WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
PROP 65 WARNING:
Chemicals known to the state
of California to cause cancer,
birth defects or other
reproductive harm are created
by the combustion of
propane.
WARNING:
FOR YOUR SAFETY:
]
For Outdoor Use Only
(outside any enclosure)
GSF2818KS
Owner's Manual
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@BBQTEK.COM OR
CALL 1-877-885-8227 (TOLL-FREE), 07:00 A.M. – 16:00 P.M.
(EST), MONDAY-FRIDAY.
Service Center: 1-877-885-8227
0
MODEL#GSF2818KS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bond GSF2818KS
Summary of Contents for Bond GSF2818KS
- Page 1 MODEL#GSF2818KS WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER: Failure to follow these instructions could result in fire or explosion that could cause property damage, personal injury or death.
- Page 2 NOTE: This grill must be used with propane gas only (propane gas cylinder not included). Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference. GSF2818KS Owner’s Manual...
-
Page 3: Table Of Contents
Operating Your Grill....................... 12 Connecting Gas Cylinder ....................13 Checking for Leaks......................13 Lighting Your Grill......................14 Excess flow safety valve reset procedure ..............16 Care and Maintenance ....................17 Troubleshooting ......................18 Warranty Program ......................20 GSF2818KS Owner’s Manual... -
Page 4: For Your Safety
Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open the relief valve and allow gas to escape. Safe Locations For Use Of This Outdoor Grill GSF2818KS Owner’s Manual... - Page 5 Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A propane gas cylinder is required for operation. This gas grill is NOT intended for commercial use. 3. Don't obstruct the ventilation opening of the cylinder enclosure. GSF2818KS Owner’s Manual...
-
Page 6: Package Contents
1 PC Cart right side panel 1 PC Cart bottom panel 1 PC Cart Front frame 1 PC 1 PC 1 PC Left door Tank support 1 PC 2 PCS Right door Swivel caster Warming rack 1 PC GSF2818KS Owner’s Manual... -
Page 7: Hardware Contents
M4 Lock Washer Screwdriver M6 Nut LL: 2 PCS KK: 4 PCS M6 x 12 Bolt Wrench Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience. GSF2818KS Owner’s Manual... -
Page 8: Assembly Instructions
Screw one M6 x 15 bolt (AA), one M6 lock washer (CC) and one M6 flat washer (BB) into each pre-drilled holes by hand. Tighten all the bolts using the screwdriver provided. M6 x 15 Bolt 4 PCS M6 Flat washer 4 PCS M6 Lock washer 4 PCS GSF2818KS Owner’s Manual... - Page 9 Push down the pin on the top of left door and insert it into the pre-drilled hole on left top of front rack (W). Repeat the procedure with the right door (L) and cart front frame (W). d) Close the two doors. GSF2818KS Owner’s Manual...
- Page 10 Repeat the same procedure with the left side shelf (C) and body assembly. d) Go back and tighten all the bolts using the screwdriver provided. M6 x 15 Bolt 10 PCS M6 Flat washer 10 PCS M6 Lock washer 10 PCS GSF2818KS Owner’s Manual...
- Page 11 (GG) and one M4 lock washer (FF) into each pre-drilled holes by screwdriver provided. Put the side burner (Q) upon the side burner frame (P). M4 x 15 Bolt 4 PCS M4 Flat washer 4 PCS M4 Lock washer 4 PCS GSF2818KS Owner’s Manual...
- Page 12 15 (Place the gas tank) a) Place the gas tank on the gas holder clip it using the tank clip (I). b) Connect the tank with regulator by screwing regulator collar onto the tank valve. Conduct the leaking test on page GSF2818KS Owner’s Manual...
-
Page 13: Operating Your Grill
DO NOT obstruct the flow of combustion air or ventilation air to the grill. The propane cylinder must be arranged for vapor withdrawal and equipped with a listed overfill prevention device (OPD). GSF2818KS Owner’s Manual... -
Page 14: Connecting Gas Cylinder
If bubbles appear, you have a leak. Go to step 6. Disconnect the regulator from the tank and reconnect. Make sure the connection is tight and secured. Retest with solution. If you continue to see bubbles, replace the cylinder. GSF2818KS Owner’s Manual... -
Page 15: Lighting Your Grill
4. Clean the grill after each use. DO NOT use abrasive or flammable cleaners. This may damage parts of the grill and cause a fire. Lighting Side Burner Open lid while lighting the burner. Lid must remain open while burner is lit. Valve must be in the “OFF” position. GSF2818KS Owner’s Manual... - Page 16 If burner does not light on the first try, turn the control knob to its OFF position and wait 5 minutes for gas to clear before trying again. If burner flame goes out during operation, immediately turn the gas OFF and open lid to let the gas clear for about 5 minutes. Attempt to re-light. GSF2818KS Owner’s Manual...
-
Page 17: Excess Flow Safety Valve Reset Procedure
When all front burners are lit, close the grill lid. Wait for 10-15 minutes; the temperature should reach 400 – 450°F. WARNING: The cylinder valve always has to be above the horizontal position, for the cylinder to have vapor withdrawl only. GSF2818KS Owner’s Manual... -
Page 18: Care And Maintenance
Inspect burner for damage (cracks or holes). If damage is found, replace with a new burner. Reinstall burner. Make certain the gas valve orifices are correctly positioned, pointing straight into burner inlet (venturi tube). Also, check position of spark electrode. GSF2818KS Owner’s Manual... -
Page 19: Troubleshooting
High or gusting winds. Turn front of grill to face wind or Increase flame height. Low on propane gas. Replace or refill propane tank. Excess flow valve tripped. Refer to the Excessive flow safety GSF2818KS valve reset procedure on page 15. Owner’s Manual... - Page 20 If flames are blue and noisy – close flap noise blue flames. at the end of the venturi tubes in 1/8 in. increments until flames are correct. *Propane Models must be open a minimum of 1/8 in. GSF2818KS Owner’s Manual...
-
Page 21: Warranty Program
1-877-885-8227, 07:00 A.M. to 16:00 P.M. (EST), Monday through Friday. Manufactured by: Lucas BBQ Co., Ltd. Niuyang Industrial Zone, Liaobu Town, Dong Guan City, Guang Dong, China. Printed in China GSF2818KS Owner’s Manual...
