Hunter 23483 Parts Manual

PARTS GUIDE
PARTS GUIDE
Using the Parts Guide below, check to make sure all parts are included in the box.
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE.
Before installing your fan, record the following information for your records and warranty assistance.
Fan Parts
46 Blade Set
Blade Iron Set Hardware
44
Wood Screw
65
47 Screw, Blade Iron
68 Washer, Flat
63 Screw, Low Profile Washer
69 Screw, Machine, 6-32
If parts are missing or damaged call 1-888-830-1326.
(Not Drawn to Scale)
239
3 Canopy
Motor Housing Assembly
(Drawn to Scale)
8 Set Screw
Armature
70 Wire Nut
Hanger Bracket
Assembly
7 Hanger Ball /
Downrod Assembly
28
150 Globe / Shade
64 Wood Screw
Blade Assembly Screw
67
71 Mounting Isolator
Model Name
Catalog No.
Serial No.
Date Purchased
Where Purchased
Missing / Broken Parts:
Call 1-888-830-1326
Fan does not work:
1. Reference the Troubleshooting guide in
your Instruction Manual.
Switch /
2. Call your Local Service Center.
Housing
3. Call Technical Support at 901-248-2222.
Assembly
For additional information on:
Hunter Products
Dealer Location
Call 1-800-448-6837
www.hunterfan.com
75 Balancing Kit
61 Washer
Installer Choice
66 Blade Grommet
Trouble Shooting
Service Center Locator
62 Canopy Screw
