WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
PROP 65 WARNING:
Chemicals known to the state
of California to cause cancer,
birth defects or other
reproductive harm are created
by the combustion of
propane.
WARNING:
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
GSF20JD
Instruction Manual
DELUXE LP GAS GRILL
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@BBQTEK.COM OR
CALL 1-877-885-8227 (TOLL-FREE), 07:00 A.M. – 04:00 P.M.
(EST), MONDAY-FRIDAY.
0
MODEL # GSF20JD
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bond GSF20JD
Summary of Contents for Bond GSF20JD
- Page 1 MODEL # GSF20JD DELUXE LP GAS GRILL WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER: Failure to follow these...
-
Page 2: Grill Operation
Read and follow all warnings and instructions before assembling and using the appliance. Follow all warnings and instructions when using the appliance. (Always keep this manual for convenient future reference. GSF20JD Instruction Manual... -
Page 3: Table Of Contents
Package Contents ......................5 Hardware Contents ....................6 Assembly Instructions....................7 Operating Your Grill....................10 Connecting Gas Cylinder ..................10 Checking for Leaks....................11 Lighting Your Grill....................11 Excess flow safety valve reset procedure ............13 Care and Maintenance ....................14 Troubleshooting ......................15 Warranty Program ....................17 GSF20JD Instruction Manual... -
Page 4: For Your Safety
Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open the relief valve and allow gas to escape. Safe Locations For Use Of This Outdoor Grill GSF20JD Instruction Manual... -
Page 5: General Information
Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A propane gas cylinder is required for operation. This gas grill is NOT intended for commercial use. 3. Don't obstruct the ventilation opening of the cylinder enclosure. GSF20JD Instruction Manual... -
Page 6: Package Contents
1 PC Heat plate 1 PC Tank clip 1 PC Cart left side panel 1 PC Cart bottom panel assembly 1 PC Cart right side panel Cart beam 1 PC 2 PCS Cart front panel 1 PC GSF20JD Instruction Manual... -
Page 7: Hardware Contents
M6 x 15 bolt 14 PCS M6 Spring washer 14 PCS M6 Flat washer 14 PCS Screwdriver 1 PC Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience). GSF20JD Instruction Manual... -
Page 8: Assembly Instructions
(CC) into each pre-drilled hole. Tighten bolts by hand until secured. g) Go back and tighten all bolts using the screwdriver provided. M6 x 15 Bolt 5 PCS M6 Spring Washer 5 PCS M6 Flat Washer 5 PCS GSF20JD Instruction Manual... - Page 9 Close the top lid. Step 5 Put the grease cup (G) onto the grease cup support (H). (See diagram to right) Hook the grease cup support into the holes under the bottom seat of body assembly. GSF20JD Instruction Manual...
- Page 10 Connect the tank with regulator by screwing the regulator collar onto the tank valve. (See diagram to right ) b) Conduct the leak test on page 11 to make certain all connections are connected securely. Fully Assembled View Left Side Right Side GSF20JD Instruction Manual...
-
Page 11: Operating Your Grill
8. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Install only the type of dust cap on cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result in leakage of propane. GSF20JD Instruction Manual... -
Page 12: Checking For Leaks
2. Once lit, place the flame through the hole on cooking grid to reach the burner ports. (see diagram to right). 3. Press the valve knob and rotate it counter clockwise to the ‘’HIGH’’ position. The burner should light immediately. 4. Adjust burners to the desire cooking temperature. GSF20JD Instruction Manual... - Page 13 Controlling the intensity of the flare-ups is necessary, however, in order to avoid burned or unevenly cooked foods and to prevent the possibility of accidental fire. GSF20JD Instruction Manual...
-
Page 14: Excess Flow Safety Valve Reset Procedure
When all front burners are lit, close the grill lid. Wait for 10-15 minutes; the temperature should reach 400 – 450°F. WARNING: The cylinder valve always has to be above the horizontal position, for the cylinder to have vapor withdrawl only. GSF20JD Instruction Manual... -
Page 15: Care And Maintenance
Inspect burner for damage (cracks or holes). If damage is found, replace with a new burner. Reinstall burner. Make certain the gas valve orifices are correctly positioned, pointing straight into burner inlet (venturi tube). Also, check position of spark electrode. GSF20JD Instruction Manual... -
Page 16: Troubleshooting
Turn front of grill to face wind or Flame blow out. Increase flame height. Low on propane gas. Replace or refill propane tank. GSF20JD Excess flow valve tripped. Refer to the Excessive flow safety Instruction Manual valve reset procedure on page 13. - Page 17 If flames are blue and noisy – close flap at the end of the venturi tubes in 1/8 in. increments until flames are correct. *Propane Models must be open a minimum of 1/8 in. GSF20JD Instruction Manual...
-
Page 18: Warranty Program
1-877-885-8227, 07:00 A.M. to 04:00 P.M. (EST), Monday through Friday. Manufactured by: Lucas BBQ Co., Ltd. Niuyang Industrial Zone, Liaobu Town, Dong Guan City, Guang Dong, China. Printed in China...
