InHand InRouter 600 Series User Manual

Inrouter 600 series
Hide thumbs
Table of Contents

Advertisement

Quick Links

InRouter 600 Series User's Manual
www.inhandnetworks.com
InRouter 600 Series User's Manual
First Edition, August, 2011
© 2011 InHand Networks, All rights reserved.
Republication without permission is prohibited.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InRouter 600 Series and is the answer not in the manual?

Questions and answers

Related Manuals for InHand InRouter 600 Series

Summary of Contents for InHand InRouter 600 Series

  • Page 1 InRouter 600 Series User’s Manual www.inhandnetworks.com InRouter 600 Series User’s Manual First Edition, August, 2011 © 2011 InHand Networks, All rights reserved. Republication without permission is prohibited.
  • Page 2 All rights reserved. Reproduction without permission is prohibited. Trademarks InHand is a registered trademark of InHand Networks. Other registered marks cited in this manual represented their respective companies. Disclaimer Information in this document is subject to change without notice and does not represent an obligation on the part of InHand Networks.
  • Page 3 InRouter 600 Series User’s Manual www.inhandnetworks.com Introduction to InRouter 601 Overview ◆ Package Checklist ◆ Product Features & Specifications ◆ Product Models ◆...
  • Page 4 InRouter601 is ideal for industrial applications choice. InRouter 600 series products support VPN (IPSec/PPTP/ L2TP/GRE/SSL VPN), which create high-security links between remote equipment and customer’s center. Application data in a secure IPSec tunnel transmission, preventing data be thieved and tampered.

  • Page 5: Important Safety Information

    InRouter 600 Series User’s Manual www.inhandnetworks.com Important Safety Information This product is not intended for use in the following circumstances  Area(s) where radio transmission equipment (such as cell phone) are not permitted.  Hospitals, health care facilities and area(s) where cell phones are restricted by law.

  • Page 6: Package Checklist

    We put each In Router 601 cellular router in a box with standard accessories. Additionally, there’re optional accessories can be ordered. When you receive our package, please check carefully, and if there’re items missing or appearing to be damaged, please contact with your InHand Networks sales representative. Items in package include:...

  • Page 7: Product Features

    InRouter 600 Series User’s Manual www.inhandnetworks.com 1.3 Product Features 1.3.1 Interface Cellular WAN: Band Options: HSUPA /HSDPA/WCDMA 850/900/1900/2100MHz GSM/GPRS/EDGE 850/900/1800/1900MHz Ethernet WAN: Ethernet: 10/100 Mbps, RJ45 connector, Auto MDI/MDIX Magnetic Isolation Protection: 1.5 KV built-in IR601/611 Number of Ports: 1 Ethernet: 10/100 Mbps, RJ45 connector, Auto MDI/MDIX Magnetic Isolation Protection: 1.5 KV built-in...
  • Page 8 InRouter 600 Series User’s Manual www.inhandnetworks.com 1.3.2 Functions Supported VPDN/APN, fast access to virtual private dial-up network (VPDN) provided by mobile operator, ensure high-security data transmission. Support CHAP/PAP/MS-CHAP/MS-CHAP V2 authorization Support Connection Detection, auto-recovery, auto-link, ensure reliable communication. Support On-demand connection, SMS Activity...

  • Page 9: Warranty

    Housing: Steel, providing IP30 protection Weight: 490g Dimensions (mm) 1.3.6 Advanced Industrial Characteristics Physical Characteristics: Shell: Metal, IP30 1.3.7 Device Management Software Device Manager: Centralized management solution for InHand Networks Devices 1.3.8 Warranty Warranty Period: 1 year (Optional service for 3 years)

  • Page 10: Product Models

    InRouter 600 Series User’s Manual www.inhandnetworks.com 1.4 Product Models The current models of InRouter 600 Series include: InRouter 601/611. The models are classified according to main difference including cellular network, VPN support and interface for device. Ethernet Model Serial Cellular WAN...

  • Page 11: Quick Installation Guide

    InRouter 600 Series User’s Manual www.inhandnetworks.com Quick Installation Guide Typical Application ◆ Panel Layout ◆ Quick Connect to Internet ◆ Quick IPSec VPN Configuration ◆ Reset to Factory Defaults ◆...

  • Page 12: Typical Application

    2.1 Typical Application InRouter 600 series can be used to connect your device(with RS232/485/Ethernet Interface) to internet via GPRS/HSUPA cellular. Meanwhile, to ensure the security and access, InRouter 600 series support VPN, enabling remote access and secure data transmission through internet.

  • Page 13: Panel Layout

    InRouter 600 Series User’s Manual www.inhandnetworks.com 2.2 Panel Layout Front： Back:...
  • Page 14 InRouter 600 Series User’s Manual www.inhandnetworks.com Interface Description Power Interface Access 5-26V DC Power Supply Serial Access to the serial line, realizing Ethernet Ports One 10/100Base-TX RJ45 Port (IR601,IR611) ANTENNA 2.5G/3G antenna SIM Card Connector Put SIM card Description of LED...

  • Page 15: Quick Connection To Internet

    InRouter 600 Series User’s Manual www.inhandnetworks.com 2.3 Quick Connection to Internet 2.3.1 Insert SIM Card Push the yellow button next to SIM, then insert SIM CARD. 2.3.2 Antenna Installation After install the IR601, connect the interface of enhanced antenna and the interface of skin antenna and screw closely.
  • Page 16 InRouter 600 Series User’s Manual www.inhandnetworks.com 3) Click “Properties”, enter “Local Area Connection Properties” screen Choose “Internet Protocol (TCP/IP)”, click “properties” button, ensure your PC can obtain IP and DNS address automatically. (Or you can set your PC in the subnet: 192.168.2.0/24, for example, set IP: 192.168.2.10, Net Mask:...
  • Page 17 InRouter 600 Series User’s Manual www.inhandnetworks.com Click “OK”, InRouter will allocate an IP address: 192.168.2.X, and a gateway: 192.168.2.1(the default address of IR600). After configure TCP/IP protocols, you can use ping command to check whether the link between PC and Router is built correctly.
  • Page 18 InRouter 600 Series User’s Manual www.inhandnetworks.com 2.3.6 Start to configure your InRouter 600(Optional) After you have finished the former steps, you can configure the Router: Open IE browser, input the default IP address of the Router: http://192.168.2.1, you can see the login web below: Input “username”...

  • Page 19: Connect Inrouter With Internet

    InRouter 600 Series User’s Manual www.inhandnetworks.com Now the IP address of IR600 has been reset, and in order to enter the configuration web, you need set your PC in the same subnet, for example: 192.168.1.10/24 then input the changed IP address (192.168.1.254) in your IE Browser.

  • Page 20: Quick Ipsec Vpn Configuration

    If you need to build a VPN tunnel to realize access to your PLC far away through internet or you need ensure the security by using VPN. Here’s a quick configuration guide of IPSec for InRouter 600 Series. Connect PC with Router to enter router configuration web, select “VPN” => “IPSec setting”: Enable NAT-Traversal (NATT): select enable.
  • Page 21 InRouter 600 Series User’s Manual www.inhandnetworks.com Click “Add” to add a new IPSec Tunnel: Basic Parameters: set basic parameters of IPSec tunnel. Tunnel Name: name IPSec tunnel, the default is IPSec_tunnel_1. Destination Address: set to VPN server IP/domain, e.g.: the domain provided by GJJ is gjj-ovdp.3322.org.
  • Page 22 InRouter 600 Series User’s Manual www.inhandnetworks.com You can click “Show Detail Status” to observe the specific connection details, or click “Add” to add a new tunnel. Now you succeed to build a high-security IPSec tunnel, here’s an example: We set an IPSec Tunnel from subnet: 192.168.220.0/24 to subnet: 192.168.123.0/24, when it succeeds, the web will show: And the PC in IPSec client subnet can get access to the server’s subnet.

  • Page 23: Advanced Configuration

    InRouter 600 Series User’s Manual www.inhandnetworks.com Advanced Configuration Configuration on Web ◆...

  • Page 24: Configuration On Web

    InRouter 600 Series User’s Manual www.inhandnetworks.com 3.1 Configuration on Web InRouter must be correctly configured before use. This Chapter will show you how to configure via Web. 3.1.1 Preparation Firstly, connect your devices with IR600 by cable or HUB (switch), then set the IP of PC and IR600 in the same subnet, for example: Set PC IP to 192.168.2.50, net mask: 255.255.255.0, gateway (default IP of IR600: 192.168.2.1 ):...
  • Page 25 InRouter 600 Series User’s Manual www.inhandnetworks.com 3.1.2 System System settings include the 9 settings: Basic Setup, Time, Serial Port, Admin Access, System Log, Config Management, Update, Reboot and Logout. (1) Basic Setup Parameters Name Description Default Example Language Choose language of configuration web...

  • Page 26: Serial Port

    InRouter 600 Series User’s Manual www.inhandnetworks.com (2) Time Name Description Default Router Time Display router time 2000-01-01 8:00:00 PC Time Display PC time (or the time of device linked with router) Time Zone Set time zone Custom Custom TZ string...

  • Page 27: Admin Access

    InRouter 600 Series User’s Manual www.inhandnetworks.com (4) Admin Access Name Description Default Username/Password Username Username for configuration web login Old Password To change the password, you need to input the old one 123456 New Password Input new password Confirm New Password...
  • Page 28 InRouter 600 Series User’s Manual www.inhandnetworks.com (5) System Log Name Description Default Log to Remote System Enable remote log server Disable IP address/Port (UDP) Set the IP and Port of remote log server Port: 514 Log to Console Enable remote log server...
  • Page 29 InRouter 600 Series User’s Manual www.inhandnetworks.com Click “update”, and then click “sure” to begin update as it shows below. Upgrade firmware succeed, and click “reboot” to restart IR600. (8) Reboot If you need to reboot system, please click ”System”=>”Reboot”, Then click ”OK” to restart system.
  • Page 30 InRouter 600 Series User’s Manual www.inhandnetworks.com 3.1.3 Network Network settings include configurations of Dialup, LAN, DNS, DDNS, Static Route, and etc. (1) Dialup Name Description Default Enable Enable PPP dialup Enable Time Schedule Set time for online and offline SHARED Enabled—device linked with Router Can access to internet.
  • Page 31 InRouter 600 Series User’s Manual www.inhandnetworks.com APN parameters provided by Local ISP, you can set TWO different group of cmnet/uninet dialup parameters (APN/Username/Password) and set one as backup “*99#”“*99***1#” or #777 Access Number Dialup parameters provided by Local ISP “gprs” or ”CDMA”...
  • Page 32 InRouter 600 Series User’s Manual www.inhandnetworks.com Time Range 2 Set Time Range 2 14:00-18:00 Time Range 3 Set Time Range 3 0:00-0:00 Description Describe configuration Blank (2) LAN Notice: please DO NOT set LAN address as: 192.168.3.x (an IP for DMZ port).
  • Page 33 InRouter 600 Series User’s Manual www.inhandnetworks.com Name Description Default Primary DNS Set Primary DNS Blank Secondary DNS Set Secondary DNS Blank (4) DDNS (Dynamic DNS) Name Description Default Current Address Show the current IP address Blank Service Type Select DDNS Provider...
  • Page 34 InRouter 600 Series User’s Manual www.inhandnetworks.com Destination Set IP address of destination Blank Net Mask Set subnet Mask of destination 255.255.255.0 Gateway Set the gateway of destination Blank Interface Optional LAN/WAN port access to destination Blank Description Describe static route Blank 3.1.4 Service...
  • Page 35 InRouter 600 Series User’s Manual www.inhandnetworks.com Name Description Default Enable DNS Relay Click to enable DNS Relay Disabled Designate IP address<=>DNS couples (20 at the most) IP Address Set IP address <=> DNS couples Blank Host Set the name of IP address <=> DNS couples...
  • Page 36 InRouter 600 Series User’s Manual www.inhandnetworks.com Name Description Default Mode Only SMS Query SMS Interval Set how long to check SMS 24 hours Trust Phone List Add trust Cell Phone List Name Description Default Mode SMS+IP Mode Vendor Set Vendor Name...
  • Page 37 InRouter 600 Series User’s Manual www.inhandnetworks.com (5) DTU Name Description Default Enable Click to enable DTU Disable DTU Protocol Set DTU protocol, Please see more in related Quick Guide Transparent Protocol Optional between TCP/UDP Work Mode Set DTU as client or server...
  • Page 38 InRouter 600 Series User’s Manual www.inhandnetworks.com Name Description Default Enable Click to enable filtering Blank Protocol Optional among TCP/UDP/ICMP Source IP address Set Source IP address Blank Source Port Set Source Port Blank Destination IP Set destination IP Blank Destination Port...
  • Page 39 InRouter 600 Series User’s Manual www.inhandnetworks.com Enable logging concerned with virtual IP Disable Description Describe this configuration Blank (5) DMZ (All Port Mapping) Mapping all the ports and then external PC can get access to all the ports of internal device behind IR600.
  • Page 40 InRouter 600 Series User’s Manual www.inhandnetworks.com 3.1.7 VPN This page introduces the parameters set in InRouter 600’s Web. (1) IPSec Settings To build an IPSec VPN Tunnel, you need first set IPSec properties in this page, then turn to IPSec Tunnels to add your VPN: IPSec Settings Description: 1.
  • Page 41 InRouter 600 Series User’s Manual www.inhandnetworks.com Name Description Default Show Advanced Options Click to enable advanced options Disable Basic Parameters Tunnel Name To name the tunnel IPSec_tunnel_1 Destination Address Set the destination address of IPSec VPN Server Blank Startup Mode...

  • Page 42: Gre Tunnels

    InRouter 600 Series User’s Manual www.inhandnetworks.com (Enable Advanced options) Tunnel Type Optional: Subnet——Subnet Mode Host——Host, Host——Subnet, Subnet——Host, Subnet——Subnet Local Subnet Set IPSec Local Protected Subnet 192.168.2.1 Local Subnet Net Mask Set IPSec Local Protected Subnet Net Mask 255.255.255.0 Remote Subnet Address...
  • Page 43 InRouter 600 Series User’s Manual www.inhandnetworks.com Enable Click Enable Enable Tunnel Name Set GRE Tunnel Name tun0 Local Virtual IP Set Local Virtual IP 0.0.0.0 Remote Address Set Remote Address 0.0.0.0 Remote Virtual IP Set Remote Virtual IP 0.0.0.0 Remote Subnet Address Set Remote Subnet Address 0.0.0.0...
  • Page 44 InRouter 600 Series User’s Manual www.inhandnetworks.com Link Detection Interval Set Link Detection Interval Max Retries for Link Detection Set Max Retries for Link Detection Enable NAT Click Enable NAT Disable Set MTU parameters 1500 Set MRU parameters 1500 Enable Debug Mode...
  • Page 45 InRouter 600 Series User’s Manual www.inhandnetworks.com Enable MPPE Click Enable MPPE Blank Enable MPPC Click Enable MPPC Blank Set MTU parameters 1500 Set MRU parameters 1500 Enable Debug Mode Click Enable Debug Mode Blank Expert Options For InHand R&D only Blank 3.1.8 Tools...
  • Page 46 InRouter 600 Series User’s Manual www.inhandnetworks.com (3) Link Speed Test Test link speed via unload or download 3.1.9 Status Status contains System, Modem, Network Connections, Route Table, Device List and Log. (1) System Status This page shows the status of system, including Name, Model Type, Current Version and etc.
  • Page 47 InRouter 600 Series User’s Manual www.inhandnetworks.com This page shows the status of Modem, including the signal level. (3) Network Connections This page shows the network connections via WAN or LAN (4) Route Table This page shows the route table of IR600.
  • Page 48 InRouter 600 Series User’s Manual www.inhandnetworks.com (6) Log This page shows the log of system, including download log file. For some situation when there’re some problems that can’t be diagnosed at the moment, you’ll be asked to provide the diagnose log to InHand engineers, you can click “Download System Diagnosing Data” then send the diagnose log to us.
  • Page 49 3.2 Support In case you have problems with the installation and use, please address them to us by e-mail: support@inhandnetworks.com. Copyright © 2011 InHand Networks, All rights reserved. Tel: 86-10-64391099-8022 Fax: 86-10-84170089 Address: Wangjing Science Park, Road Lizezhonger, Chaoyang District, Beijing, P. R. C, 100102 Website: http://www.inhandnetworks.com...
