24 Electrical connection machine is emptying. This could be done by tying it to the tap with a piece of string or Information on the electrical connection is attaching it to the wall. given on the rating plate on the inner side of the appliance door.

  • Page 25: Environmental Concerns

    Enviromental concerns Packaging materials Ecological hints The materials marked with the symbol To save water, energy and to help protect the recyclable. environment, we recommend that you follow >PE<=polyethylene these tips: >PS<=polystyrene Normally soiled laundry may be washed ● >PP<=polypropylene without prewashing in order to save This means that they can be recycled by detergent, water and time (the environment...
  • Page 26 WARRANTY SHALL BE LIMITED TO THE REPLACEMENT OF PARTS AS HEREINBEFORE PROVIDED. and maintenance in accordance with instructions in the user's manual for the appliance. ELECTROLUX INTERNATIONAL COMPANY ID09-816A PITTSBURGH, PA 15220, U.S.A. 137 074 100A - 00 - 0807...
