WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
PROP 65 WARNING:
Chemicals known to the state
of California to cause cancer,
birth defects or other
reproductive harm are created
by the combustion of
propane.
WARNING:
FOR YOUR SAFETY:
For Outdoor Use Only
]
(outside any enclosure)
GSS2520JA
Owner's Manual
4 Burner LP Gas Grill
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@BBQTEK.COM OR
CALL 1-877-885-8227 (TOLL-FREE), 07:00 A.M. – 16:00 P.M.
(EST), MONDAY-FRIDAY.
Service Center: 1-877-885-8227
0
MODEL#GSS2520JA
Advertisement
Table of Contents
Related Manuals for Bond GSS2520JA
Summary of Contents for Bond GSS2520JA
- Page 1 MODEL#GSS2520JA 4 Burner LP Gas Grill WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER: Failure to follow these instructions could result in...
-
Page 2: Grill Operation
NOTE: This grill must be used with propane gas only (propane gas cylinder not included). Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference. GSS2520JA Owner’s Manual... -
Page 3: Table Of Contents
Operating Your Grill....................... 13 Connecting Gas Cylinder ....................13 Checking for Leaks......................14 Lighting Your Grill......................14 Excess flow safety valve reset procedure ..............16 Care and Maintenance ....................17 Troubleshooting ......................18 Warranty Program ......................19 GSS2520JA Owner’s Manual... -
Page 4: For Your Safety
Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open the relief valve and allow gas to escape. Safe Locations For Use Of This Outdoor Grill GSS2520JA Owner’s Manual... -
Page 5: General Information
Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A propane gas cylinder is required for operation. This gas grill is NOT intended for commercial use. 3. Don't obstruct the ventilation opening of the cylinder enclosure. GSS2520JA Owner’s Manual... -
Page 6: Package Contents
Tank clip 1 PC 1 PC 1 PC Body assembly Heat insulator 1 PC 1 PC Left side shelf Grease pan Right side shelf 1 PC Grease pan stopper 1 PC Knob 1 PC Latch magnet 1 PC GSS2520JA Owner’s Manual... -
Page 7: Hardware Contents
M6 Lock Washer M4 Lock Washer M4 Flat Washer GG: 4 PCS HH: 1 PCS Screwdriver M4 Nut Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience). GSS2520JA Owner’s Manual... -
Page 8: Assembly Instructions
Insert one M6 x 15 bolt (AA) into each pre-drilled hole and tighten the bolt by hand. Repeat the procedure with cart right panel (C) and cart back panel (D). d) Go back and tighten all bolts using screwdriver provided. M6 x 15 Bolt 4 PCS GSS2520JA Owner’s Manual... - Page 9 Insert one M4 x 10 bolt (BB) and one M4 flat washer (EE) into each pre-drilled holes. Tighten all the bolts using the screwdriver provided. M4 x 10 bolt 2 PCS M Flat Washer 2 PCS GSS2520JA Owner’s Manual...
- Page 10 Tighten the bolts by hand. d) Repeat the same procedure with the left side shelf (J) and body assembly. e) Go back and tighten all the bolts using the screwdriver provided. M6 x 15 Bolt 2 PCS GSS2520JA Owner’s Manual...
- Page 11 Step12 (install the heating plates, cooking grids and warming rack) a) Place the heating plates (O) upon each burner. b) Put the cooking grids (P) upon the heating plates. Put the warming rack (Q) on the side walls of firebox. GSS2520JA Owner’s Manual...
- Page 12 M4 Flat Washer 2 PCS Step15 (Install the grease cup and grease cup support) a) Hook the grease cup support (R) into the grooves beneath the grease pan. b) Put the grease cup (S) onto the grease cup support. GSS2520JA Owner’s Manual...
- Page 13 Fully Assembled View Right Side Left Side Operating Your Grill CAUTION: Use only the regulator provided. If a replacement is necessary, call our customer service center. The use of unauthorized parts can create an unsafe condition and environment. GSS2520JA Owner’s Manual...
-
Page 14: Operating Your Grill
Do not use matches, lighters or a flame to check for leaks. Do not use grill until all leaks have been stopped. If you are unable to stop a leak, disconnect the propane supply, call for gas appliance service or your local propane gas supplier. GSS2520JA Owner’s Manual... -
Page 15: Checking For Leaks
1. After lighting, observe the burner flame. Make sure all burner ports are lit. 2. If the burner flame goes out during operation, immediately turn the gas “OFF”. Open lid to let the gas clear for at least 5 minutes before re-lighting. GSS2520JA Owner’s Manual... - Page 16 Burner installation and adjustment Normal: Soft blue flames with yellow Out of adjustment: Noisy hard blue Poor combustion: Wavy, yellow tips between I inch - 2 inches high. flames – too much air. flames- too little air. GSS2520JA Owner’s Manual...
-
Page 17: Excess Flow Safety Valve Reset Procedure
When all front burners are lit, close the grill lid. Wait for 10-15 minutes; the temperature should reach 400 – 450°F. WARNING: The cylinder valve always has to be above the horizontal position, for the cylinder to have vapor withdrawl only. GSS2520JA Owner’s Manual... -
Page 18: Care And Maintenance
Inspect burner for damage (cracks or holes). If damage is found, replace with a new burner. Reinstall burner. Make certain the gas valve orifices are correctly positioned, pointing straight into burner inlet (venturi tube). Also, check position of spark electrode. GSS2520JA Owner’s Manual... -
Page 19: Troubleshooting
High or gusting winds. Turn front of grill to face wind or Increase flame height. Low on propane gas. Replace or refill propane tank. Excess flow valve tripped. Refer to the Excessive flow safety valve reset procedure on page 16. GSS2520JA Owner’s Manual... -
Page 20: Warranty Program
1-877-885-8227, 07:00 A.M. to 16:00 P.M. (EST), Monday through Friday. Manufactured by: Lucas BBQ Co., Ltd. Niuyang Industrial Zone, Liaobu Town, Dong Guan City, Guang Dong, China. Printed in China GSS2520JA Owner’s Manual...
