- Page 1 ADSL2/2+ Router 8012-R2 User’s Manual Version 1.0 Last Revised: 08-12-10...
-
Page 2: User Manual
(―Marks‖) displayed on this manual are the property of Innoband or other third parties. Users are not permitted to use these Marks without the prior written consent of Innoband or such third party that may own the Mark. IBM is a registered trademark of International Business Machines Corporation. Intel and Pentium are registered trademarks of Intel Corporation. -
Page 3: Table Of Contents
Table of Contents INTRODUCTION ............................1-6 ..........................1-6 ENERAL ESCRIPTION ............................1-6 PECIFICATIONS ..........................1-8 YSTEM REQUIREMENT HARDWARE INSTALLATION ........................2-9 ........................2-9 ARDWARE EQUIREMENTS ............................. 2-9 RONT ANEL ............................... 2-9 ANEL ........................2-10 ESET ACTORY EFAULTS ........................2-10 ONNECTION ECHANISM SOFTWARE CONFIGURATION ....................... - Page 4 3.4.5 UPnP Configuration ........................3-45 3.4.6 RIP Configuration ..........................3-46 ........................3-48 DVANCE ONFIGURATION 3.5.1 ARP table ............................3-48 3.5.2 Bridging ............................3-49 3.5.3 Routing ............................. 3-50 3.5.4 SNMP Configuration ........................3-52 3.5.5 IP QoS .............................. 3-53 3.5.6 Remote Access..........................3-55 3.5.7 Others ..............................
- Page 5 APPENDIX B: FREQUENTLY ASKED QUESTIONS ..................4-78 APPENDIX C: TROUBLESHOOTING GUIDE ....................4-80 APPENDIX D: GLOSSARY ..........................4-83 APPENDIX E: REGULATION ..........................4-90 APPENDIX F: WARRANTIES ..........................4-91 APPENDIX G: CONTACT INFORMATION ....................4-93...
-
Page 6: Introduction
1 Introduction 1.1 General Description Congratulations on your purchase of the Innoband 1-Port ADSL2/2+ Router. This device is a 1-Port Switch built-in ADSL2/2+ Router that allows ADSL/ADSL2/ADSL2+ connectivity for residential, industries and SOHO environments. ADSL2/2+ is a transmission technology used to carry user data over a single twisted-pair line between the Central Office and the Customer Premises. - Page 7 Network Protocols & Features IP Routing – RIPv1 and RIPv2. Support Static Routing. Support DHCP Server, Relay and Client. Support DDNS. Support IP QoS features. Support IGMP Proxy Support IP Filter and MAC Filter ...
-
Page 8: System Requirement
1.3 System requirement Check and confirm that your system conforms to the following minimum requirements: Personal computer ( PC/Notebook ). Pentium III compatible processor and above. Ethernet LAN card installed with TCP/IP protocol. 64 MB RAM or more. ... -
Page 9: Hardware Installation
2 Hardware Installation 2.1 Hardware Requirements One 1-Port ADSL2/2+ Router One Power Adapter One CAT-5 Ethernet Cable One RJ-11 ADSL Cable One CD-ROM ( Manual / Quick Setup Guide ) If any of the above items are damaged or missing, please contact your dealer immediately. 2.2 Front Panel The 1-Port ADSL2/2+ Router’s LEDs indicators display information about the device’s status. -
Page 10: Reset Factory Defaults
ADSL Port for connecting to the DSL line. 10/100Mbps Ethernet Ports for connecting to network devices Power Power adapter connection Reset Restore the 1-Port ADSL2/2+ Router to factory default setting 2.4 Reset Factory Defaults The Restore Factory Defaults feature will set the device to its factory default configuration by resetting the 1-Port ADSL2/2+ Router. - Page 11 Service Provider (ISP). You will need one or more of the following configuration parameters to connect your 1-Port ADSL2/2+ Router to the Internet: VPI/VCI parameters Multiplexing Method or Protocol Type or Encapsulation Type Host and Domain Names ISP Login Name and Password ISP Domain Name Server (DNS) Address Fixed or Static IP Address.
- Page 12 Figure below shows the overall hardware connection mechanism of your 1-Port ADSL2/2+ Router. Following are the steps to properly connect your 1-Port ADSL2/2+ Router: Turn off your computer/notebook. Connect the ADSL port of your 1-Port ADSL2/2+ Router to the wall jack of the ADSL/ADSL2/ADSL2+ Line with a RJ-11 cable.
-
Page 13: Software Configuration
3 Software Configuration The DSL device is an ADSL 2/2+ router. When you power on the device, the system will boot up and connect to ADSL automatically. The system provides a PVC for bridge test by default. The default configurations for the system are listed below. ... - Page 14 Once you have connected to ADSL router. You will see the status page. This page displays the ADSL modem/router’s current status and settings. This information is read-only. Click the ―Refresh‖ button to update the status page. Function buttons in this page: Refresh Click to get the updated status of the DSL device.
-
Page 15: Setup Wizard
3.1 Setup Wizard The Setup Wizard is a presetting wizard which meant to help you install the 1-port ADSL2/2+ Router. Click on “Setup Wizard” and the following screen will pop-up: Step 1: Select the Encapsulation Mode (see following page for more details). Step 2: Enter your VPI and VCI values provided by your ISP. - Page 16 With the following “Encapsulation”, enter the PPP User Name and Password as shown below: PPPoA VC-Mux PPPoA LLC PPPoE VC-Mux PPPoE LLC Half-Bridged VC-Mux Half-Bridged LLC Manually enter your “User Name” and “Password” which will be provided by your Step 1: Service Provider (ISP).
- Page 17 With the following “Encapsulation”, the following window will pop-up: 1483 Routed IP VC-Mux (Fixed IP only) 1483 Routed IP LLC (Fixed IP only) 1483 Bridged IP VC-Mux (DHCP only) 1483 Bridged IP LLC (DHCP only) 1483 MER VC-Mux (Fixed IP or DHCP) ...
- Page 18 Fixed IP Step 1: Click the radio button to enable Fixed IP option. Manually enter the “Local IP Address”, “Subnet Mask”, “Remote IP Address” (Default Step 2: Gateway) and “DNS” which will be provided by your ISP. Click “Save” after your setting. Step 3: Click Commit and Reboot button to commit changes to system memory and reboot router.
- Page 19 DHCP (Get IP dynamically from ISP) Step 1: Click the radio button to enable DHCP option. Click the “Save” button to confirm your setting. Step 2: Click Commit and Reboot button to commit changes to system memory and reboot router. Note: New parameters will permanently take effect only after changes are committed into flash memory and system is rebooted.
- Page 20 When successfully rebooted, the following page with the device setup information will be displayed: Ensure that the changes highlighted above reflect the settings that your ISP has provided you. 3-20...
-
Page 21: Lan Configuration
3.2 LAN Configuration Fields in this page: Field Description The IP address your LAN hosts use to identify the device’s LAN port. IP Address Subnet Mask LAN subnet mask. Function buttons in this page: Apply Changes Click to save the setting to the configuration. New parameters will take effect after save into flash memory and reboot the system. -
Page 22: Wan Configuration
3.3 WAN Configuration There are three sub-menu for WAN configuration: [Channel Config], [ATM Settings], and [ADSL Settings]. 3.3.1 Channel Configuration ADSL modem/router comes with 8 ATM Permanent Virtual Channels (PVCs) at the most. There are mainly three operations for each of the PVC channels: add, delete and modify. And there are several channel modes to be selected for each PVC channel. - Page 23 Fields in the Auto-PVC Search block: Field Description Virtual Path Identifier. Virtual Channel Identifier. The VCI, together with VPI, is used to identify the next destination of a cell as it passes through to the ATM switch. Function buttons for Auto-PVC Search: Apply Click to save the Enable Auto-PVC Search setting to the configuration.
-
Page 24: Atm Settings
3.3.2 ATM Settings The page is for ATM PVC QoS parameters setting. The DSL device support 4 QoS mode —UBR/CBR/rt-VBR/nrt-VBR. Fields in this page: Field Description Virtual Path Identifier. This is read-only field and is selected on the Select column in the Current ATM VC Table. - Page 25 exceed. CDVT Cell delay variation tolerance, the maximum amount of cell delay variation that can be accommodated. Cell delay variation measures the random inter-arrival times of cells within an ATM connection due to cell transfer delay caused by buffering, multiplexing, and so on. Sustained Cell Rate, measured in cells/sec., is the average cell rate over the duration of the connection.
-
Page 26: Adsl Setting
3.3.3 ADSL Setting The ADSL setting page allows you to select any combination of DSL training modes. Fields in this page: Field Description ADSL modulation Choose prefered xdsl standard protocols. G.lite : G.992.2 Annex A G.dmt : G.992.1 Annex A T1.413 : T1.413 issue 2 ADSL2 : G.992.3 Annex A ADSL2+ : G.992.5 Annex A... -
Page 27: Services Configuration
Apply Changes Click to save the setting to the configuration and the modem will be retrained. Note: New parameters will permanently take effect only after changes are committed into flash memory and system is rebooted. Go to “Admin Commit/Reboot” to do so. Services Configuration 3.4.1 DHCP Settings You can configure your network and DSL device to use the Dynamic Host Configuration Protocol (DHCP). - Page 28 Fields in this page: Field Description IP Pool Range Specify the lowest and highest addresses in the pool. Max Lease Time The Lease Time is the amount of time that a network user is allowed to maintain a network connection to the device using the current dynamic IP address. At the end of the Lease Time, the lease is either renewed or a new IP is issued by the DHCP server.
-
Page 29: Dhcp Relay
Assign IP Click to assign IP to the Host MAC Address. Delete Assigned IP Click to delete the assigned IP. Close Click to close the window. 3.4.1.2 DHCP Relay Some ISPs perform the DHCP server function for their customers’ home/small office network. In this case, you can configure this device to act as a DHCP relay agent. -
Page 30: Dns Server
3.4.2.1 DNS Server This page is used to select the way to obtain the IP addresses of the DNS servers. Fields in this page: Field Description Attain DNS Select this item if you want to use the DNS servers obtained by the WAN interface Automatically via the auto-configuration mechanism. -
Page 31: Dynamic Dns
3.4.2.2 Dynamic DNS Each time your device connects to the Internet, your ISP assigns a different IP address to your device. In order for you or other users to access your device from the WAN-side, you need to manually track the IP that is currently used. - Page 32 On the Dynamic DNS page, configure the following fields: Fields in this page: Field Description Enable Check this item to enable this registration account for the DNS server. DDNS provider There are two DDNS providers to be selected in order to register your device with: DynDNS and TZO.
-
Page 33: Firewall Configuration
3.4.3 Firewall Configuration Firewall contains several features that are used to deny or allow traffic from passing through the device. 3.4.3.1 IP/Port Filtering The IP/Port filtering feature allows you to deny/allow specific services or applications in the forwarding path. Fields on the first setting block: Field Description Outgoing Default... - Page 34 Fields on the second setting block: Field Description Direction Traffic forwarding direction. Protocol There are 3 options available: TCP, UDP and ICMP. Rule Action Deny or allow traffic when matching this rule. Source IP Address The source IP address assigned to the traffic on which filtering is applied. Source Subnet Mask Subnet-mask of the source IP.
-
Page 35: Mac Filtering
3.4.3.2 MAC Filtering The MAC filtering feature allows you to define rules to allow or deny frames through the device based on source MAC address, destination MAC address, and traffic direction. Fields on the first setting block: Field Description Outgoing Default Action Specify the default action on the LAN to WAN bridging/forwarding path. - Page 36 Fields on the second setting block: Field Description Direction Traffic bridging/forwarding direction. Rule Action Deny or allow traffic when matching this rule. Source MAC Address he source MAC address. It must be xxxxxxxxxxxx format. Blanks can be used in the MAC address space and are considered as don’t care. Destination MAC Address The destination MAC address.
-
Page 37: Port Forwarding
3.4.3.3 Port Forwarding Firewall keeps unwanted traffic from the Internet away from your LAN computers. Add a Port Forwarding entry will create a tunnel through your firewall so that the computers on the Internet can communicate to one of the computers on your LAN on a single port. Fields in this page: Field Description... - Page 38 Function button for this first setting block: Apply Changes Click to save the setting of default actions to the configuration. Function buttons for this second setting block: Click to add the rule entry to the configuration. Function buttons for the Current Port Forwarding Table: Delete Selected Delete the selected port forwarding rules from the forwarding table.
-
Page 39: Url Blocking
3.4.3.4 URL Blocking A URL is a web address that is normally typed into a web browser. For instance www.yahoo.com, www.msn.com are all URLs. URL Blocking allows you to block URLs based upon keywords that you enter into a box. Blocking URLs prevents people on your network from accessing these websites. These keywords may be full URL's or they may just be words. -
Page 40: Domain Blocking
Function buttons in this page: Apply Changes Click to save the setting to the configuration. Delete Selected Delete selected keyword entry from the keyword filtering table. Delete All Delete all keyword entry from the keyword filtering table. 3.4.3.5 Domain Blocking This page is used to configure the Blocked domain. - Page 41 Function buttons for the Domain Block Table: Delete Selected Delete selected domain entry from the Domain Block table. Delete All Delete all domain entry from the Domain Block table. Note: Many web sites construct pages with images and content from other web sites. Access will be forbidden if you do not enable all the web sites used to construct a page.
-
Page 42: Dmz
3.4.3.6 A DMZ (Demilitarized Zone) allows a single computer on your LAN to expose ALL of its ports to the Internet. Enter the IP address of that computer as a DMZ (Demilitarized Zone) host with unrestricted Internet access. When doing this, the DMZ host is no longer behind the firewall. Fields in this page: Field Description... -
Page 43: Igmp Proxy Configuration
3.4.4 IGMP Proxy Configuration Multicasting is useful when the same data needs to be sent to more than one hosts. Using multicasting as opposed to sending the same data to the individual hosts uses less network bandwidth. The multicast feature also enables you to receive multicast video stream from multicast servers. IP hosts use Internet Group Management Protocol (IGMP) to report their multicast group memberships to neighboring routers. - Page 44 Fields in this page: Field Description IGMP Proxy Enable/disable IGMP proxy feature Proxy Interface The upstream WAN interface is selected here. Function buttons in this page: Apply Changes Click to save the setting to the configuration. Note: New parameters will permanently take effect only after changes are committed into flash memory and system is rebooted.
-
Page 45: Upnp Configuration
3.4.5 UPnP Configuration The DSL device supports a control point for Universal Plug and Play (UPnP) version 1.0, and supports two key features: NAT Traversal and Device Identification. This feature requires one active WAN interface. In addition, the host should support this feature. In the presence of multiple WAN interfaces, select an interface on which the incoming traffic is present. -
Page 46: Rip Configuration
3.4.6 RIP Configuration RIP is an Internet protocol you can set up to share routing table information with other routing devices on your LAN, at your ISP’s location, or on remote networks connected to your network via the ADSL line. Most small home or office networks do not need to use RIP;... - Page 47 Function buttons for the second setting block in this page: Apply Changes Click to save the setting of this setting block to the system configuration Fields on the second setting block: Field Description Interface The name of the interface on which you want to enable RIP. Receive Mode Indicate the RIP version in which information must be passed to the DSL device in order for it to be accepted into its routing table.
-
Page 48: Advance Configuration
3.5 Advance Configuration 3.5.1 ARP table This table shows a list of learned MAC addresses. Function buttons in this page: Refresh Update the status. 3-48... -
Page 49: Bridging
3.5.2 Bridging You can enable/disable 802.1d Spanning Tree Protocol and set MAC address ageing time in this page. Fields in this page: Field Description Ageing Time Set the Ethernet address ageing time, in seconds. After [Ageing Time] seconds of not having seen a frame coming from a certain address, the bridge will time out (delete) that address from Forwarding DataBase (fdb). -
Page 50: Routing
3.5.3 Routing The Routing page enables you to define specific route for your Internet and network data. Most users do not need to define routes. On a typical small home or office LAN, the existing routes that set up the default gateways for your LAN hosts and for the DSL device provide the most appropriate path for all your Internet traffic. - Page 51 Fields in this page: Field Description Enable Check to enable the selected route or route to be added. Destination The network IP address of the subnet. The destination can be specified as the IP address of a subnet or a specific host in the subnet. It can also be specified as all zeros to indicate that this route should be used for all destinations for which no other route is defined (this is the route that creates the default gateway).
-
Page 52: Snmp Configuration
3.5.4 SNMP Configuration Simple Network Management Protocol (SNMP) is a troubleshooting and management protocol that uses the UDP protocol on port 161 to communicate between clients and servers. The DSL device can be managed locally or remotely by SNMP protocol. Fields in this page: Field Description... -
Page 53: Ip Qos
Function buttons in this page: Apply Changes Click to save SNMP settings to system configuration. Reset Click to reset SNMP settings to default configuration. Note: New parameters will permanently take effect only after changes are committed into flash memory and system is rebooted. Go to “Admin Commit/Reboot”... - Page 54 Fields on the first setting block of this page: Field Description IP QoS Enable/disable the IP QoS function. Source IP The IP address of the traffic source. Source Netmask The source IP netmask. This field is required if the source IP has been entered. Source Port The source port of the selected protocol.
-
Page 55: Remote Access
Function buttons for this second setting block: Click to add the rule entry to the configuration. Function buttons for the IP QoS Rules Table: Delete Selected Delete selected IP QoS rules from the table. You can click the checkbox at the Select column to select the IP QoS rule. -
Page 56: Others
3.5.7 Others IP Pass Through: Although the Router mode is capable of terminating the PPP in the modem and hence does not require PPPoE client software on the host PC, there are some disadvantages to Router mode when only single-user support is required. For instance, Router mode uses NAT which requires ALG support. -
Page 57: Diagnostic
3.6 Diagnostic The Diagnostics page allows you to run a series of diagnostic tests of your system software and hardware connections. 3.6.1 Ping Diagnostic This page allows you to run the Ping Diagnostic test. Fields in this page: Field Description Host Address Enter the host address which your ISP provider provided. -
Page 58: Atm Loopback
3.6.2 ATM Loopback This page shows to perform the VCC loopback function to check the connectivity of the VCC. The ATM OAM Loopback Mode Detection feature allows the router to automatically detect when a peer ATM interface is in loopback mode. When loopback is detected on an interface where end-to-end F5 Operation, Administration, and Maintenance (OAM) is enabled, the impacted permanent virtual circuit (PVC) is moved to a DOWN state, and traffic is suspended. -
Page 59: Adsl
3.6.3 ADSL This page shows the DSL line condition diagnostic result. Click on the Start button to start the ADSL diagnostic. It takes about 3 minutes to complete this diagnostic test. 3-59... -
Page 60: Diagnostic Test
3.6.4 Diagnostic Test The Diagnostic Test page shows the test results for the connectivity of the physical layer and protocol layer for both LAN and WAN sides. Fields in this page: Field Description Select the Internet The available WAN side interfaces are listed. You have to select one for the WAN Connection side diagnostic. -
Page 61: Admin
3.7 Admin 3.7.1 Commit/Reboot Whenever you use the Web configuration to change system settings, the changes are initially placed in temporary storage. These changes will be lost if the device is reset or turn off. To save your change for future use, you can use the commit function. -
Page 62: Backup/Restore
3.7.2 Backup/Restore This page allows you to backup and restore your configuration into and from file in your host. Function buttons in this page: Save Save the setting to file Load Settings from Files Browse a configuration file for uploading to the router Reset Settings to Default Reset the router setting to default values. -
Page 63: System Log
3.7.3 System Log This page shows the DSL device’s system log. Fields in this page: Field Description System Log Click on the relevant radio button to enable or disable the function. Function buttons in this page: Apply Changes Click to complete enabling or disabling system log function. Save…... -
Page 64: Password
3.7.4 Password The first time you log into the system, you use the default password. There are two-level logins: admin and user. The admin and user password configuration allows you to change the password for administrator and user. Fields in this page: Field Description User Name... -
Page 65: Upgrade Firmware
3.7.5 Upgrade Firmware To upgrade the firmware for the DSL device: Click the Browse button to select the firmware file. Confirm your selection. Click the Upload button to start upgrading. Do not turn off your DSL device or press the Reset button while this procedure is in progress. -
Page 66: Acl Config
3.7.6 ACL Config The Access Control List (ACL) is a list of permissions attached to the DSL device. The list specifies who is allowed to access this device. If ACL is enabled, all hosts cannot access this device except for the hosts with IP address in the ACL table. - Page 67 Select one or more existing ACL entry(s) by clicking the checkbox(s) at the Select column of the ACL Table. Click Delete Selected button to remove the selected ACL entry(s) from the ACL Table. Delete All Click to delete all the ACL entries from the ACL Table. Note: New parameters will permanently take effect only after changes are committed into flash ...
-
Page 68: Time Zone
3.7.7 Time Zone Simple Network Timing Protocol (SNTP) is a protocol used to synchronize the system time to the public SNTP servers. The DSL device supports SNTP client functionality in compliance with IETF RFC2030. SNTP client functioning in daemon mode which issues sending client requests to the configured SNTP server addresses periodically can configure the system clock in the DSL device. -
Page 69: Statistics
3.8 Statistics The DSL device shows the different layer of network statistics information. 3.8.1 Interfaces You can view statistics on the processing of IP packets on the networking interfaces. You will not typically need to view this data, but you may find it helpful when working with your ISP to diagnose network and Internet data transmission problems. -
Page 70: Adsl
3.8.2 ADSL This page shows the ADSL line statistic information. 3-70... -
Page 71: Channel Mode Configuration
4 Channel Mode Configuration ADSL router supports multiple channel operation modes. This Chapter will show procedures to configure the router by adding new PVC channels with different VPI/VCI values to the Current ATM VC Table. By default, the DSL device is set to Bridge mode with DHCP Server enabled. 4.1 Bridge Mode 1. -
Page 72: 1483 Mer (Mac Encapsulating Routing) Mode
4.2 1483 MER (MAC Encapsulating Routing) Mode 1. Open your web browser page, for example Internet Explorer. 2. Type in 192.168.1.1 in your address bar. 3. On the left panel of your DSL device’s web configuration page, click on ―WAN Channel Configuration‖. -
Page 73: Pppoe Mode
4.3 PPPoE Mode 1. Open your web browser page, for example Internet Explorer. 2. Type in 192.168.1.1 in your address bar. 3. On the left panel of your DSL device’s web configuration page, click on ―WAN Channel Configuration‖. 4. Select the Channel Mode to ―PPPoE‖. Set the parameters VPI/VCI and Encapsulation mode according to the CO DSLAM’s setting provided by your ISP. -
Page 74: Pppoa Mode
4.4 PPPoA Mode 1. Open your web browser page, for example Internet Explorer. 2. Type in 192.168.1.1 in your address bar. 3. On the left panel of your DSL device’s web configuration page, click on ―WAN Channel Configuration‖. 4. Select the Channel Mode to ―PPPoA‖. Set the parameters VPI/VCI and Encapsulation mode according to the CO DSLAM’s setting provided by your ISP. -
Page 75: 1483 Routed Mode
4.5 1483 Routed Mode 1. Open your web browser page, for example Internet Explorer. 2. Type in 192.168.1.1 in your address bar. 3. On the left panel of your DSL device’s web configuration page, click on ―WAN Channel Configuration‖. 4. -
Page 76: Appendix A: Router Terms
Appendix A: Router Terms What is a firewall? A firewall is a device that protects one network from another, while allowing communication between the two. A firewall incorporates the functions of the NAT router, while adding features for dealing with a hacker intrusion or attack. -
Page 77: What Is A Gateway
You should use the DMZ when you want to run a server that others will access from the Internet. Internal programs and servers (like print servers, etc) should NOT be connected to the DMZ What is a Gateway? The Internet is so large that a single network cannot handle all of the traffic and still deliver a reasonable level of service. -
Page 78: Appendix B: Frequently Asked Questions
Appendix B: Frequently Asked Questions The Frequently Asked Questions addresses common questions regarding 1-Port ADSL2/2+ Router settings. Some of these questions are also found throughout the guide, in the sections to which they reference. How do I determine if a link between the Ethernet card (NIC) and the 1-Port ADSL2/2+ Router has been established? Ans. - Page 79 I forgot my password. Ans. Reset the 1-Port ADSL2/2+ Router to factory default by pressing the Reset button for more than 5 seconds and then releasing it. If you are still getting prompted for a password when saving settings, then perform the following steps: Access the 1-Port ADSL2/2+ Router’s web-based utility by going to http://192.168.1.1 or the IP address of the 1-Port ADSL2/2+ Router.
-
Page 80: Appendix C: Troubleshooting Guide
Appendix C: Troubleshooting Guide The Troubleshooting Guide provides answers to common problems regarding the 1-Port ADSL2/2+ Router settings, connections, and computer settings. The 1-Port ADSL2/2+ Router does not work (None of the LEDs light up) Ans. Check the following: 1. Make sure that the 1-Port ADSL2/2+ Router is plugged into a power socket. 2. - Page 81 Failed to configure the 1-Port ADSL2/2+ Router through web browser (By a client PC in LAN) Ans. Check the following: 1. Check the hardware connection of the 1-Port ADSL2/2+ Router’s LAN port. The LED will lit when a proper connection is made. 2.
- Page 82 I need to upgrade the Firmware. Ans. In order to upgrade the Firmware with the latest features, check your local dealer or ISP for technical support. Before proceed the upgrading process, check the following details: 1. Download the latest Firmware and save at your pointed location. 2.
-
Page 83: Appendix D: Glossary
Appendix D: Glossary The Glossary provides an explanation of terms and acronyms discussed in this user guide. 10BASE-T: IEEE 802.3 specification for 10 Mbps Ethernet over twisted pair wiring. 100BASE-Tx: IEEE 802.3 specification for 100 Mbps Ethernet over twisted pair wiring. 802.1x: 802.1x defines port-based, network access control used to provide authenticated network access and automated data encryption key management. - Page 84 authenticated using a one-way hashing function. CLP: Cell Loss Priority: ATM cells have two levels of priority, CLP0 and CLP1. CLP0 is of higher priority, and in times of high traffic congestion, CLP1 error cells may be discarded to preserve the Cell Loss Ratio of the CLP0 cells.
- Page 85 DSLAM: Digital Subscriber Line Access Multiplexer: Using multiplexing techniques, a DSLAM receives signals from customer DSL lines and places the signals on a high-speed backbone line. DSLAMs are typically located at a telephone company’s CO (Central Office). Encapsulation: The inclusion of one data structure within another. For example, packets can be encapsulated in an ATM frame during transfer.
- Page 86 Half Duplex: Data transmission can be transmitted and received on the same signal medium, but not simultaneously. Half Duplex lines are bi-directional. HEC: Headed Error Control: ATM error checking by using a CRC algorithm on the fifth octet in the ATM cell header to generate a check character.
- Page 87 send packet with information field larger than this value. MSS: Maximum Segment Size: The largest size of data that TCP will send in a single, unfragmented IP packet. When a connection is established between a LAN client and a host in the WAN side, the LAN client and the WAN host will indicate their Maximum Segment Size during the TCP connection handshake.
- Page 88 PVC: Permanent Virtual Circuit: A software defined logical connection in a network; A Virtual Circuit that is permanently available to the user. RIP: Routing Information Protocol: A management protocol that ensures that all hosts in a particular network share the same information about routing paths. In a RIP, a host computer will send its entire routing table to another host computer every X seconds, where X is the supply interval.
- Page 89 Trellis Code: An advanced method of FEC (Forward Error Correction). When enabled, it makes for better error checking at the cost of slower packet transmission. Setting Trellis Code to Disabled will cause increased packet transmission with decreased error correction. TTL: Time To Live: A value in an IP packet that indicates whether or not the packet has been propagating through the network too long and should be discarded.
-
Page 90: Appendix E: Regulation
But if it does, the user will be required to correct the interference at his or her own expense. The authority to operate this equipment is conditioned by the requirement that no modifications will be made to the equipment unless Innoband expressly approves the changes or modifications. -
Page 91: Appendix F: Warranties
Appendix F: Warranties Innoband warrants that equipment furnished will be free from defects in material and workmanship for a period of one year from the confirmed date of purchase of the product new from the purchase location. Upon written notice of any such defect, the manufacturer will, at its option, repair or replace the defective item under the terms of this warranty, subject to the provisions and specific exclusions listed herein. -
Page 92: Registration Card
Registration Card Innoband 8012-R2 Product Registration Name: Company: Address: City/State/Zip: Phone: E-mail: Serial Number: Purchased from: Date of Purchase: Please cut out the above Product Registration Card and send in with a self-addressed stamped envelope Innoband Technologies, Inc. 2526 Qume Dr Ste21,... -
Page 93: Appendix G: Contact Information
We would more than love to help if you have further technical questions, please visit our Website at http://www.innoband.com or send E-mail to support@innoband.com To purchase accessories or replacement parts for this router, please visit http://www.innocow.com Company Address Innoband Technologies, Inc 2526 Qume Dr Ste21, San Jose, CA 95131 4-93...
