Z
A-H01
USB DAC STEREO INTEGRATED AMPLIFIER
OWNER'S MANUAL
What's in the Box . . . . . . . . . . . . . . . . . . . 4
Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Remote Control Unit . . . . . . . . . . . . . . . 5
Connections . . . . . . . . . . . . . . . . . . . . . . . 6
Speaker Connection . . . . . . . . . . . . . . . . 8
Identifying the Parts (Remote Control
Unit) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Computer . . . . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting. . . . . . . . . . . . . . . . . . . 15
Specifications . . . . . . . . . . . . . . . . . . . . . 16
3D0806820B
MODE D'EMPLOI
Contenu de l'emballage . . . . . . . . . . . 18
Avant l'utilisation . . . . . . . . . . . . . . . . . . 18
Télécommande . . . . . . . . . . . . . . . . . . . 19
Branchements . . . . . . . . . . . . . . . . . . . . . 20
Identification des parties
(Télécommande) . . . . . . . . . . . . . . . . . . 24
Lecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
conservés sur ordinateur . . . . . . . . . . 26
Guide de dépannage . . . . . . . . . . . . . . 29
Caractéristiques techniques . . . . . . . 30

MANUAL DEL USUARIO

Qué hay en la caja . . . . . . . . . . . . . . . . . 32
Antes de su utilización . . . . . . . . . . . . . 32
Mando a distancia . . . . . . . . . . . . . . . . . 33
Conexiones . . . . . . . . . . . . . . . . . . . . . . . 34
Conexión de los altavoces . . . . . . . . . 36
Identificación de las partes (A-H01) 37
Identificación de las partes (Mando a
distancia) . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Reproducción . . . . . . . . . . . . . . . . . . . . . 39
Reproducir archivos de música
almacenados en un ordenador . . . . 40
Solución de posibles fallos . . . . . . . . 43
Especificaciones . . . . . . . . . . . . . . . . . . . 44
ENGLISH
FRANÇAIS
ESPAÑOL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A-H01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teac A-H01

Summary of Contents for Teac A-H01

  • Page 1: Table Of Contents

    Speaker Connection ....8 Identification des parties (A-H01) . . 23 Identificación de las partes (A-H01) 37 Identifying the Parts (A-H01) ..9 Identification des parties Identificación de las partes (Mando a Identifying the Parts (Remote Control (Télécommande) .
  • Page 2 10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11) Only use attachments/accessories specified by CAUTION: TO REDUCE THE RISK OF ELECTRIC the manufacturer. SHOCK, DO NOT REMOVE COVER (OR BACK).
  • Page 3 CABINETS TO EXPOSE THE ELECTRONICS. NO USER SERVICEABLE PARTS ARE WITHIN. < IF YOU ARE EXPERIENCING PROBLEMS WITH THIS PRODUCT, CONTACT TEAC FOR A SERVICE REFERRAL. DO NOT USE THE PRODUCT UNTIL IT HAS BEEN REPAIRED. For U.S.A. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 4: What's In The Box

    What’s in the Box Before Use If one of the following is missing or damaged, CAUTION contact your dealer or our customer service/ technical support (stated on the back cover). Placement of the unit Power cord x 1 < Avoid placing it in high temperature environments such as in direct sunlight or close to a source of Remote control unit (RC-1268) x 1 heat.

  • Page 5: Remote Control Unit

    Remote Control Unit The included remote control allows this unit to Battery Replacement If the effective range decreases, the batteries be operated from a distance. are exhausted. In this case, replace the Point the remote control unit at the main unit’s batteries with new ones.

  • Page 6: Connections

    Be sure to connect each plug securely. Cassette deck, CD player, etc. Computer LINE OUT Install the dedicated TEAC driver software on your computer before connecting the TEAC A-H01 unit to the computer. (page 12) Connection DIGITAL OUT DIGITAL OUT (OPTICAL) (COAXIAL)
  • Page 7 Inputs digital audio from a computer. Connect to the USB port of a computer. Use a commercially available USB cable. < Install dedicated TEAC driver software on the computer before connecting the unit. (page 12) < Note that connection cables indicated other than the power cord are not included with this product. All other connection cables are available from your retail dealer.

  • Page 8: Speaker Connection

    Speaker Connection Right Speaker Left Speaker How to connect: CAUTION before connection Turn the terminal cap counterclockwise < After all other connections are complete, to loosen it. The speaker terminal caps connect the power cord's plug to the wall cannot be fully removed from the socket.

  • Page 9: Identifying The Parts (A-H01)

    Identifying the Parts (A-H01) POWER Press this button to turn the unit on and off. The blue indicator lights when the unit is turned on. Remote control light sensor Receives signals from the remote control unit. When operating the remote control unit, point it at this sensor.

  • Page 10: Identifying The Parts

    Identifying the Parts (Remote Control Unit) Using the remote control unit RC-1268, you can control the A-H01 and DS-H01. Only the buttons used for the A-H01 are explained in this document. SOURCE Use this button to select the source you want to play.

  • Page 11: Unit)

    PCM audio output. < To select "USB" to play back music files stored on a computer, install dedicated TEAC driver software on the computer before connecting the unit. (page 12) Start playback on the connected source device.

  • Page 12: Playing Back Music Files Stored On A

    Sampling frequencies that can be transmitted are 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz and 192 kHz. If the connection has been made properly, “TEAC USB HS ASYNC AUDIO” will be selectable as an audio output destination.
  • Page 13 Playing back music files stored on the computer Connect the unit to the computer using a USB cable. < USB cable Use a cable with a connector that fits the USB port on the unit. Turn the computer on. < Confirm that the operating system has started properly.
  • Page 14 Playing Back Music Files Stored on a Computer (2) < You cannot use the computer to control this unit or use this unit to control the computer. < When playing back a music file using the USB connection, do not attempt any of the following operations.

  • Page 15: Computer

    If you experience any problems with the unit, please take a moment to look through this chart before asking for repairs. If you still have a problem, contact your dealer or TEAC customer service/technical support (stated on the back cover).

  • Page 16: Specifications

    Specifications Amplifier Section General Maximum power output Power supply 30 W + 30 W (8 Ω, 1 kHz, JEITA) Europe model ... . AC 230V, 50 Hz 60 W + 60 W (4 Ω, 1 kHz, JEITA) U.S.A./Canada model .
  • Page 17 7733 Telegraph Road, Montebello, California 90640 U.S.A. Phone: (323) 726-0303 TEAC CANADA LTD. 5939 Wallace Street, Mississauga, Ontario L4Z 1Z8, Canada Phone: (905) 890-8008 TEAC MEXICO, S.A. DE C.V. Río Churubusco 364, Colonia Del Carmen, Delegación Coyoacàn, CP 04100, México DF, México Phone: (5255)5010-6000 TEAC UK LTD.
