Innoband 8520-R1 User Manual

4-port wireless n gateway
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
8520-R1
4-Port Wireless N Gateway
Issue 1.0
th
6
, July, 2010
8520-R1 4-Port Wireless N Gateway
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8520-R1 and is the answer not in the manual?

Questions and answers

Related Manuals for Innoband 8520-R1

Summary of Contents for Innoband 8520-R1

  • Page 1 User’s Manual 8520-R1 4-Port Wireless N Gateway Issue 1.0 , July, 2010 8520-R1 4-Port Wireless N Gateway...

  • Page 2: User Manual

    Innoband or other third parties. Users are not permitted to use these Marks without the prior written consent of Innoband or such third party that may own the Mark. IBM is a registered trademark of International Business Machines Corporation.

  • Page 3: Table Of Contents

    4.5.1.4 WAN – Channel Config – PPPoA Mode ..............53 4.5.1.5 WAN – Channel Config – 1483 Routed Mode ............56 4.5.2 WAN – ATM Settings ......................59 4.5.3 WAN – ADSL Settings ....................... 61 4.6 S ............................ 62 ERVICE 8520-R1 4-Port Wireless N Gateway...
  • Page 4 4.9.7 Admin – Time Zone ......................103 4.9.8 Admin – TR-069 ......................104 4.10 S ..........................106 TATISTICS 4.10.1 Statistics – Interface ...................... 106 4.10.2 Statistics – ADSL......................106 APPENDIX A: ROUTER TERMS ....................107 8520-R1 4-Port Wireless N Gateway...
  • Page 5 APPENDIX C: TROUBLESHOOTING GUIDE ............... 113 APPENDIX D: UPNP SETTING ON WINDOWS XP (OPTIONAL) ........116 APPENDIX E: GLOSSARY ......................120 APPENDIX F: REGULATION ....................127 APPENDIX G: WARRANTIES ....................129 APPENDIX H: CONTACT INFORMATION ................131 8520-R1 4-Port Wireless N Gateway...

  • Page 6: Chapter 1 Introduction

    300Mbps transfer data rate for the 11n connection. This device allows ADSL2/2+ connectivity while providing Wireless LAN capabilities for home or office users. This asymmetric nature lends itself to applications such as Internet access and video delivery. With minimum setup, you can install and use the router within minutes. 8520-R1 4-Port Wireless N Gateway...

  • Page 7: Features

    Support IP Filter and MAC Filter functionality.  URL Blocking feature supported.  Support Port Forwarding features.  Support DMZ functionality.  Support NAT and NAPT (PAT) functionality with extensive ALG supported.  Support VPN Pass-Through.  Built-in Firewall features. 8520-R1 4-Port Wireless N Gateway...
  • Page 8  Built-in 4 Ports 10/100Mbps Ethernet Switch which compliant with IEEE 802.3x standards  Automatic MDI/MDI-X crossover for 100BASE-TX and 10BASE-T ports.  Auto-negotiation and speed-auto-sensing support.  Port based VLAN supported in any combination. 8520-R1 4-Port Wireless N Gateway...

  • Page 9: System Requirement

    One Power Adapter  One RJ-11 ADSL Cable  One RJ-45 Ethernet Cable  One CD-ROM ( Manual / Specsheet ) If any of the above items are damaged or missing, please contact your dealer immediately. 8520-R1 4-Port Wireless N Gateway...

  • Page 10: Chapter 2 Knowing The 4 Port Wireless N Gateway

    Blinking when it is attempting to make an ADSL connection with ISP. Lights up when PPPoE or PPPoA connection is successfully authenticated. Blinking when PPP/ACT sending or receiving data. Blinking when WPS is in progress. 8520-R1 4-Port Wireless N Gateway...

  • Page 11: Back Panel

    Press the Reset button for 2~5 seconds and release. Wait for 30 seconds after release the Reset button. To setup WPS via WPS button:  Press the WPS button for 2 seconds and release. The Wireless LED will be blinking to establish WPS connection. 8520-R1 4-Port Wireless N Gateway...

  • Page 12: Connection Mechanism

    Multiplexing Method or Protocol Type or Encapsulation Type Host and Domain Names ISP Login Name and Password ISP Domain Name Server (DNS) Address Fixed or Static IP Address. Figure below shows the overall hardware connection mechanism of your 4-port Wireless N Gateway. 8520-R1 4-Port Wireless N Gateway...
  • Page 13 This product’s Wireless is pre-configured with the latest Wireless Encryption: SSID: INNOBAND8520R1 Security Key: Unique MAC Address of the device; found at the bottom of the device or on the side of the retail box. 8520-R1 4-Port Wireless N Gateway...

  • Page 14: Chapter 3 Setting Up The Tcp/Ip In Windows

    Follow the procedures below to set your computer/notebook function as a DHCP Client. Restart and Reboot your Windows system might be necessary after setting your computer function as a DHCP Client. In order to properly activate your choice, click “OK” to restart your Windows system. 8520-R1 4-Port Wireless N Gateway...

  • Page 15: Windows Me / 98

    Step 5: Go to Gateway icon and erase all previous setting. Step 3: Go to Configuration icon, select network Step 6: Go to DNS Configuration icon, select adapter installed and click Properties. Disable DNS and click OK. 8520-R1 4-Port Wireless N Gateway...

  • Page 16: Windows 2000

    Step 2: Double-click the Network and Dial-up Connections. Step 5: Select Obtain an IP address automatically and DNS server address automatically. Then, click OK. Step 3: Right Click the Local Area Connection and select Properties. 8520-R1 4-Port Wireless N Gateway...

  • Page 17: Windows Xp

    Step 2: Double-click the Network Connections. Step 5: Go to General icon, select Obtain an IP address automatically and DNS server address automatically. Then, click OK. Step 3: Right Click on the Local Area Connection and select Properties. 8520-R1 4-Port Wireless N Gateway...

  • Page 18: Windows Vista

    Step 2: Double-click the Network and Sharing Center. Step 6: Go to General icon, select Obtain an IP address automatically and DNS server Step 3: Click on the Manage network connections. address automatically. Then, click OK. 8520-R1 4-Port Wireless N Gateway...

  • Page 19: Windows 7

    Step 2: Click the View network status and tasks. (TCP/IPv4) and click Properties. Step 3: Click on the Change adapter settings. Step 6: Go to General icon, select Obtain an IP address automatically and DNS server address automatically. 8520-R1 4-Port Wireless N Gateway...

  • Page 20: Chapter 4 Device Administration

    Launch your web browser, and enter the 4-port Wireless N Gateway’s IP Address: “192.168.1.1” in the address field then press the “Enter” key to login. Enter your user name and password in the respective text boxes. The default user name and password is “admin”. 8520-R1 4-Port Wireless N Gateway...
  • Page 21 Connect/Disconnect button to connect/disconnect the PPP dial up link. Release/Renew The two buttons take effect only when PVC is configured as 1483 Routed IP/Bridged IP/MER mode. Click Release/Renew button to release/renew the WAN IP Address. 8520-R1 4-Port Wireless N Gateway...

  • Page 22: Setup Wizard

    Select the Encapsulation Mode (see following page for more details). Step 2: Enter your VPI and VCI values provided by your ISP. If you are not sure of the setting/configuration details, contact your ISP immediately. 8520-R1 4-Port Wireless N Gateway...
  • Page 23 Manually enter your “User Name” and “Password” which will be provided by your Service Step 1: Provider (ISP). Click “Save” after setup. Step 2: Click Commit and Reboot button to commit changes to system memory and reboot router. 8520-R1 4-Port Wireless N Gateway...
  • Page 24  1483 MER VC-Mux (Fixed IP or DHCP)  1483 MER LLC (Fixed IP or DHCP) In this current window, you will find different Connection Types:  Fixed IP (Fixed IP by ISP)  DHCP (Get IP dynamically from ISP) 8520-R1 4-Port Wireless N Gateway...
  • Page 25 Manually enter the “Local IP Address”, “Subnet Mask”, “Remote IP Address” Step 2: (Default Gateway) and “DNS” which will be provided by your ISP. Click “Save” after your setting. Step 3: Click Commit and Reboot button to commit changes to system memory and reboot router. 8520-R1 4-Port Wireless N Gateway...
  • Page 26 DHCP (Get IP dynamically from ISP) Step 1: Click the radio button to enable DHCP option. Click the “Save” button to confirm your setting. Step 2: Click Commit and Reboot button to commit changes to system memory and reboot router. 8520-R1 4-Port Wireless N Gateway...
  • Page 27 When successfully rebooted, the following page with the device setup information will be displayed: Ensure that the changes highlighted above reflect the settings that your ISP has provided you. 8520-R1 4-Port Wireless N Gateway...

  • Page 28: Lan

    Function buttons in this page: Apply Changes Click to save the setting to the configuration. New parameters will take effect after save into flash memory and reboot the system. See section “Admin” for save details. 8520-R1 4-Port Wireless N Gateway...

  • Page 29: Wireless

    MBSSID This product’s Wireless is pre-configured with the latest Wireless Encryption: SSID: INNOBAND8520R1 Security Key: Unique MAC Address of the device; found at the bottom of the device or on the side of the box. 8520-R1 4-Port Wireless N Gateway...

  • Page 30: Wireless - Basic Settings

    Radio Power (mW) The AP Radio Power. Select 60mW, 30mW or 15mW power level from the drop down manual. The default Radio Power level is 60mW. It’s recommended to leave this setting as its default. 8520-R1 4-Port Wireless N Gateway...
  • Page 31 Click Show Active Clients button and it will show the clients currently associated with the ADSL router.  Apply Changes Change the settings. New parameters will take effect after save into flash memory and reboot the system. See section “Admin” for save details. 8520-R1 4-Port Wireless N Gateway...

  • Page 32: Wireless - Advanced Setting

    The ADSL modem (or AP) sends Request to Send (RTS) frames to a particular receiving station and negotiates the sending of a data frame. After receiving an RTS, the wireless station responds with a Clear to Send (CTS) frame to 8520-R1 4-Port Wireless N Gateway...
  • Page 33 Short GI Short guard interval. Function buttons in this page: Apply Changes Change the settings. New parameters will take effect after save into flash memory and reboot the system. See section “Admin” for save details. 8520-R1 4-Port Wireless N Gateway...

  • Page 34: Wireless - Security

    RADIUS server, the RADIUS port (default is 1812) and the shared secret from the RADIUS server. Please refer to “Authentication RADIUS Server” setting below for RADIUS setting. The WPA algorithm is selected between TKIP and AES, please 8520-R1 4-Port Wireless N Gateway...
  • Page 35 1812), IP address and password of external RADIUS server are specified here. Function buttons in this page: Apply Changes Change the settings. New parameters will take effect after save into flash memory and reboot the system. See section “Admin” for save details. 8520-R1 4-Port Wireless N Gateway...

  • Page 36: Wireless - Access Control

    Function buttons for the setting block: Apply Changes Click to add this entry into the Current Access Control List. The Current Access Control List lists the client MAC addresses. Any wireless client with its MAC address listed 8520-R1 4-Port Wireless N Gateway...
  • Page 37 You can select the entries at the Select column and apply to the following function buttons. Function buttons for the Current Access Control List: Delete Selected Delete the selected entries from the list. Delete All Flush the list. 8520-R1 4-Port Wireless N Gateway...

  • Page 38: Wireless - Wds

    WDS AP list may have a WDS link to the device. You can select the entries at the Select column and apply to the following function buttons. Function buttons for the Current WDS AP List: Delete Selected Delete the selected entries from the list. Delete All Flush the list. 8520-R1 4-Port Wireless N Gateway...

  • Page 39: Wireless - Wps

    Click to apply the new configuration.  Reset Click to abort change and recover the previous configuration. Function buttons for client PIN number:  Start PIN Click to Start WPS via the client PIN number. 8520-R1 4-Port Wireless N Gateway...

  • Page 40: Wireless - Mbssid

    Maximum number of client associations. You can set the number of users that can associate via a particular SSID, which makes it possible to control usage of particular applications. This can help provide a somewhat limited form of bandwidth control for particular applications.  Blocking between VAP: Disable/Enable blocking between VAP. 8520-R1 4-Port Wireless N Gateway...
  • Page 41 SSID: Set the SSID manually. The SSID is up to 32 characters.  Authentication Type: Open system, Shared Key and Auto.  Relay Blocking: Enabled/Disabled Relay Blocking.  Apply: Click Apply to confirm your setting.  Reset: Click Reset to give up all your current setting 8520-R1 4-Port Wireless N Gateway...

  • Page 42: Wan

    4.5 WAN There are three sub-menus for WAN configuration: [Channel Config], [ATM Settings], and [ADSL Settings]. 8520-R1 4-Port Wireless N Gateway...

  • Page 43: Wan - Channel Config

    Delete Selected Select an existing PVC channel to be deleted by clicking the radio button at the Select column of the Current ATM VC Table. Click Delete to delete this PVC channel from configuration. 8520-R1 4-Port Wireless N Gateway...
  • Page 44 The WAN setup configuration page enable the user to create, save, delete and select connection profiles as required. (In many cases, only one connection profile will be required and only one connection profile will be used at one time). 8520-R1 4-Port Wireless N Gateway...

  • Page 45: Wan - Channel Config - Bridge Mode

    The VCI field specifies this 16-bit numerical tag that determines the destination.  Encapsulation: There are 2 Encapsulation type:   VC-Mux  Channel Mode: Select “1483 Bridged” from the drop down manual. 8520-R1 4-Port Wireless N Gateway...

  • Page 46: Configuration Procedure

    The new settings will take effect after reboot the system. The following window display indicates the system restarting process. The following screen display after the system rebooting process. The System Home page will shows all the connection status and system information. 8520-R1 4-Port Wireless N Gateway...

  • Page 47: Wan - Channel Config - Mer (Mac Encapsulation Routing) Mode

     Encapsulation: There are 2 Encapsulation type:   VC-Mux  Channel Mode: Select “1483 MER” from the drop down manual.  Enable NAPT: Select “Disable” or “Enable” the NAPT functionality. Default setting is “Enable”. 8520-R1 4-Port Wireless N Gateway...
  • Page 48 ) the existing connection profile under the Actions column. 10. Click “Admin/ Commit/Reboot”. Press “Commit” to save the settings into flash memory. 11. The new settings will take effect after reboot the system. 12. The following window display indicates the system restarting process. 8520-R1 4-Port Wireless N Gateway...
  • Page 49 13. The following screen display after the system rebooting process. The System Home page will shows all the connection status and system information. 8520-R1 4-Port Wireless N Gateway...

  • Page 50: Wan - Channel Config - Pppoe Mode

    Encapsulation: There are 2 Encapsulation type:   VC-Mux  Channel Mode: Select “PPPoE” from the drop down manual.  Enable NAPT: Select “Disable” or “Enable” the NAPT functionality. Default setting is “Enable”.  PPP: 8520-R1 4-Port Wireless N Gateway...
  • Page 51 ) the existing connection profile under the Actions column. 10. Click “Admin/ Commit/Reboot”. Press “Commit” to save the settings into flash memory. 11. The new settings will take effect after reboot the system. 12. The following window display indicates the system restarting process. 8520-R1 4-Port Wireless N Gateway...
  • Page 52 13. The following screen display after the system rebooting process. The System Home page will shows all the connection status and system information. 8520-R1 4-Port Wireless N Gateway...

  • Page 53: Wan - Channel Config - Pppoa Mode

     Encapsulation: There are 2 Encapsulation type:   VC-Mux  Channel Mode: Select “PPPoA” from the drop down manual.  Enable NAPT: Select “Disable” or “Enable” the NAPT functionality. Default setting is “Enable”. 8520-R1 4-Port Wireless N Gateway...
  • Page 54 ) or “Delete” ( ) the existing connection profile under the Actions column. 10. Click “Admin/ Commit/Reboot”. Press “Commit” to save the settings into flash memory. 11. The new settings will take effect after reboot the system. 8520-R1 4-Port Wireless N Gateway...
  • Page 55 12. The following window display indicates the system restarting process. 13. The following screen display after the system rebooting process. The System Home page will shows all the connection status and system information. 8520-R1 4-Port Wireless N Gateway...

  • Page 56: Wan - Channel Config - 1483 Routed Mode

     Encapsulation: There are 2 Encapsulation type:   VC-Mux  Channel Mode: Select “1483 Routed” from the drop down manual.  Enable NAPT: Select “Disable” or “Enable” the NAPT functionality. Default setting is “Enable”. 8520-R1 4-Port Wireless N Gateway...
  • Page 57 ) the existing connection profile under the Actions column. Click “Admin/ Commit/Reboot”. Press “Commit” to save the settings into flash memory. 10. The new settings will take effect after reboot the system. 11. The following window display indicates the system restarting process. 8520-R1 4-Port Wireless N Gateway...
  • Page 58 12. The following screen display after the system rebooting process. The System Home page will shows all the connection status and system information. 8520-R1 4-Port Wireless N Gateway...

  • Page 59: Wan - Atm Settings

    (Asynchronous Transfer Mode) to describe the time difference that is acceptable between cells being presented at the receiving host. Available only when VBR QoS is chosen. Sustained Cell Rate, measured in cells/sec., is the average cell rate over the 8520-R1 4-Port Wireless N Gateway...
  • Page 60 Apply Changes Set new PVC OoS mode for the selected PVC. New parameters will take effect after save into flash memory and reboot the system. See section “Admin” for save details. Undo Discard your settings. 8520-R1 4-Port Wireless N Gateway...

  • Page 61: Wan - Adsl Settings

    Function buttons in this page: Tone Mask Choose tones to be masked. Mased tones will not carry any data. Apply Changes Click to save the setting to the configuration and the modem will be retrained. 8520-R1 4-Port Wireless N Gateway...

  • Page 62: Service

    4.6 Service You can view Service link in the left navigation bar. Following are the options available under Service:  DHCP Settings   Firewall  IGMP Proxy  UPnP  8520-R1 4-Port Wireless N Gateway...

  • Page 63: Service - Dhcp Settings

    Specify the IP Address of Gateway. Function buttons in this page: Apply Changes Set new DHCP server configuration. New parameters will take effect after save into flash memory and reboot the system. See section “Admin” for save details. 8520-R1 4-Port Wireless N Gateway...
  • Page 64 DHCP relay agent. When a host on your network requests Internet access, the device contacts your ISP to obtain the IP configuration, and then forward that information to the host. You should set the DHCP mode after you configure the DHCP relay. 8520-R1 4-Port Wireless N Gateway...

  • Page 65: Service - Dns

    4.6.2 Service – DNS There are two submenus for the DNS Configuration: [DNS Server] and [Dynamic DNS] 8520-R1 4-Port Wireless N Gateway...

  • Page 66: Service - Dns - Dns Server

    Function buttons in this page: Apply Changes Set new DNS relay configuration. New parameters will take effect after save into flash memory and reboot the system. See section “Admin” for save details. Reset Selected Discard your changes. 8520-R1 4-Port Wireless N Gateway...

  • Page 67: Service - Dns - Ddns Server

    Click Modify to modify this registration into the configuration. Remove Select an existing DDNS registration by clicking the radio button at the Select column of the Dynamic DNS Table. Click Remove button to remove the selected registration from the configuration. 8520-R1 4-Port Wireless N Gateway...

  • Page 68: Service - Firewall

    4.6.3 Service – Firewall Firewall contains several features that are used to deny or allow traffic from passing through the device. 8520-R1 4-Port Wireless N Gateway...

  • Page 69: Service - Firewall - Ip/Port Filtering

    Starting and ending source port numbers. Destination IP Address The destination IP address assigned to the traffic on which filtering is applied. Subnet Mask Subnet-mask of the destination IP. Port Starting and ending destination port numbers. 8520-R1 4-Port Wireless N Gateway...
  • Page 70 Function buttons for the Current Filter Table: Delete Selected Delete selected filtering rules from the filter table. You can click the checkbox at the Select column to select the filtering rule. Delete All Delete all filtering rules from the filter table. 8520-R1 4-Port Wireless N Gateway...

  • Page 71: Service - Firewall - Mac Filtering

    The destination MAC address. It must be xxxxxxxxxxxx format. Blanks can be used in the MAC address space and are considered as don’t care. Address Function buttons for this second setting block: Click to add the rule entry to the configuration. 8520-R1 4-Port Wireless N Gateway...
  • Page 72 Function buttons for the Current Filter Table: Delete Selected Delete selected filtering rules from the filter table. You can click the checkbox at the Select column to select the filtering rule. Delete All Delete all filtering rules from the filter table. 8520-R1 4-Port Wireless N Gateway...

  • Page 73: Service - Firewall - Port Forwarding

    Delete Selected Delete the selected port forwarding rules from the forwarding table. You can click the checkbox at the Select column to select the forwarding rule. Delete All Delete all forwarding rules from the forwarding table. 8520-R1 4-Port Wireless N Gateway...

  • Page 74: Service - Firewall - Url Blocking

    The complete domain name for a specific computer (host) on the Internet. Keyword Enter the filtered keyword. Function buttons for the setting block: Apply Changes Click to save the enable/disable the URL Blocking to the configuration. 8520-R1 4-Port Wireless N Gateway...
  • Page 75 Delete Selected Delete the selected keyword from the Keyword Filtering table. You can click the checkbox at the Select column to select the keyword entry. Delete All Delete all keyword entry from the keyword filtering table. 8520-R1 4-Port Wireless N Gateway...

  • Page 76: Service - Firewall - Domain Blocking

    Delete Selected Delete the selected Domain from the Domain Blocking table. You can click the checkbox at the Select column to select the Domain entry. Delete All Delete all Domain entry from the Domain Blocking table. 8520-R1 4-Port Wireless N Gateway...

  • Page 77: Service - Firewall - Dmz

    DMZ Host IP Address IP address of the local host. This feature sets a local host to be exposed to the Internet. Function buttons in this page: Apply Changes Click to save the setting to the configuration. 8520-R1 4-Port Wireless N Gateway...

  • Page 78: Service - Igmp Proxy

    IGMP proxy.  Upstream: The interface that IGMP requests from hosts is sent to the multicast router.  Downstream: The interface data from the multicast router are sent to hosts in the multicast group database. 8520-R1 4-Port Wireless N Gateway...

  • Page 79: Service - Upnp

    Field Description UPnP Enable/disable UPnP feature. WAN Interface Select WAN interface that will use UPnP from the drop-down lists. Function buttons in this page: Apply Changes Click to save the setting to the system configuration. 8520-R1 4-Port Wireless N Gateway...

  • Page 80: Service - Rip

    Indicate the RIP version in which information must be passed to the DSL device in order for it to be accepted into its routing table. Send Mode Indicate the RIP version this interface will use when it sends its route information to other devices. 8520-R1 4-Port Wireless N Gateway...

  • Page 81: Advance

    You can view Advance link in the left navigation bar. Following are the options available under Advance:  ARP table  Bridging  Routing  SNMP  Port Mapping  IP QoS  Remote Access  Others 8520-R1 4-Port Wireless N Gateway...

  • Page 82: Advance - Arp Table

    4.7.1 Advance – ARP table ARP table shows a list of learned MAC address. 8520-R1 4-Port Wireless N Gateway...

  • Page 83: Advance - Bridging

    Function buttons in this page: Apply Changes Save this bridge configuration. New configuration will take effect after saving into flash memory and rebooting the system. See section “Admin” for details. Show MACs List MAC address in forwarding table. 8520-R1 4-Port Wireless N Gateway...

  • Page 84: Advance - Routing

    Defines the number of hops between network nodes that data packets travel. The default value is 0, which means that the subnet is directly one hop away on the local LAN network. Interface The WAN interface to which a static routing subnet is to be applied. 8520-R1 4-Port Wireless N Gateway...
  • Page 85 Update the selected destination route on the Static Route Table. Delete Selected Delete a selected destination route on the Static Route Table. Show Routes Click this button to view the DSL device’s routing table. The IP Route Table displays, as shown in Figure. 8520-R1 4-Port Wireless N Gateway...

  • Page 86: Advance - Snmp

    MIB. Function buttons in this page: Apply Changes Save SNMP configuration. New configuration will take effect after saving into flash memory and rebooting the system. See section “Admin” for details. 8520-R1 4-Port Wireless N Gateway...

  • Page 87: Advance - Port Mapping

    3. Click “Apply Changes” button to save the changes. Function buttons in this page: Apply Changes Save configuration to system. New configuration will take effect after saving into flash memory and rebooting the system. See section “Admin” for details. 8520-R1 4-Port Wireless N Gateway...

  • Page 88: Advance - Ip Qos

    The selections are TCP, UDP, ICMP and the blank for none. This field is required if the source port or destination port has been entered. Physical Port The incoming ports. The selections include LAN ports, wireless port, and the blank for not applicable. 8520-R1 4-Port Wireless N Gateway...
  • Page 89 Delete selected IP QoS rules from the table. You can click the checkbox at the Select column to select the IP QoS rule. Delete All Delete all IP QoS rules from the IP QoS Rules table. 8520-R1 4-Port Wireless N Gateway...

  • Page 90: Advance - Remote Access

    HTTP service for example; when it is changed to 8080, the HTTP server address for the WAN side is http://dsl_addr:8080, where the dsl_addr is the WAN side IP address of the DSL device. Function buttons in this page: Apply Changes Save configuration to system. 8520-R1 4-Port Wireless N Gateway...

  • Page 91: Advance - Others

    The Lease time is the amount of time a network user will be allowed to connect with DHCP server. Allow LAN Access Click to enable LAN Access. Function buttons in this page: Apply Changes Save configuration to system. 8520-R1 4-Port Wireless N Gateway...

  • Page 92: Diagnostic

    The Diagnostics page allows you to run a series of diagnostic tests of your system software and hardware connections. You can view Diagnostic link in the left navigation bar. Following are the options available under Diagnostic:  Ping  ATM Loopback  ADSL  Diagnostic Test 8520-R1 4-Port Wireless N Gateway...

  • Page 93: Diagnostic - Ping

    IP address in the Host Address field. Click Go! To start the ping command, the ping result will then be shown in this page. Fields in this page: Field Description Host Address The IP address you want to ping. 8520-R1 4-Port Wireless N Gateway...

  • Page 94: Diagnostic - Atm Loopback

    The ATM OAM flow type. The selection can be F5 Segment or F5 End-to-End. Loopback Location ID The loop-back location ID field of the loop-back cell. The default value is all 1s (ones) to indicate the endpoint of the segment or connection. 8520-R1 4-Port Wireless N Gateway...

  • Page 95: Diagnostic - Adsl

    4.8.3 Diagnostic – ADSL This page shows the ADSL diagnostic result. Click Start button to start the ADSL diagnostic. 8520-R1 4-Port Wireless N Gateway...

  • Page 96: Diagnostic - Diagnostic Test

    The Diagnostic Test page shows the test results for the connectivity of the physical layer and protocol layer for both LAN and WAN sides. Fields in this page: Field Description Select the Internet The available WAN side interfaces are listed. You have to select one for the WAN Connection side diagnostic. 8520-R1 4-Port Wireless N Gateway...

  • Page 97: Admin

    To save your changes for future use, you can use the Commit/Reboot function. This function saves your changes from RAM to flash memory and reboot the system. IMPORTANT! Do not turn off your modem or press the Reset button while this procedure is in progress. 8520-R1 4-Port Wireless N Gateway...

  • Page 98: Admin - Backup/Restore

    4.9.2 Admin – Backup/Restore This page allows you to backup and restore your configuration into and from file in your host. 8520-R1 4-Port Wireless N Gateway...

  • Page 99: Admin - System Log

    Click to save the setting of this setting block to the system configuration. Fields on the second setting block: Field Description Save Log to File Click Save button to save log. Clear Log Click Reset button to clear log. 8520-R1 4-Port Wireless N Gateway...

  • Page 100: Admin - Password

    Enter the old password for this selected login. New Password Enter the new password here. Confirmed Password Enter the new password here again to confirm. Function buttons in this page: Apply Changes Save configuration to system. 8520-R1 4-Port Wireless N Gateway...

  • Page 101: Admin - Upgrade Firmware

    Click the Browse button to select the firmware file.  Confirm your selection.  Click the Upload button to start upgrading. IMPORTANT! Do not turn off your modem or press the Reset button while this procedure is in progress. 8520-R1 4-Port Wireless N Gateway...

  • Page 102: Admin - Acl

    Field Description ACL Capability Enable/disable the ACL function Enable Check to enable this ACL entry Interface Select the interface domain: LAN or WAN IP Address Enter the IP address that allows access to this device. 8520-R1 4-Port Wireless N Gateway...

  • Page 103: Admin - Time Zone

    The IP address or the host name of the SNTP server. You can select from the list or set it manually. Function buttons in this page: Apply Changes Click to save the setting to the configuration. 8520-R1 4-Port Wireless N Gateway...

  • Page 104: Admin - Tr-069

    The CPE WAN Management Protocol is intended to support a variety of functionalities to manage a collection of CPE, including the following primary capabilities:  Auto-configuration and dynamic service provisioning  Software/firmware image management  Status and performance monitoring  Diagnostics 8520-R1 4-Port Wireless N Gateway...
  • Page 105 Click Browse button and upload the CPE certificate CA Certificate Click Browse button and upload the CA certificate Function buttons in this page: Apply Changes Click to save the setting to the configuration. Undo Discard your changes. 8520-R1 4-Port Wireless N Gateway...

  • Page 106: Statistics

    ISP to diagnose network and Internet data transmission problems. To display updated statistics showing any new data since you opened this page, click Refresh. 4.10.2 Statistics – ADSL This page shows the ADSL line statistic information. 8520-R1 4-Port Wireless N Gateway...

  • Page 107: Appendix A: Router Terms

    "fakes" the connection to your machine. You should use the DMZ when you want to run a server that others will access from the Internet. Internal programs and servers (like print servers, etc) should NOT be connected to the DMZ 8520-R1 4-Port Wireless N Gateway...
  • Page 108 If your machine can reach all stations on the same subnet (usually a building or a sector within a building), but cannot communicate outside of this area, it is usually because of an incorrectly configured default gateway. 8520-R1 4-Port Wireless N Gateway...

  • Page 109: Appendix B: Frequently Asked Questions

    Internet using DeMilitarized Zone (DMZ) setting. Refer to Service–Firewall–DMZ section for the setting detail. I need to upgrade the firmware. Ans. In order to upgrade the firmware with the latest features, check with your local dealer or ISP for technical support. 8520-R1 4-Port Wireless N Gateway...
  • Page 110 Ethernet networking device. This address is usually permanent. What is IEEE 802.11b standard? Ans. IEEE 802.11b is an extension standard to 802.11 that applies to Wireless LAN and provides 11Mbps transmission speed in the 2.4 GHz band. 8520-R1 4-Port Wireless N Gateway...
  • Page 111 802.11b standard. WEP is designed to provide the same level of security as that of a wired LAN. WEP aims to provide security by encrypting data over radio waves so that it is protected as it is transmitted from one end point to another. 8520-R1 4-Port Wireless N Gateway...
  • Page 112 Ans. The 4-port Wireless N Gateway can support up to 253 IP addresses. What is the factory default encapsulation protocol for the Innoband 8520-R1? Ans. By default, 1483 MER and Wireless security is enabled. You can find your unique default Wireless...

  • Page 113: Appendix C: Troubleshooting Guide

    Check the location of the 4-port Wireless N Gateway in the building. Make sure both WLAN client adapter and the 4-port Wireless N Gateway is allowed to connect through wireless channels as defined for local regulatory domain. 8520-R1 4-Port Wireless N Gateway...
  • Page 114 1. Download the latest Firmware and save at your pointed location. 2. Read the firmware release note carefully before proceed the upgrading process. 3. Refer to Admin – Upgrade Firmware section for the upgrading process. 8520-R1 4-Port Wireless N Gateway...
  • Page 115 1. Check whether your Wireless LAN setting (e.g. SSID, Channel Number) is the same as your 4-port Wireless N Gateway. 2. Check whether you’d used the same WEP Key Encryption for both your Wireless LAN and your 4-port Wireless N Gateway. 8520-R1 4-Port Wireless N Gateway...

  • Page 116: Appendix D: Upnp Setting On Windows Xp (Optional)

    If you are running Microsoft Windows XP, it is recommended to add the UPnP component to your system. Proceed as follows: Click “Start”  “Settings” then “Control Panel”. The “Control Panel” window appears. Click “Add or Remove Programs”. 8520-R1 4-Port Wireless N Gateway...
  • Page 117 The “Add or Remove Programs” window appears. Click “Add/Remove Windows Components”. The “Windows Components Wizard” appears. Select “Networking Services” in the Components list and click “Details”. 8520-R1 4-Port Wireless N Gateway...
  • Page 118 System may ask for original Windows XP CD-ROM. Insert the CD-ROM and direct Windows to the proper location of the CD-ROM. Restart your Windows system to activate your setting might be necessary. Click “OK” to restart your Windows system. 8520-R1 4-Port Wireless N Gateway...
  • Page 119 A “Completing the Windows Components Wizard” will appears indicating the installation was successful. Click “Finish” to quit. 8520-R1 4-Port Wireless N Gateway...

  • Page 120: Appendix E: Glossary

    CBR: Constant Bit Rate: A constant transfer rate that is ideal for streaming (executing while still downloading) data, such as audio or video files. Cell: A unit of transmission in ATM, consisting of a fixed-size frame containing a 5-octet header and a 48-octet payload. 8520-R1 4-Port Wireless N Gateway...
  • Page 121 DSL lines and places the signals on a high-speed backbone line. DSLAMs are typically located at a telephone company’s CO (Central Office). Encapsulation: The inclusion of one data structure within another. For example, packets can be encapsulated in an ATM frame during transfer. 8520-R1 4-Port Wireless N Gateway...
  • Page 122 Host: In context of Internet Protocol, a host computer is one that has full two way access to other computers on the Internet. IAD: Integrated Access Device: A device that multiplexes and demultiplexes communications in the CPE 8520-R1 4-Port Wireless N Gateway...
  • Page 123 NAPT: Network Address and Port Translation: An extension of NAT, NAPT maps many private internal addresses into one IP address. The outside network (WAN) can see this one IP address but it cannot see the individual device IP addresses translated by the NAPT. 8520-R1 4-Port Wireless N Gateway...
  • Page 124 USB port. This enables the ADSL WAN access to be shared with multiple nodes on the LAN. Network Address Translation (NAT) is supported so that one WAN-side IP address can be shared among multiple LAN-side devices. DHCP is used to serve each LAN-side device and IP address. 8520-R1 4-Port Wireless N Gateway...
  • Page 125 VC: Virtual Circuit: A virtual circuit is a circuit in a network that appears to be a physically discrete path, but is actually a managed collection of circuit resources that allocates specific circuits as needed to satisfy traffic requirements. 8520-R1 4-Port Wireless N Gateway...
  • Page 126 LAN systems. WPS: Wi-Fi Protected Setup is a standard for easy and secure establishment of a wireless home network 8520-R1 4-Port Wireless N Gateway...

  • Page 127: Appendix F: Regulation

    But if it does, the user will be required to correct the interference at his or her own expense. The authority to operate this equipment is conditioned by the requirement that no modifications will be made to the equipment unless Innoband expressly approves the changes or modifications.
  • Page 128 Do not use any other power adapter except the one that accompanies the unit. Use of other adapter could result in damage to the unit. To prevent electronic shock, please do not open the cover. 8520-R1 4-Port Wireless N Gateway...

  • Page 129: Appendix G: Warranties

    Appendix G: Warranties Innoband warrants that equipment furnished will be free from defects in material and workmanship for a period of one year from the confirmed date of purchase of the product new from the purchase location. Upon written notice of any such defect, the manufacturer will, at its option, repair or replace the defective item under the terms of this warranty, subject to the provisions and specific exclusions listed herein.

  • Page 130: Registration Card

    Serial Number: Purchased from: Date of Purchase: Please cut out the above Product Registration Card and send in with a self-addressed stamped envelope to: Innoband Technologies, Inc. 2526 Qume Dr Ste21, San Jose, CA 95131 8520-R1 4-Port Wireless N Gateway...

  • Page 131: Appendix H: Contact Information

    We would more than love to help if you have further technical questions, please visit our Website at http://www.innoband.com or send E-mail to support@innoband.com To purchase accessories or replacement parts for this router, please visit http://www.innocow.com Company Address Innoband Technologies, Inc 2526 Qume Dr Ste21, San Jose, CA 95131 8520-R1 4-Port Wireless N Gateway...

Table of Contents
