JBL MS125S/WH Technical Manual

Technical Manual
JBL MS125S/WH

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance:
• Power Capacity:
• Frequency Range:
• Sensitivity:
• Crossover Frequency:

SYSTEM COMPONENTS:

• Cabinet:
• Grille:
• Low Frequency
Transducer:
DC Resistance:
• Crossover Network/
Terminal Cup:
PACKAGE
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
4 ohms
700W, AES Noise 2800W Peak
35 Hz – 250 Hz (–10dB)
103 dB SPL, 1 Watt @ 1 Meter
200 Hz 6dB/octave internal
(Not For Sale)
128-00393-6,128-00393-00 (Wh)
380mm (15 in.) Cone
Transducer (2032H) (2)
4.3 ohm ± 10%
129-10032-00
Warranty 59660
Owner's Manual 10
981-00043-03
Tech Note 980-00036-00
Logo Sticker, Marquis
950-00032-00
Filler (2)
991-00126-00
Microfoam (8)
Packaging
49790P
Carton
990-00148-00

AURAL SWEEP TEST SPECIFICATIONS:

A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:

PHYSICAL SPECIFICATIONS:

• Enclosure Dimensions:
• Weight:

WARRANTY INFORMATION:

• Refer to Warranty Statement packed with each product.

WIRING DIAGRAM

Speaker,
Low Freq (2)
2032H
(318219-001X)
Cone Repl
C8R2032
* See Note
Back of Page
SCHEMATIC (129-10032-00)
Neutrik
Connector (2)
NL4MPR
INPUT PCB
RED
1+
1+
BLK
1– 1–
2+ N/C
2+
2– 2–
N/C
7.0V Input, 20 Hz to 1.2 kHz
7.0V Input, 20 Hz to 1.2 kHz
922mm x 569mm x 572mm D
(36.3 x 22.4 x 22.5 in. D)
100 lbs. (45.5 kg.)
BLK RED
GRN Network
129-10032-00
GRN/BLK
BLK RED
WHT
WHT/BLK
NETWORK PCB
Busbar L1
T3
3.0mH
T1 T2
Bypass
T2 T1 T3
Passive
CONNECTION INFORMATION
GRN
WHT
L.F.
GRN/BLK 2032H
WHT/BLK
10-03
