Gasoline Stationary Air Compressor
Installation, Operation and Maintenance Manual
To the Owner:
Thank you for purchasing a NorthStar Air Compressor. Your machine is designed for long life, dependability, and
the top performance you demand! Please take time now to read through this manual so you better understand
the machine's operation, maintenance and safety precautions. Everyone who operates this machine must read
and understand this manual. The time you take now will prolong your machine's life and prepare you for its safe
operation. Enjoy the exceptional performance of your NorthStar Air Compressor, the industry leader!
The manufacturer reserves the right to make improvements in design and/or changes in specifications at any
time without incurring any obligation to install them on units previously sold.
Engine Oil
Engine is shipped without oil. Fill before starting.
Use SAE 10W-30 motor oil.
Pump Oil
Check pump oil level before starting.
Use SAE 30W non-detergent pump oil (part # 35605).
Air Filter
Replacement air filter part number is #35409.
Maximum
Item #45938 maximum pressure = 175 psi
Pressure
Maintenance
Engine:
Schedule
Tank:
Compressor
Pump:
Read and understand all manuals before operating.
Any Questions, Comments, Problems, or Parts Orders
Quick Facts
Oil: change after first 20 hours, then annually or every 100 hours.
Spark Plug: clean every 100 hrs., replace annually or every 300 hrs.
Air Filter: clean weekly, replace annually or every 1000 hrs.
Drain water daily.
Oil: change after first 50 hours, then every 3 months or 500 hours.
Call NorthStar Product Support 1-800-270-0810
M36029L
45938; 13 HP Honda, 27.4 PSC, 30 Gal. Stationary Tank
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NorthStar M36029L
Summary of Contents for NorthStar M36029L
- Page 1 Installation, Operation and Maintenance Manual To the Owner: Thank you for purchasing a NorthStar Air Compressor. Your machine is designed for long life, dependability, and the top performance you demand! Please take time now to read through this manual so you better understand the machine’s operation, maintenance and safety precautions.
-
Page 2: Table Of Contents
Operation Troubleshooting Limited Warranty BREATHING AIR PRECAUTION Safety NorthStar air compressors are not designed, intended or approved for breathing air. Compressed air should not DEFINITIONS be used for breathing air applications unless treated in DANGER! accordance with all applicable codes and regulations. -
Page 3: Machine Component Identification
Machine Component Identification 01044 1.) Engine Control - Location of choke, engine 9.) Drain Valve - Location of tank drain valve. speed and fuel valve. Drain tank daily after each use. 2.) Engine - Engine is NOT shipped with oil. Refer 10.) ASME Safety Valve - This valve automatically to engine owners’... -
Page 4: Assembly
Assembly Step 2. Step 1. Remove tape from compressor inlet. Remove compressor air filter from pallet. Remove tape Remove lag bolts and washers and discard 01046 Step 3. Step 4. Bolt compressor air filter to compressor Mounting dimensions inlet. Air filter bolt (in manual bag) ... -
Page 5: Operation
Use of compressor without check pump oil level. Add SAE 30 non-detergent lubricant or inadequate lubricant voids all warranties. pump oil (NorthStar part #35605), if necessary. Hand Synthetic Lubricants tighten breather cap. Synthetic lubricants are recommended after 50 hour 2. -
Page 6: Maintenance
Maintenance WARNING! Disconnect spark plug wire from spark plug and release air pressure from system before performing maintenance. NOTE: All compressed air systems contain maintenance parts (e.g. lubricating oil, filters, separators), which are periodically replaced. These used parts may be, or contain, substances that are regulated and must be disposed of in accordance with local, state, and federal laws and regulations. -
Page 7: Exploded View / Component List
¼ Compress Sleeve Brass 34737 Rotating equip. decal 35189 Throttle Control 779226 Warning hot decal 35064 Engine, Honda GX390 787617 NorthStar decal 784822 Belt, A66 35664 Bushing, H x 1” Receiver tank 780796 37852 Operation instr. decal 36030 Air filter... - Page 8 779103 Pump Assembly Item Description Part # Item Description Part # Pump Head AB6061401 Rod Nut AB9128234 Head Bolt (M10 x 55mm SHCS) AB9101754 Oil Seal AB9163030 Air Filter 35409 Cover D.E. AB6061590 Air Filter Assy. 35404 Cover Bolt (M6 x 15mm SHCS) AB9101154 Intake/After cooler Gasket AB5070200...
-
Page 9: Pneumatic Schematic Diagrams
Pneumatic Schematic Diagram Safety Relief Valve Pump Idle Down Unloader Safety Relief Valve 30 Gallon Tank... -
Page 10: Troubleshooting
Deglaze cylinder with 180 grit flex-hone. V.) Low pressure inlet valve leaking. Inspect, clean or repair as required. W.) High pressure inlet valve leaking. Inspect, clean or repair as required. Any Questions, Comments, Problems, or Parts Orders Call NorthStar Product Support 1-800-270-0810... -
Page 11: Limited Warranty
This warranty does not cover any personal injury or damage to surrounding property caused by failure of any part. This warranty is in lieu of any other warranty expressed or implied and NorthStar assumes no other responsibility or liability outside that expressed within this warranty. - Page 12 ® Manufactured by Northern Tool + Equipment Co., 2800 SouthCross Drive West P.O. Box 1499 Burnsville, MN 55337-0499...
