2.2 Front Panel

2.3 Back Panel

2.4 Connection

2.4.1 Power connection

The player's power voltage: DC 5V.
Press to stop playback.
Navigational button. Press the arrow buttons to select menu
options.
Press to enter file editing menu in file manager.
Press to enter file selecting menu in media library.
Navigational button. Press the arrow buttons to select menu
options.
Press to return to the previous screen while navigating menus.
7
1. POWER button
2. Copy button
3. Memory Card slot
4. Status indicator
5. USB HOST port
1. DC-IN jack
2. A/V OUT jack
3. HDMI connector
4. USB3.0 DEVICE port
