  • Page 1 ADSL2/2+ Router 8012-B1 User’s Manual Version 1.0 Last Revised: 11-07-11...

  • Page 2: User Manual

    Innoband is a trademark of Innoband Technologies, Inc. The trademarks, logos and service marks (―Marks‖) displayed on this manual are the property of Innoband or other third parties. Users are not permitted to use these Marks without the prior written consent of Innoband or such third party that may own the Mark. IBM is a registered trademark of International Business Machines Corporation.

  • Page 3: Table Of Contents

    Panel Layout ......................4 2.1.1 Front Panel ...................... 4 2.1.2 Back Panel ....................... 4 2.1.3 8012-B1’s Back Panel ..................5 Installation Environment ..................5 2.2.1 Physical Environment Requirement ..............5 2.2.2 Recommended Working Environment ..............5 Hardware Installation ....................5 2.3.1...
  • Page 4 Windows 2000 PCs ...................... 48 Windows Me PCs ......................49 Assigning static Internet information to your PCs ............. 49 Appendix B - Troubleshooting ................51 Troubleshooting Suggestions ....................51 Diagnosing Problem using IP Utilities ..................53 Ping ........................... 53 nslookup ........................53 Appendix C - Glossary ..................

  • Page 5: Chapter 1: Product Introduction

    Chapter 1: Product Introduction 1.1 Product Overview Our INNOBAND 8012-B1 which complies with ADSL, ADSL2 and ADSL2+ standards is an ADSL terminal with one Ethernet port. It supports multiple network protocols, up to 24Mbps downstream rate and 1Mbps upstream rate, as well as NAT Routing and Bridging functions. With stable performance, exquisite appearance and s great compatibility, it is the best choice for SOHO, small enterprise and individual users to access the Internet.

  • Page 6: Chapter 2: Hardware Description

    Chapter 2: Hardware Description 2.1 Panel Layout 2.1.1 Front Panel 8012-B1‘s Front Panel On the front panel, there are 4 LED indicators through whose working statuses we can tell whether the Router is working correctly. Below is the description of them.

  • Page 7: 8012-B1'S Back Panel

    Insert a telephone line to the splitter‘s ―Line‖ port.  Connect one end of a network cable to 8012-B1‘ LAN (RJ45) port and the other end to PC‘s NIC.  Plug the included power adapter into the Power socket on 8012-B1 Router and turn on the power switch.
  • Page 8 Tip: To protect the device against thunderbolt attack, disconnect power adapter and telephone line connection.

  • Page 9: Chapter 3: Login To Web Management Interface

    Chapter 3: Login to Web Management Interface 3.1 Configuring PC 1. Right click ―My Network Places‖ on the desktop and select ―Properties‖. 2. Right click ―Local Area Connection‖ in the appearing window and select ―Properties‖. 3. Select ―Internet Protocol (TCP/IP)‖ and click ―Properties‖. 4.

  • Page 10: Verifying Connection

    b. ―Use the Following IP Address‖ is shown in the figure below: IP address: 192.168.1.XXX：(XXX is any number from 2~254) Subnet Mask: 255.255.255.0 Gateway: 192.168.1.1 DNS server: Enter your local DNS server address (consult your ISP if necessary). Or use the router as the DNS proxy server.

  • Page 11: Login To Router

    3.3 Login to Router 1. To access the router‘s Web-based interface, launch a web browser such as Internet Explorer and enter the Router‘s default IP address, http://192.168.1.1 and press ―Enter‖. 2. Input ―admin‖ as both the ―User Name‖ and ―Password‖ and then click ―OK‖ (Both user name and password are admin by default) 3.

  • Page 12: Chapter 4: Quick Setup Guide

    Chapter 4: Quick Setup Guide On the ―wizard‖ page, you are required to enter VPI and VCI values. Consult your ISP or select the corresponding country and area if you are not clear about your local VCI and VPI. Then click ―Next‖. 4.1 Configuring PPPoA 1.
  • Page 13 3. Click ―Next‘‘ and enable WAN service (enabled by default). 4. Click ―Next‖ to review your configurations on the following page.
  • Page 14 5. Click ―Save/Reboot‖ to bring your configurations into effects.

  • Page 15: Configuring Pppoe

    4.2 Configuring PPPoE 1. Select PPPoE 2. Click ―Next‖, enter the user name and password provided by your ISP and default values for other options. For detailed information of these parameters, please refer to introductions later. 3. Click ―Next‘‘ and enable WAN service (enabled by fault).
  • Page 16 4. Click ―Next‖ to review your configurations on the following page. 5. Click ―Save/Reboot‖ to bring your configurations into effects.

  • Page 17: Configuring Mer (Mac Encapsulation Routing)

    4.3 Configuring MER (MAC Encapsulation Routing) 1. Select MER connection 2. Click ―Next‖ and enter an IP address in the corresponding field if your ISP provided it. 3. Select ―Obtain IP Address Automatically‖ if your ISP didn‘t provide you a static IP address.
  • Page 18 4. Click ―Next‖. We recommend you to enable NAT and firewall functions. 5. Click ―Next‖ to review your configurations on the following page.
  • Page 19 6. Click ―Save/Reboot‖ to bring your configurations into effects.

  • Page 20: Configuring Ipoa

    4.4 Configuring IPoA 1. Select IPoA 2. Click ―Next‖ and enter an IP address and a subnet mask provided by your ISP. 3. Click ―Next‖. We recommend you to enable NAT and firewall functions.

  • Page 21: Configuring Bridge

    4. Click ―Next‖ to review your configurations on the following page. 5. Click ―Save/Reboot‖ to bring your configurations into effects. 4.5 Configuring Bridge 1. Select bridging 2. Enable bridge service If you select bridging mode you must enable this function. By default it is enabled.
  • Page 22 3. Click ―Next‖ to display the following page. It displays all the configured options by you. Click ―Save‖ to save your configurations. To activate them, click the ―Save/Reboot‖ button...

  • Page 23: Chapter 5: Configuration Guide

    Chapter 5: Configuration Guide 5.1 Status 1. Click ―Running Status‖---―Summary‖ to display ―Device Info‖ and ―DSL‖ information. Note: Default Gateway：Default gateway is not displayed in complete bridge mode, while in other modes (like PPPoE / PPPoA) it displays the IP address of an uplink device. Primary/ Secondary DNS Address: DNS address is obtained from an uplink device in PPPoA / PPPoE mode while it is not displayed in complete bridge mode.

  • Page 24: Advanced Setting

    5.2 Advanced Setting 5.2.1 WAN Click ―WAN‖ to add/modify WAN information. Note: You need to reboot the router to bring new configurations into effects after you modify or add new information VPI (Virtual Path Identifier)：the virtual path between two points in ATM network. Its valid value is any number from 0 to 255 VCI (Virtual Channel Identifier)：the virtual channel between two points in ATM network.
  • Page 25 Encapsulation Mode：VC/MUX / LLC/ENCAPSULATION When you select a connection mode the encapsulation mode will automatically change to adapt to the selected mode. We recommend you not to change the default setting. 2. Click ―Next‖ to display the following page. 1）Authentication Method： Auto/PAP/CHAP/MSCHAP.

  • Page 26: Pppoe Mode

    Enable IGMP Multicast: IGMP agent. For example, check this option when you want to enable the IPTV in the PPPoE mode. Enable WAN Service: enabled by default. It is recommended not to disable it, unless you do not need to activate your WAN.
  • Page 27 Encapsulation Mode： VC/MUX or LLC/SNAP-BRIDGING When you select a connection type the encapsulation mode will automatically change to adapt to the selected type. We recommend you not to change the default setting. 2. Click ―Next‖ to display the following page. 1）Authentication Method：Auto/PAP/CHAP/MSCHAP.
  • Page 28 Enable IGMP Multicast: IGMP agent. For example, check this option when you want to enable the IPTV in the PPPoE mode. Enable WAN Service: enabled by default. It is recommended not to disable it, unless you do not need to activate your WAN.
  • Page 29 Encapsulation Mode：VC/MUX or LLC/SNAP-BRIDGING When you select a connection type the encapsulation mode will automatically change to adapt to the selected type. We recommend you not to change the default setting. 2. Click ―Next‖ to display the following page. Obtain an IP address automatically: If you enable this option, the IP address and other parameters will be automatically obtained from your ISP.
  • Page 30 Enable IGMP Multicast: IGMP agent. For example, when you want to enable IPTV in PPPoE mode, you need to enable this function. Enable WAN Service: By default this function is enabled. And you are recommended not to disable it, unless you do not need to activate your WAN.
  • Page 31 Encapsulation Mode：VC/MUX or LLC/SNAP-BRIDGING When you select a connection type the encapsulation mode will automatically change to adapt to the selected type. We recommend you not to change the default setting. 2. Click ―Next‖ to display the following page. WAN IP Address: the WAN IP address provided by your ISP.WAN IP Address: the WAN IP address provided by your ISP.

  • Page 32: Bridge Mode

    3. Click ―Next‖. Enable NAT：NAT can enable several PCs in LAN to share one WAN IP address for Internet access. It is recommended that you enable this function. Enable Firewall: Enabling this function can protect your PC against some attacks. We recommend you to enable it.
  • Page 33 Encapsulation Mode：VC/MUX or LLC/SNAP-BRIDGING When you select a connection type the encapsulation mode will automatically change to adapt to the selected type. We recommend you not to change the default setting. 5. Enable bridge service If you select bridging mode you must enable this function. By default it is enabled. 6.

  • Page 34: Lan

    5.2.2 LAN IP Address: The LAN IP address.default value is 192.168.1.1.You can change it according to your needs. Note: Notice: Once you change this IP address, you should use the new IP address to enter the Web interface upon next time login. In addition you must set all LAN PCs‘ default gateway at this new address to ensure successful internet access.

  • Page 35: Nat

    5.2.4 NAT 5.2.4.1 Virtual Server 1. Click ―NAT‖-----―Virtual Server‖ to display the following page. You can add or delete your virtual server settings here. By default, the external networks cannot access the IP addresses of your internal network. However, if you need such access by the external networks, for example, when you want to set up a server or support some special applications), you should enable this function to allow the access to your internal network by external networks.

  • Page 36: Port Triggering

    5.2.4.2 Port Triggering 1. Click ―Port Triggering‖ to display the following page. You can add or delete your port triggering service settings here. Some special application programs require you to enable application ports. You can enable the automatic opening of these ports through the port triggering. 2.
  • Page 37 5.2.4.3 DMZ Host 1. Click ―DMZ Host‖ to display the following page. 2. DMZ Host IP Address: Entering the LAN IP address of the DMZ host. Caution: Once you enable DMZ all ports will be opened. In this case, your computer will be totally exposed to the public network.

  • Page 38: Security

    2. Enable UPnP: you can enable or disable the UPnP (Universal Plug and Play) function. UPnP is a kind of architecture of common Peer-to-Peer network connection used between the computer and intelligent devices/instruments. Based on the Internet standards and technologies (such as TCP/IP, HTTP and XML), UPnP enables automatic connection and cooperation between such devices, thus to enable network (especially the family network) to meet more people‘s needs.
  • Page 39 3. Click ―Save/Apply‖ to bring your configurations into effects. 4. Click ―Add‖ to display the following page. You can add your rules according to the above configurations You can select a WAN interface. We recommend you not to modify the default settings. 5.

  • Page 40: Routing

    5.2.6 Routing 5.2.6.1 Default Gateway 1. Click ―Routing‖ → ―Default Gateway‖ to display the following page. Enable ―Obtain default Gateway automatically‖: Check to enable and uncheck to disable this function. It is recommended that you keep the default setting. 2. Click ―Save/Apply‖ to bring your configurations into effects. 5.2.6.2 Static Route 1.

  • Page 42: Dns

    5.2.7 DNS 5.2.7.1 DNS Server Click ―DNS Server‖ to display the following page. Enable Automatic Assigned DNS: After enabling it, Router‘s DHCP server will distribute a DNS server address to the client submitting the request. Primary DNS Address: Input the DNS address provided by your ISP Secondary DNS Address: Enter the second DNS address here if your ISP provides two.

  • Page 43: Dsl

    D-DNS provider: Select a specific provider of dynamic DNS. Hostname: Domain name applied by you. Interface: the physical interface for enabling DDNS function. Username: Your user name registered on the website of the dynamic DNS provider. Password: Your password corresponding to the user name registered on the website of the dynamic DNS provider.

  • Page 44: Dhcp

    5.3 DHCP 5.3.1 DHCP Server 1. Click ―DHCP Setting‖ to display the following page. Start IP Address: the start address the start IP address from which DHCP server starts IP address distribution End IP Address: the end IP address from which DHCP server ends IP address distribution. Leased Time(h): Validity period of the IP address obtained.

  • Page 45: Diagnostic

    5.4 Diagnostic Your modem is capable of testing your DSL connection. The individual tests are listed below. If a test displays a fail status, click "Rerun Diagnostic Tests" at the bottom of this page to make sure the fail status is consistent.

  • Page 46: System Tools

    5.5 System Tools 5.5.1 Settings 1. Click ―Backup‖ to back up the current settings of the router after selecting a save path. 2. Click ―Update‖ to update router‘s current settings after entering a full path of the file in the interface or selecting a backup file through ―browse‖.

  • Page 47: System Log

    Note: After restoring the default settings, you need to reboot the router to activate this modification. 5.5.2 System Log 1. Click ―System Log‖ to display the following page. 2. Click ―View System Log‖ to display the following page. 3. Click ―Configure System Log‖ to display the following page. Log: Enable;...

  • Page 48: Snmp Agent

    5.5.3 SNMP Agent SNMP is the abbreviation for Simple Network Management Protocol, it can monitor device‘s status and set the parameters using the SNMP Client software, Router can also automatically send trap information to the management host to report their state. If you do not use SNMP to manage the network or you do not know whether it is necessary to run SNMP, then do not enable it.

  • Page 49: Access Control

    5.5.5 Access Control 5.5.5.1 Passwords 1. Click ―Passwords‖ to display the following page. Here, you can modify the password for login to the Management page. 2. Enter your old login password, and then the new one. If the entered old login password is correct, click ―Save/Apply‖...

  • Page 50: Appendix A - Configuring The Internet Settings

    Appendix A - Configuring the Internet Settings This appendix provides instructions for configuring the Internet settings on your computers to work with the device. Configuring Ethernet PCs Before you begin By default, the device automatically assigns the required Internet settings to your PCs. You need to configure the PCs to accept this information when it is assigned.

  • Page 51: Windows Me Pcs

    In the Select Network Component Type dialog box, select Protocol, and then click Add. Select Internet Protocol (TCP/IP) in the Network Protocols list, and then click OK. You may be prompted to install files from your Windows 2000 installation CD or other media. Follow the instructions to install the files.
  • Page 52  You maintain different subnets on your LAN (subnets are described in Appendix B). Before you begin, you must have the following information available:  The IP address and subnet mask of each PC  The IP address of the default gateway for your LAN. In most cases, this is the address assigned to the LAN port on the device.

  • Page 53: Appendix B - Troubleshooting

    Appendix B - Troubleshooting This appendix suggests solutions for problems you may encounter in installing or using the device, and provides instructions for using several IP utilities to diagnose problems. Contact Customer Support if these suggestions do not resolve the problem. Troubleshooting Suggestions Problem Troubleshooting Suggestion...
  • Page 54 Problem Troubleshooting Suggestion I forgot/lost my user ID or If you have not changed the password from the default, try using ―admin‖ as both the user ID password. and password. Otherwise, you can reset the device to the default configuration by pressing three times the Reset Default button on the front panel of the device.

  • Page 55: Diagnosing Problem Using Ip Utilities

    Diagnosing Problem using IP Utilities Ping Ping is a command you can use to check whether your PC can recognize other computers on your network and the Internet. A ping command sends a message to the computer you specify. If the computer receives the message, it sends messages in reply. To use it, you must know the IP address of the computer with which you are trying to communicate.
  • Page 56 There may be several addresses associated with an Internet name. This is common for web sites that receive heavy traffic; they use multiple, redundant servers to carry the same information. To exit from the nslookup utility, type exit and press [Enter] at the command prompt.

  • Page 57: Appendix C - Glossary

    Appendix C - Glossary Term Description 10BASE-T A designation for the type of wiring used by Ethernet networks with a data rate of 10 Mbps. Also known as Category 3 (CAT 3) wiring. See data rate, Ethernet. 100BASE-T A designation for the type of wiring used by Ethernet networks with a data rate of 100 Mbps.
  • Page 58 Bridging Passing data from your network to your ISP and vice versa using the hardware addresses of the devices at each location. Bridging contrasts with routing which can add more intelligence to data transfers by using network addresses instead. The device can perform both routing and bridging. Typically, when both functions are enabled, the device routes IP data and bridges all other types of data.
  • Page 59 Digital Subscriber Line A technology that allows both digital data and analog voice signals to travel over existing copper telephone lines. Encryption keys See network keys Ethernet The most commonly installed computer network technology, usually using twisted pair wiring. Ethernet data rates are 10 Mbps and 100 Mbps. See also 10BASE-T, 100BASE-T, twisted pair.
  • Page 60 network ID and the host ID. Because IP addresses are difficult to remember, they usually have an associated domain name that can be specified instead. See domain name, network mask. Internet Service Provider A company that provides Internet access to its customers, usually for a fee.
  • Page 61 Network Interface Card An adapter card that plugs into your computer and provides the physical interface to your network cabling. For Ethernet NICs this is typically an RJ- 45 connector. See Ethernet, RJ-45. Packet Data transmitted on a network consists of units called packets.
  • Page 62 Routing Forwarding data between your network and the Internet on the most efficient route, based on the data‘s destination IP address and current network conditions. A device that performs routing is called a router. SDNS Secondary Domain Name System (server) A DNS server that can be used if the primary DSN server is not available.
  • Page 63 so, whether to replace addresses on TCP packets only, UDP packets only, or both. Twisted pair The ordinary copper telephone wiring used by telephone companies. It contains one or more wire pairs twisted together to reduce inductance and noise. Each telephone line uses one pair. In homes, it is most often installed with two pairs.
  • Page 64 site, the first page that is displayed is called the home page. See hyperlink, web site. Web site A computer on the Internet that distributes information to (and gets information from) remote users through web browsers. A web site typically consists of web pages that contain text, graphics, and hyperlinks.

  • Page 65: Appendix D - Specification

    Appendix D - Specification A1. Hardware Specifications LAN Interface One 10/100BaseT Ethernet port Connector – RJ-45 One USB 1.1 device port, type B connector WAN ADSL Line Interface Compliant with ITU-T G.992.1, G.992.2, G.992.3, G.992.5 and ANSI and ANSI T1. 413 Issue 2 Line Impedance: 100 ...
  • Page 66 A2. Software Specifications ATM Cells over ADSL, AAL5 Bridge mode: Supports 8 PVCs Router mode: Supports 5 PVCs Supports UBR, CBR, VBR-nrt, and VBR-rt traffic classes ATM Forum UNI 3.0, UNI 3.1, UNI 4.0 ILMI 4.0 Bridging Transparent Bridging and spanning tree protocol (IEEE 802.1D) RFC2684 (RFC 1483) Bridged IP packet filtering ZIPB (Zero installation PPP Bridge)

  • Page 67: Appendix E - Warranty

    Fill out the next page and mail or fax to Innoband Technologies, Inc. for product registration.

  • Page 68: Registration Card

    Registration Card Innoband 8012-B1 Product Registration Name: Company: Address: City/State/Zip: Phone: E-mail: Serial Number: Purchased from: Date of Purchase: Please cut out the above Product Registration Card and send in with a self-addressed stamped envelope Innoband Technologies, Inc. 2526 Qume Dr. Ste 21...

  • Page 69: Appendix F - Regulation

    The authority to operate this equipment is conditioned by the requirement that no modifications will be made to the equipment unless Innoband expressly approves the changes or modifications.
  • Page 70 FCC Part 68 Notice This equipment complies with Part 68 of FCC Rules. On the base unit of this equipment is a label that contains, among other information, the FCC Registration Number and Ringer Equivalence Number (REN) for this equipment. IF REQUESTED, THIS INFORMATION MUST BE GIVEN TO THE TELEPHONE COMPANY.

  • Page 71: Appendix G - Contact Information

    Appendix G - Contact information We would more than love to help if you have further technical questions, please visit our Website at http://www.innoband.com or send E-mail to support@innoband.com To purchase accessories or replacement parts for this router, please visit http://www.innocow.com...
