Hunter 23783 Parts Manual

PARTS GUIDE PARTS GUIDE
PARTS GUIDE PARTS GUIDE
Using the Parts Guide below, check to make sure all parts are included in the box.
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE.
Before installing your fan, record the following information for your records and warranty assistance.
Fan Parts
Hanger Ball /
7
Downrod
Assembly
46
Blade Set
Hardware
44 Blade Iron Set
65 Wood Screw
100 Locking Screw
Screw, Blade
47
Iron Armature
67 Blade Assembly Screw
If parts are missing or damaged call 1-888-830-1326.
(Not Drawn to Scale)
3
Motor Housing Assembly
68 Flat Washer
69
Canopy Screw
62
2 Ceiling Plate
4 Canopy
75 Balancing Kit
Trim Ring
Switch /
28
Housing
Canopy
Assembly
150 Globe / Shade
(Drawn to Scale)
64 Wood Screw
66 Blade Grommet
70
Machine Screw, 6-32
Model Name
Catalog No.
Serial No.
Date Purchased
Where Purchased
Missing / Broken Parts:
Call 1-888-830-1326
Fan does not work:
1. Reference the Trouble Shooting guide in
your Instruction Manual.
2. Call your Local Service Center.
3. Call Technical Support at 901-248-2222.
For additional information on:
Hunter Products
Dealer Location
Call 1-800-448-6837
www.hunterfan.com
76 Pull Chain Pendant
27
131 Screw, Switch
Housing
Assembly
Wire Nut
Trouble Shooting
Service Center Locator
Pull Chain
78
Low Profile Washer
