10.3 Pressure switch

Control of the water level is performed by a two or three-level pressure switch which functions as follows:
•
contact 11-14: anti-boiling safety level
•
contact 21-24: anti-boiling safety level
•
contact 31-32: anti-overflow safety level (not all models)
10.3.1

Pressure switch settings

10.4 Detergent dispenser

The EWM 2000 plus electronic system and LCD can control different types of dispensers:
Type
3 compart-
ments
4 compart-
ments
SOI/DT 2005-01 dmm
Anti-boiling level
Anti-boiling level
Anti- overflow level
Detergent dispenser
Pre-wash/Stains – Wash – Conditioner
(pre-wash and stain are in alternance)
Pre-wash/Stains – Wash – Bleach - Conditioner
(the pre-wash/stain and conditioner compartment are
linked together with a "intersection")
Pre-wash/Stains – Wash – Bleach - Conditioner
(pre-wash and stain are in alternance)
Full (mm) Refill (mm)
50± 3 30± 3
50± 3 30± 3
390± 15 240±50
38/67
No. of solenoid
valves
2
2
3
599 36 82-57
